OVERVIEW

-1-

1. PRODUCT OVERVIEW

1.1 Description

This PTZ network camera series is a high-performance device for use in professional and demanding surveillance

situation. It supports multiple network protocols for MPEG4 or MJPEG live video transmission, and you can easily view,

record and operate the camera via the supplied video viewer software or the web browser. Video surveillance over IP

network infrastructure is available and easy from anywhere, at anytime.

1.2 Features

 Built-in 22x / 3x optical zoom lens with auto focus lens

 Intelligent auto tracking function to follow intruders (AVI321 only)

 Area Zoom functions – Draw a square in the live view with your mouse and the PTZ network camera

will zoom in the assigned area.

 Motion detection and alarm notification functions

 Real time MPEG-4 network transmission

 Low-latency video streaming for sharp and clear images

 Hybrid digital / analog video output

 Control network camera via Central Management System (CMS) software

 Excellent precision controllability using joystick or keyboard controller

 Support external microphone input

 Complete IP surveillance system, such as the Central Management System (CMS) software,

Network-Attached Storage (NAS), Network Video Recorder (NVR), etc.

OVERVIEW

-2-

1.3 Package Contents

‧ AVI321

◎In the camera package: ◎In the bracket package (Optional) :

□Bracket

□Wall mounting screw * 4

□Wall plug * 4

□Cap * 1

□M6 Nylok screw * 6

□Spirit level * 1

□ 22X PTZ network camera

□ CD-ROM disc for user manual

□ CD-ROM disc for Video Viewer AP Software

□M4 screw * 1

‧ AVI311

□ 3X PTZ network camera □Screw * 3

□ CD-ROM disc for user manual □Wall Plug * 3

□ CD-ROM disc for Video Viewer AP Software □Decoration Cover * 3

Note: The DC12V 1A adapter, power cord and RJ45 network cable are not included with the sales package.

Please prepare by yourself.

OVERVIEW

-3-

1.4 Specifications

SPECIFICATIONS* AVI321 AVI311

▓Network

LAN Port YES

LAN Speed 10/100 Based-T Ethernet

Supported Protocols DDNS, PPPoE, DHCP, NTP, SNTP, TCP/IP,

ICMP, SMTP, FTP, HTTP, RTP, RTSP

Frame Rate NTSC:30, PAL:25

Number of Online Users 10

Security Multiple user access levels with password

Web management software YES (Control up to 16 network cameras simultaneously)

▓Video / Audio

Video Compression MPEG4 / MJPEG

Video Remote Control YES

Video Adjustment Brightness, Contrast, Saturation and Hue

Audio Compression uLaw , 128kbps

Audio Input External Microphone Input

▓Camera

Image Sensor 1/4" Sony Color Super HAD CCD 1/3" Sony Color Super HAD CCD

Pixels 768(H)*494(V)<NTSC> / 752(H)*582(V)<PAL>

Resolutions 480 TVL

Lens f3.9 ~ 85.9mm f4.2 ~ 12.7mm

F-number F1.6 (Wide) ~ 3.7 (Tele) F2.6 (Wide) ~ 4.3 (Tele)

Viewing Angle 4∘~ 80∘26.7° ~ 80°

Pan Range 360∘

Tilt Range 90∘

Zoom 22X Optical Zoom (f3.9 ~ 85.9mm) 3X Optical Zoom (f4.2 ~ 12.7mm)

Max Speed Pan 360º/s, Tilt 90º/s Pan 27º/s, Tilt 18º/s

Shutter Speed 1 / 60 (1/50) to 1 / 100,000 sec.

Min Illumination 1 Lux / F1.6 1.5 Lux / F2.6

Video Output 1.0 Vp-p. 75Ω

BLC On / Off

White Balance ATW

Camera ID 0~255

▓Others

Remote Control YES

Motion Detection YES

Alarm and event Notification Image upload over FTP and Email

General I/O Alarm in x1

Power 12VDC, 1A

Operating Temperature 0~40℃

Humidity 85%

Minimum Web Browsing Requirements

‧Pentium 4 CPU 1.3 GHz or higher, or equivalent AMD

‧256 MB RAM

‧AGP graphics card , Direct Draw, 32MB RAM

‧Windows XP, Windows 2000 Server, ME, 98, DirectX 9.0 or later

‧Internet Exploerer 6.x or later

Dimension (L x W x H) 145(D) x 184(H) mm 134(D) x 122(H)

Shipping Weight NA NA

Indoor / Outdoor Application Outdoor Indoor

* The specifications are subject to change without notice.

CONNECTOR OVERVIEW

-4-

2. CONNECTOR OVERVIEW

2.1 CONNECTOR OVERVIEW

CONNECTOR DESCRIPTION

Power Connector Connect the DC 12V adapter for power supply.

Video Output Connector Connect to the video input connector of your monitor with a video cable (i.e. a RCA line with the

BNC connector, or a coaxial line) for video output.

* The video cable is not included with the sales package.

Audio Input Connector Support the connection to an audio device, such as a microphone, for voice transmission of the

local side.

RJ11 Connector

Get a RJ11 line with the proper length to your connection.

Different RJ11 line may have different line layout, so the connection might be different. If you

cannot control the PTZ network camera after connection, please reverse the RJ11 line layout and

try again.

RJ45 Jack Connector Get a R45 network cable with the proper length to your connection. And connect the network

camera to the network.

INSTALLATION

-5-

3. INSTALLATION

3.1 Install the Hardware (For AVI321)

Before installation, you need the following items before installation:

‧ Bracket (supplied with the bracket sales package)

‧ The accessory packages supplied with the bracket sales package, including:

(1) Wall mounting screws

(2) Wall plugs

(3) Cap

(4) M6 Nylok screws

(5) Spirit level

(6) M4 screw

‧ Power Drill

STEP 1: Attach the camera-mounting base to the PTZ camera.

Put the all the camera connectors through the hole of the camera-mounting base. Align the breach of the

camera-mounting base to the sticker label on the camera, and use two M6 Nylok screws to attach the

camera-mounting base to the camera, as shown in the picture below.

STEP 2: Attach the bracket to the wall.

The bracket is composed of two parts: the upper part and the bottom part. Remove the upper part from the

bottom part of the bracket. Use the four mounting screws and wall plugs to attach the bottom bracket to the wall,

as shown in the picture below.

Use the spirit level supplied with the bracket package to check the surface is horizontal or not. If the surface is

horizontal, the bubble will remain in the center circle of the spirit level.

INSTALLATION

-6-

STEP 3: Attach the PTZ network camera to the bracket.

Turn the camera up side down, and put the power, video and RS485 data connectors through the hole of the

bracket. Then, slightly secure the camera and the bracket with three M6 Nylok screws.

STEP 4: Check the surface is horizontal or not.

Use the spirit level to check the surface is horizontal or not, and adjust the tightness of the M6 Nylok screws.

When you make sure the surface is horizontal, use the M4 screw to fix the camera and the bracket tightly.

STEP 5: Connect the power, video, audio, RJ11, RJ45 connectors.

Arrange the cables in the proper position. Put the cables through the slot and connect the camera with the

indicated power adapter, video cable, audio cable, RJ11 cable and RJ45 cable. After connection, use the

insulation tape to cover the connected wires and arrange the cables in the proper position again.

STEP 4: Replace the upper part of the bracket and finish the installation.

Replace the upper part of the bracket and fasten the bracket with a M6 Nylok screw. Then use the cap supplied

with the package to cover it and finish the installation.

INSTALLATION

-7-

3.2 Install the Hardware (For AVI311)

Before installation, you need the following items before installation:

‧ The accessory package which includes:

(1) Wall mounting screws

(2) Wall plugs

(3) Decoration covers

‧ Power Drill or screwdriver

STEP 1: Mount the camera to the ceiling.

Attach the camera to the ceiling, and fasten the camera with the supplied 3 screws.

STEP 2: Push the decoration covers to the camera to lock.

When the camera is mounted, find the supplied 3 decoration covers in the accessory package, and push them to

the camera to lock as shown below.

STEP 3: Connect the power, video, audio, RJ11, RJ45 connectors.

Please refer to Step 5 in “3.1 Install the Hardware (For AVI321)”.

INSTALLATION

-8-

3.3 Assign an IP address and Access the Camera

Step 1. Install the Software

Place the supplied Video Viewer AP software CD into your DVD- / CD-ROM drive. The installation process will

automatically start. Follow the on-screen instructions to install the application programs. After installation, a “Video

Viewer” shortcut icon will be shown on your PC desktop.

Step 2. Connect the network camera to the Internet access via a RJ-45 network cable.

Step 3. Search the available IP address to login

a) Double-click “ ” icon on your PC desktop to enter the Video Viewer control panel. By defaults, the “Address

Book” ( ) panel will be displayed on the right side of the Video Viewer control panel.

b) Click ” ” (Search) ” ” (Refresh) to search the available IP address(es). The found address(es)

will be listed, and can be added into the address book by clicking ” ” (Add into address book).

For details, please see “ ” (Search) at page 11.

c) Select the IP address you just added into the address book, and click “ ” (Edit) to edit the settings.

d) Double-click the IP address in the address book to login.

Note: For detailed network settings under different network types (Static IP / PPPOE / DHCP), please refer to

your user manual.

‧ If you cannot search any available IP address, please follow the instructions below.

Step 4. Add the IP address and other network settings to login

a) Double-click “ ” icon on your PC desktop to enter the Video Viewer control panel. By defaults, the “Address

Book” panel will be displayed on the right side of the Video Viewer control panel.

b) The default network camera settings are as follows:

Item Default Setting

IP Address 192.168.1.10

User Name admin

Password admin

Port Number 80

c) Click ” ” (Address Book) ” ” (Add) button to key in the IP address, user name, password, and

port number of the network camera you intend to connect.

Item Default Setting

IP Address 192.168.1.10

User Name admin

Password admin

Port Number 80

d) Double-click the IP address you just added into the address book to login.

APPENDIX 1 DEFAULT VALUE

-9-

4. VIDEO VIEWER BASIC OPERATION

4.1 The Live View Page

After setting up the network information, login user name and password, double-click “ ” on the PC desktop to open

and log into the Video Viewer control panel. You will see a screen similar to the following with 6 major sections:

‧ Connect to only one network camera ‧ Connect to multiple network cameras (ex. 4 cameras)

‧ 1-cut display ‧ 4-cut display

NO. Button Function Description

1Image Display

To switch to another camera view if two or more network cameras are connected,

click the corresponding blue tab. The camera title shown in the blue tab can be

customized (For example, “321”, “311”, “Play1” and “Digi”). The default camera

title is “Camera1”.

Scale Click to view the images in the full screen, 4-cut, 9-cut and 16-cut mode.

Full Screen Click to view the images in the full screen mode. To exit the full screen mode,

press “Esc” key on the keyboard of the PC.

Click to close the current image display view.

If the image display view is closed, you will be logged out automatically.

Close All

Click to close all the current image display view.

If the image display view is closed, you will be logged out automatically.

2Address Book Click to show the predefined IP address(es). You can add, remove or search the

IP address to login the network camera remotely.

Miscellaneous

Control

Click to show the main operation functions: audio volume control, color setting,

backup, record setting, server setting, upgrade, and find status log list.

4/ Record Click to start / stop the manual recording.

5Snapshot Click to take a snapshot of the current view. The snapshot will be saved in the path

you specified in Record Setting.

6Information Click to show the current network connection details.

7PTZ Click to show the PTZ control functions: auto tracking, auto move, auto pan, zoom

in, zoom out, focus near and focus far …etc.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cámara de seguridad de Avtech

Avtech

Avtech AVM3445-LW Manual de usuario

Avtech

Avtech AVT1105TP Manual de usuario

Avtech

Avtech AVI 201 Manual de usuario

Avtech

Avtech AVN263 Manual de usuario

Avtech

Avtech AVN222 Manual de usuario

Avtech

Avtech AVC307R Manual de usuario

Avtech

Avtech KPC131E Manual de usuario

Avtech

Avtech AVK584ZN Manual de usuario

Avtech

Avtech KPC132 Manual de usuario

Avtech

Avtech M301 Manual de usuario

Avtech

Avtech AVM359a Manual de usuario

Avtech

Avtech AVC153 Manual de usuario

Avtech

Avtech AVN808 Manual de usuario

Avtech

Avtech DG104 Instrucciones de funcionamiento

Avtech

Avtech AVM357A Manual de usuario

Avtech

Avtech AVT1301 Manual de usuario

Avtech

Avtech IR Done Camera Manual de usuario

Avtech

Avtech DG103 Instrucciones de funcionamiento

Avtech

Avtech AVM3455 Manual de usuario

Avtech

Avtech MEGAPIXEL WIRELESS NETWORK CAMERA SERIES Manual de usuario

Avtech

Avtech 960H Manual de usuario

Avtech

Avtech DGC5205T Manual de usuario

Avtech

Avtech DGC1104XFT Manual de usuario

Avtech

Avtech AVC489A Manual de usuario

Manuales populares de Cámara de seguridad de otras marcas

Okina USA

Okina USA SIR36-870VF650LP Manual de usuario

Divio

Divio NDR155PA Manual de usuario

Canon

Canon VB-C500D Manual de usuario

Easy Access

Easy Access EasyGuard Manual de usuario

Vivotek

Vivotek FD9389-EHV-v2 Manual de usuario

TUYA

TUYA COSMO W2 Manual de usuario

Eusso

Eusso UNC7500-IR Guía de configuración

urmet domus

urmet domus 1096/204 Manual de usuario

VC VC20 series Manual de usuario

Axis

Axis Q1614 Manual de usuario

ieGeek

ieGeek DD201 Manual de usuario

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manual de usuario

Vicon

Vicon V662-D-1 Instrucciones de funcionamiento

Grundig

Grundig GCH-K0274P Manual de usuario

Lorex

Lorex VANTAGE LBC7032 Manual de usuario

4xem

4xem WPT Manual de usuario

Samsung

Samsung SCV-3082 Manual de usuario

Vitek

Vitek VTC-C544 Manual de usuario
