Avidsen 623382 Manual de usuario
EN
V1
ref. 623382
IP Camera
WIFI 720P
Motorised interior
CONTENTS
A - SAFETY INSTRUCTIONS 05
1 - OPERATING PRECAUTIONS 05
2 - MAINTENANCE AND CLEANING 05
3 - RECYCLING 05
B - PRODUCT DESCRIPTION 06
1 - KIT CONTENTS 06
2 - CAMERA 06
3 - MAINS ADAPTOR 07
C - INSTALLATION 08
1 - INSTALLING THE CAMERA 08
2 - INSERTING A MICRO SD CARD (NOT INCLUDED) 08
3 - CONNECTING THE CAMERA 09
D - CONFIGURATION 10
1 - CONFIGURING THE CAMERA AND ADDING IT TO THE APP 10
2 - ACCESS TO ALL SETTINGS 11
2.1 - CONFIGURATION 12
E - OPERATION 13
1 - LIVE VIDEO 13
2 - VIEWING VIDEOS RECORDED BY THE CAMERA 13
F - RESETTING 15
G - FAQ 16
3ENEN
MOTORISED 720P INDOOR WIFI IP CAMERA
3
H - TECHNICAL AND LEGAL INFORMATION 17
1 - TECHNICAL CHARACTERISTICS 17
2 - WARRANTY 18
3 - HELP AND ADVICE 18
4 - PRODUCT RETURNS/AFTER SALES SERVICE 18
5 - DECLARATION OF CONFORMITY 18
5EN
MOTORISED 720P INDOOR WIFI IP CAMERA
A - SAFETY INSTRUCTIONS
1 - OPERATING PRECAUTIONS
• The cameras must not be installed where the
lens filter may be vulnerable to scratching and
dirt.
• Do not expose the lens to direct sunlight or any
reflected light source.
• Do not daisy-chain extension cords and/or
multi-socket adapters.
• Do not install near acidic chemicals, ammonia
or sources of toxic gases.
• The installation and use of the camera must
comply with local laws.
• Do not move the camera motors by hand. This
could cause damage to the motors and void
the warranty
2 - MAINTENANCE AND CLEANING
• Always unplug the product from the mains
before carrying out any maintenance.
• Never use abrasive or corrosive substances to
clean the products.
• Use a soft, slightly damp cloth.
• Never use an aerosol to spray the product as
this may damage the internal workings.
3 - RECYCLING
This logo denotes that devices which are
no longer in use must not be disposed of as
household waste. They are likely to contain
hazardous substances that are dangerous to both
health and the environment. Return the equipment
to your local distributor or use the recycling collection
service provided by your local council.
Pour en savoir plus :
www.quefairedemesdechets.fr
6
MOTORISED 720P INDOOR WIFI IP CAMERA
EN
B - PRODUCT DESCRIPTION
1 - CONTENTS OF THE KIT
2 - CAMERA
1
6
7
8
4
5
9
10
2
3
1Camera
2230 V A/C 50 Hz mains adaptor / 5 V D/C
2 A
1Infra-red light for night vision
2Lens
3Dusk sensor for infra-red lighting control
4Microphone
5Loudspeaker
3Wall mounting bracket
4Wall plugs for wall-mounting
5Screws for wall-mounting
6Reset button: resets
7Mains adaptor power supply (included)
8Slot for microSD card (not included) of up
to 128 GB
9RJ45 network port (use is optional)
10 QR Code to be scanned when starting up
using the Protect-Home app (inside)
Front view Rear view
5x 2
4x 2
2x 1
1x 1 3x 1
7EN
MOTORISED 720P INDOOR WIFI IP CAMERA
B - PRODUCT DESCRIPTION
3 - MAINS ADAPTER
A 230 V A/C 50 Hz / 5 V D/C 2 A mains adapter for powering the camera is included in the kit. Do not use
other power supplies as they could damage the camera and invalidate the warranty.
8
MOTORISED 720P INDOOR WIFI IP CAMERA
EN
C - INSTALLATION
1 - INSTALLING THE CAMERA
The camera may be attached to a wall, the ceiling or placed on a flat, horizontal surface.
Fix the camera mount using screws and wall plugs suitable for the type of supporting surface (the screws
and plugs included are suitable for solid walls).
Make sure the camera is properly secured to prevent it from falling.
2 - INSERTING A MICRO SD CARD (NOT INCLUDED)
Your camera has a micro SD card slot, which gives it an internal storage memory. The maximum size is 128
GB.
This use is optional, but it is necessary if you want the camera to record independently.
9EN
MOTORISED 720P INDOOR WIFI IP CAMERA
C - INSTALLATION
3 - CONNECTING THE CAMERA
10
MOTORISED 720P INDOOR WIFI IP CAMERA
EN
D - CONFIGURATION
1 - CONFIGURING THE CAMERA AND
ADDING IT TO THE APP
Note: the screenshots displayed have been taken
from the Android version of the Protect-Home app.
The iPhone version works in exactly the same way.
Download the Protect-Home app from the
Appstore or Google Play, then launch the app.
Accept the authorisation requests sent by the app
if necessary (access to the camera for scanning the
QRCode, etc.).
Next, click on the icon , the app opens the
camera on your smartphone and invites you to scan
the QRCode shown on the camera:
At this point, the camera must be powered on and
started up. It plays a standby tune when it is ready.
Click on “Ready music played” to continue.
The app then asks you how you wish to configure
the camera:
AP connection: via WiFi connection.
Audio configuration: the data will be transmitted by
the smartphone loudspeaker.
Select one of the methods to continue (they are
equivalent):
