Wine / Beverage Preservation Technology
INSTRUCTION MANUAL
Thanks for buying one of our Wine or Beverage cabinets. Before use, please read and
follow all safety rules and operating instructions.
1
WARNING
The information in this document is subject to modification without prior notice.
Some models are available in dedicated countries only.
All warranties are void if the appliance is being used for any purpose other than that for
which it was specifically designed. Warranty applies to the wine cabinet only and not to
the content of the wine cabinet.
This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.
Children should be supervised to ensure that they do not play with the appliance.
Please don't put acidic items, flammable and explosive goods into wine cabinet.
This appliance is intended to be used in household and similar applications such as
–Staff kitchen areas in shops, offices and other working environments;
–Farm houses and by clients in hotels, motels and other residential type environments;
–Bed and breakfast type environments;
–Catering and similar non-retail applications.
DANGER: Risk of child entrapment. Before you throw away your old wine chiller:
- Take off the doors;
- Leave the shelves in place so that children may not easily climb inside;
- When disposing of the appliance, do so only at an authorized waste disposal centre.
R600a WARNINGS
For your safety observe the following recommendations.
This appliance contains a small quantity of R600a refrigerant which is
environmentally friendly, but flammable. It does not damage the ozone layer, nor
does it increase the greenhouse effect.
During transportation and installation, ensure that the tubing of the refrigerant
circuit is not damaged.
Avoid using sharp objects near by the appliances.
Leaking refrigerant can ignite and may damage the eyes.
In the event any damage does occur, avoid exposure to open fires and any device
which creates a spark. Disconnect the appliance from the mains power.
Thoroughly ventilate the room in which the appliance is located for several
minutes.
2
Notify Customer Service for necessary action and advice.
The room you installing the appliance in must be at least 1 cubic metre per 8 grams
of refrigerant. The refrigerant quantity contained in this appliance is listed on the
Rating Plate of the appliance.
It is hazardous for anyone other than an Authorized Service Person to carry out
servicing or repairs to this appliance.
- WARNING: Keep ventilation openings in the appliance enclosure or in the built-in
structure clear of obstruction.
- WARNING: Do not use mechanical devices or other means to accelerate the
defrosting process, other than those recommended by the manufacturer.
- WARNING: Do not damage the refrigerant circuit.
- WARNING: Do not use electrical appliances inside the food storage compartments of
the appliance, unless they are of the type recommended by the manufacturer.
- WARNING: If you are not using the appliance, please unplug the power plug from
the socket or switch off the power supply.
- WARNING: This appliance is not intended for use by persons (including children)
with reduced Physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning use
of the appliance by a person responsible for their safety;
- WARNING:Children should be supervised to ensure that they do not play with the
appliance;
- WARNING: Do not use extension cords or ungrounded (two prong) adapters;
- WARNING: If the supply cord is damaged, it must be replaced by the manufacturer,
Its service agent or similar qualified person in order to avoid hazard.
Allow 24 hours before switching on the wine cabinet. During this time we
recommend that you leave the door open to clear any residual odors.
BEFORE LOADING & PLUGGING IN THE WINE CABINET
Important: All models without front venting (air opening) are strictly for free
standing only. (See technical chart)
Recommendations:
The location you have selected for your wine cabinet should:
- Be unencumbered and well ventilated;
- Be well away from any heat source and direct sunlight;
- Not be too damp (laundry, pantry, bathroom etc.);
- Have a flat floor;
- Have a standard and reliable electricity supply (standard socket to country standards,
linked to the ground), it is NOT recommended to use a multi-socket or extension lead;
- Have a surge protector fitted to the electrical outlet;
3
- Away from the microwave oven. Certain microwave ovens do not have wave
interference shield. When placed within 1 meter vicinity of the wine cabinet, they may
affect the operation of the wine cabinet.
Wine cabinet should be placed where the ambient temperature is constant (not to hot or
cold). If the temperature is too hot or cold, it will affect the performance of the cabinet.
Grounding instructions:
The wine cabinet must be grounded in case of power leakage. Grounding reduces the risk
of electrical shock. The wine cabinet is equipped with a power cord having an earth wire
and an earthed plug. The wine cabinet plug must be plugged into a grounded electrical
outlet.
Note: In locations where there is frequent lightning, it is advisable to use surge protectors.
Improper use of the earthed plug can result in the risk of electric shock. Consult a qualified
electrician or service person if the grounding instructions are not completely understood.
If the supply cord is damaged, it must be replaced by a qualified person in order to avoid
electrical hazard.
INSTALLING YOUR WINE CABINET
Unpack and remove all of the protection and adhesive strips from the packaging around
and inside the wine cabinet.
The wine cabinet must be positioned such that the plug is accessible. Release the power
cord. Move your wine cabinet to its final location. The wine cabinet should be installed in
a suitable place where the compressor will not be subject to physical contact.
Leveling your wine cabinet: Wine cabinet must be leveled BEFORE loading your wines.
Your wine cabinet is equipped with 4 adjustable feet to facilitate easy leveling. We
recommends that you tighten the back feet to the maximum and adjust the front feet to
level the wine cabinet.
INSTALLATION INSTRUCTIONS FOR BUILT IN WINE CABINETS:
(UNDERBENCH OR IN COLUMN) FRONT VENTING WINE CABINETS ONLY.
1. “Built in” wine cabinets are front venting but are not designed to be fully integrated
behind a joinery door.
4
2. Please follow the installation diagram when installing built-in wine cabinets. No less
than the minimum installation dimension, or it will affect the venting of cabinet.
3. Built-in wine cabinets draw air from right of ventilation frame and expel through left of
ventilation frame under the front door.
4. “Built in” wine cabinets have a power switch located on the control panel so power
point location is not critical.
5. The wine cabinet requires a standard 240 volt/10 amp power point.
6. The power cord is 2.0m in length and is fixed on the right side at the back when looking
from front of cabinet.
7. As with most appliances of today, the wine cabinet has sensitive electronic components
which are susceptible to damage through lightning and electricity supply faults. It is
therefore advised to use a power surge protector to avoid problems of this nature.
8. Air vent on door must be provided for built-in wine cabinets when a wood door
installed.
In Hot climate zone, an air vent or grid, with a minimum ventilation size of 200mm x
40mm MUST be cut out at the rear top of the back partitioning or at the top of either side
of the partitioning, allowing cool fresh air full access to flow into the 30mm gap located at
the rear of the cabinet.
This air vent or grid must not be opened on the same side as other appliances such as
ovens or an area that is sealed and without access to fresh cool air. Failing to comply with
the above specifications will void the WARRANTY.
INSTALLATION DRAWINGS FOR BUILT IN WINE CABINETS:
(UNDERBENCH OR IN COLUMN) FRONT VENTING WINE CABINETS ONLY.
Note: The appliance must be positioned so that the plug is accessible after installed.
DIMENSIONAL DRAWINGS:
5
WCSZ45BL
Installationholedepth575mm
≥
In st allation h ol e he igh t 45 7m m≥
Cabinetpanelthickness≥22mm
Cabine t pan el h o le h eig ht 465mm≥
Coolingairoutletmin200m
c2
Coolingairinletmin200m
c2
Installationholewidth565mm
≥
512mm
555mm
555mm
453mm
590mm
447mm
Cabinetpanelholewidth≥600mm
512mm
555mm
555mm
453mm
590mm
447mm
Installat ion hole height 457mm≥
In stallatio n hole dept h 575m m≥
Ventilation o pening width
≥40mm
Woo d Plate thickness 22mm≥
≥7mm
453mm
Ventilation opening width
≥40mm
In sta llat io n hol e hei gh t 45 7m m≥
Installation Instruction:
6
1.Put the wine cooler into the cabinet, then adjust the wine cooler to make it steady. Open
the door, take out the fixed plate , 2pcs Inner Hexagon Screws ,and Inner Hexagon
Screwdriver from accessory bag , then use the inner hexagon screwdriver to tighten the
fixed plate on the lower left side of wine cooler.
2.Take out 3pcs Phillips screws from accessory bag , use Phillips screwdriver to tighten
the fixed plate on the lower left side of wine cooler(1pcs screw) , then tighten the other
2pcs Phillips screws on the upper door hinge and lower door hinge.
BV60BL, BV60S, WCDZ60BL, WCDZ60S,
WCDZ60INT
7
WCDZ600TS, WCDZ600TBL, BV600TBL
OPEN ANGLE SIZE DRAWINGS:
BV60BL, BV60S, WCDZ60BL, WCDZ60S
8
WCBV60BL
WCDZ60INT
9
WCDZ600TS, WCDZ600TBL, BV600TBL
RADIATOR SYSTEM DESCRIPTION
BV60BL,BV60S,WCDZ60BL,WCDZ60S,WCBV60BL,WCDZ600TS,WCDZ600TBL,
BV600TBL WCDZ60INT Models use side anti-dew tube and Independent cooling
system:
