Avision BT-2202B Manual de usuario

A3 Bookedge Scanner

User’s Manual

Regulatory model: BT-2202B

Avision Inc.

User’s Manual

Trademarks

Microsoft is a U.S. registered trademark of Microsoft

Corporation.

Windows 7, Windows 8, Windows 10, and Windows 11 are either

registered trademarks or trademarks of Microsoft Corporation in

the United States and/or other countries.

Energy Star®is a registered trademark of the U.S. government.

Other brands and product names herein are trademarks or

registered trademarks of their respective holders.

reproduced, transmitted, transcribed, stored in a retrieval

system, or translated into any language or computer language,

in any form or by any means, electronic, mechanical, magnetic,

optical, chemical, manual, or otherwise, without the prior

written permission of Avision Inc.

Material scanned by this product may be protected by

governmental laws and other regulations, such as copyright

laws, the customer is solely responsible for complying with all

such laws and regulations.

Warranty

The information contained in this document is subject to

change without notice.

Avision makes no warranty of any kind with regard to this

material, including, but not limited to, the implied warranties

of fitness for a particular purpose.

Avision shall not be liable for errors contained herein or for

incidental or consequential damages in connection with the

furnishing, performance, or use of this material.

User’s Manual

iii

Federal Communications Commission (FCC) compliance

information statement

Part 15

The product has been tested and found to comply with the

limits for a Class A digital device pursuant to Part 15 of the FCC

Rules. Operation is subject to the following two conditions: (1)

this device may not cause harmful interference and (2) this

device must accept any interference received including

interference that may cause undesired operation.

The FCC Class A limits are designed to provide reasonable

protection against harmful interference when the equipment is

operated in a commercial environment. This equipment

generates, uses, and can radiate radio frequency energy and, if

not installed and used in accordance with the instruction

manual may cause harmful interference in which case the user

will be required to correct the interference at his own expense.

European Union Regulatory Notice

Products bearing the CE marking comply with the following EU

Directives:

Low Voltage Directive 2014/35/EC

EMC Directive 2014/30/EC

Restriction of the use of certain hazardous substances

(RoHS) Directive 2011/65/EU

CE compliance of this product is valid if powered with the correct

CE-marked AC adapter provide by Avision.

This product satisfies the Class B limits of EN55022, EN55024,

safety requirements of EN 60950 and ROHS requirements of

EN50581.

*This machine is certified as Class 1 LED product.

User’s Manual

CE Warning

This is a class A product. In a domestic environment this

product may cause radio interference in which case the user

may be required to take adequate measures.

Disposal of Waste Equipment by Users in Private Union

This symbol on the product or on its packaging indicates that

the product can not be disposed of with your other household

waste. Instead it should be sent to appropriate facilities for

recovery and recycling in an effort to protect human health and

the environment. Fore more information about where you can

drop off your waste equipment for recycling, please contact

your local city office, your household waste disposal service or

the shop where you purchased the product.

As an ENERGY STAR®Partner, Avision Inc. has

determined that this product meets the ENERGY

STAR guidelines for energy efficiency.

System Requirements

CPU:

Intel®Core™ 2 Duo or higher

Memory:

32 bit: 2 GB

64 bit: 4 GB

USB Port:

USB 3.2 Gen 1x1 (compatible to USB 3.0/3.0)

Compatible

Operating

System:

Microsoft Windows 7, Windows 8 (32 bits/64

bits), Windows 10 (32 bits/64 bits), Windows

User’s Manual

Product Safety Guide

Please clearly read all these instructions, and follow all instructions

and warnings before installing and using the device.

The following indications are used in this document to obviate any

chance of accident or damage to you and/or the device.

WARNING

Indicates potentially hazardous situations, which

if instructions are not followed, could result in

death or serious injury.

CAUTION

Indicates a potentially hazardous situation

which, if instructions are not followed, may

result in minor or moderate injury or damage to

property.

WARNING

Use only the AC power adapter that came with your device.

Using any other AC power adapter could cause fire, electrical

shock, or injury.

Use only the AC power cord and USB cable that came with

your device and avoid abrasions, cuts, fraying, crimping, and

kinking. Using any other AC power cord and USB cable could

cause fire, electrical shock, or injury.

Do not place objects on top of the AC power cord, and do not

allow the AC power adapter or the AC power cord to be

stepped on or run over.

Place the device and its AC power adapter near an electrical

outlet where the AC power adapter can easily be unplugged.

If you use an extension cord with the device, make sure that

the total ampere rating of the devices plugged into the

extension cord does not exceed the cord's ampere rating.

Place the device close enough to the computer so that the

interface cable can easily reach between the device and the

computer.

User’s Manual

Do not place or store the device or its AC power adapter:

Outdoors

Near excessive dirt or dust, water, or heat sources

In locations subject to shocks, vibrations, high

temperature or humidity, direct sunlight, strong light

sources, or rapid changes in temperature or humidity

Do not use the device with wet hands.

Never disassemble, modify, or attempt to repair the AC power

adapter, device, or device option by yourself, except as

specifically explained in the device's documentation. This

could cause fire, electrical shock, or injury.

Do not insert objects into any opening, as they may touch

dangerous voltage points or short-out components. Beware of

electrical shock hazards.

Unplug the device and the AC power adapter, and refer

servicing to qualified service personnel under the following

conditions:

The AC power adapter or plug is damaged.

Liquid has entered the device or the AC power adapter.

Object has entered the device or the AC power adapter.

The device or the AC power adapter has been dropped,

or the case has been damaged.

The device or the AC power adapter does not operate

normally (i.e. appearance of smoke, strange smell, odd

noise, etc.), or exhibits a distinct change in

performance

Unplug the device and the AC power adapter before cleaning.

User’s Manual

vii

CAUTION:

Do not locate the device on rackety or aslope tables. Do not

locate the device on unstable surface. The device may fall

down and this may result in injury.

Do not place heavy objects on the unit. It may cause

unbalance and the device may fall down. This may result in

injury.

Store the AC Power cord/USB cable bundled out of the reach

of children to avoid the risk of injury.

Keep plastic bags bundled out of the reach of children or

throw them away to avoid the danger of suffocation.

If you are not going to use the device for a long period,

unplug the AC power adapter from the electrical outlet.

User’s Manual

1-1

1. Introduction

Congratulations on your purchase of the Avision’s A3-sized

bookedge scanner. Avision is one of the leading companies to

make high quality color image scanner.

Before you install and operate the new scanner, please take

a few minutes to read through this manual. It provides

proper instructions for you to unpack, install, operate and

maintain the scanner.

The following figure indicates the package contents. Please

check all the items against your checklist. If you do not

receive all the items, please contact your authorized local

dealer immediately.

User’s Manual

1-2

1. Scanner Main Unit

2. Quick Guide

3. USB Cable

4. Power Adapter & Power Cord

Note:

1. Only use the AC adapter ADS-65LSI-24-3 24048E by

HONOR included in the machine. Using other AC adapters

may damage the machine and void the warranty.

2. Please unpack the packing carefully, and check the contents

against the checklist. If any items are missing or damaged,

please contact your dealer immediately.

3. To access more service supports, visit www.avision.com to

User’s Manual

2-1

2. Scanner Installation

2.1 Precautions

Keep the scanner out of direct sunlight. Direct exposure

to the sun or excessive heat may cause damage to the

unit.

Do not install the scanner in a humid or dusty place.

Be sure to use the proper AC power source.

Place the scanner securely on an even, flat surface.

Tilted or uneven surfaces may cause mechanical or

paper-feeding problems.

Retain the scanner box and packing materials for

shipping purposes.
