AVYCON NDAA Series Manual de usuario

NDAA

QUICK START GUIDE

IP CAMERAS

SERIES

1. INTRODUCTION..................................................................................................................

2. SAFETY INSTRUCTIONS....................................................................................................

3. INSTALLATION....................................................................................................................

3.1 Installation of Bullet Cameras.........................................................................................

3.2 Installation of Mini Dome Cameras................................................................................

3.3 Installation of Vandal-Proof Dome Cameras.................................................................

TABLE OF CONTENT

4. CONNECTING CABLES......................................................................................................

5. I/O ALARM WIRING DIAGRAM........................................................................................

6. LOGIN SYSTEM....................................................................................................................19

3.4 Installation of Bullet Cameras......................................................................................... 14

Thanks for purchasing our product. For any question or need, welcome contact us at any time.

We will make every effort to ensure correctness of the information contained in this manual,

which may be subject to change from time to time without prior notice.

1. Introduction

2. Safety Instructions

1) Please comply with the power supply speciﬁcations as required for this equipment and

select the correct power supply.

2) In case that the equipment fails to operate properly, immediately contact the manufacturer

or the nearest service center, instead of disassembling or changing it in any way on your

own.

3) For cleaning of the lens, be sure to use an air blower or dedicated lens cleaner. For cleaning

of the plastic shield, use a soft and dry cloth to wipe it. Do not use any detergent containing

alcohol or benzene.

4) Do not drop any object onto the device or Knock heavy on the equipment.

5) Do not put the camera toward any strong light source (or lighting lamp or sun), which may

cause over-exposure or light leakage (not due to defect of the product) and impair useful

life of the camera.

6) Avoid use of the equipment in any environment other than suggest in this manual.

7) Prevent water or any other liquid from ﬂowing into the equipment.

2 IP CAMERAS | NDAA SERIES

8) For replacement of any part, contact the distributor in advance and make replacement with

a new one , or similar components which have the same speciﬁcation. Change any part in the

device without authorization is not permit.

Operating Environment

Power Supply

DC12V±10%

Temperature

-30°C~60°C

Humidity

10%~95%

Altitude

-60m~3000m

Atmosphere

86kpa~106kpa

3 IP CAMERAS | NDAA SERIES

3. Installation

a. Ceiling Mounting

3.1 Installation of Bullet Cameras

Expansion Bolt

Locking Screw

4 IP CAMERAS | NDAA SERIES

Insert three expansion bolts in place into the ceiling and ﬁx the equipment with three locking

screws.

Completion of Installation

b. Wall Mounting

Expansion Bolt

Locking Screw

5 IP CAMERAS | NDAA SERIES

Insert three expansion bolts in place into the wall and ﬁx the equipment with three locking

screws.

Ceiling Mounting

Completion of Installation

3.2 Installation of Mini Dome Cameras

6 IP CAMERAS | NDAA SERIES

7 IP CAMERAS | NDAA SERIES

Setup of Sticker

Paste the sticker in place at the proper position as selected.

Mini Dome Camera

IP CAMERAS | NDAA SERIES

Remove the collar off the camera by rotating it down

Collar

Expansion Bolt

Locking Screw

9 IP CAMERAS | NDAA SERIES

Fix the pedestal by drilling locking holes around the sticker and inserting three expansion

bolts into the holes and fastening it with three locking screws.

Adjust it to an appropriate angle.

Mount the collar back by rotating it up
