AVF JNL454 Manual de usuario
55"
140cm
JNL454 465391 rev01
40kg
88lbs
STOP
Read through instructions before commencing installation.
If you have any questions about this product or issues with installation
contact the customer services helpline before returning this product to
the store. See jl.avfgroup.com/p/jnl454 for more information.
ALL
AVF Group Ltd. Hortonwood 30, Telford, Shropshire, TF1 7YE, England
CUSTOMER SERVICES HELP LINE NUMBER:
+44 (0) 333 320 0463
Assembly Overview
Fit the TV Mounting Plate
Fit the Wall Bracket
Connect the TV
2 Person Installation Recommended
Measure the TV fixing holes Width and Height
1
Fitting the Wall Bracket
5
Connecting the TV
7
Index
Fitting the TV Mounting Plate
2
3
Fitting the Wall Bracket Covers
4
Preparing the Front Adaptor Plate
6
Retain all packaging in case the bracket needs to be returned.
Contents may vary from photography/ Illustrations.
You will not need all these parts, so expect there to be some left over depending upon the
specification of your TV.
This product is intended for indoor use only. Use of this product outdoors could lead to
failure and personal injury.
It is the responsibility of the installer to ensure that the mounting wall is of a suitable
standard and void of any services (eg gas, electricity, water etc).
AVF accept no responsibility for any damage or loss caused by installing this product in a
sub standard wall.
Preparing the TV Mounting Plate
Cable Management
8
B
B
A
C
Dx4
Stud Finder Ø3mm
Wood
Ø12mm
Masonry
Boxed Parts
Tools Recommended
Kx4 Lx4 Mx4
J2x4 J4x4
M4 M5
25mm
25mm
J6x4
M6
25mm
H1x4 H2x4
J9x4
M8
25mm
I1x12 I2x4
J7x4
M6
45mm
J10 x4
M8
45mm
16mm
M8
J8x4
J5x4
M6
16mm
J1x4
M4
16mm
J3x8
M5
16mm
Fx8 Gx16
M6
Ex8
M6
Nx1
4mm
TV Screws, Reducers and Spacers
You are provided with 4 diameters of TV fixing screws, M4, M5, M6 and M8.
Determine the screw diameter that fits and remember for step 4.
After completing step 4
you will have fittings left
over, please keep
for future reference
1
TV Fixing Holes
!
J5/J7
J3/J4
J1/J2
M8 =
M6 =
M4 =
M5 =
J8-J10
2
J3x4
M5
16mm
C
J3
Top
75 - 400mm
Y
If width X is greater than 400mm
or height Y greater than 400mm
STOP installation now and
contact the customer help line
!
75 - 400mm
X
Preparing the Front Adaptor Plate
Measure the TV fixing holes Width and Height
3
Use the option that fits your TV
Do not fully tighten
If in any doubt please call the customer help line.
X 400mm Y 100mm
X 400mm Y 200mm
X 300mm Y 200mm X 400mm Y 300mm
X 300mm Y 300mm X 400mm Y 400mm
OPTION 3
X 300mm Y 100mm
X 75 - 400mm Y 75 - 400mm
Preparing the TV Mounting Plate
OPTION 1
X 75mm
X 100mm Y 100mm
X 200mm Y 100mm
X 200mm Y 200mm
Y 75mm
OPTION 2
X 100mm Y 200mm
OPTION 1
X
If your TV fixing holes match any of the sizes
shown above you will not need to use any
adaptors.
Please go to step 4.
Y
C
100
mm
200mm
75
mm
100
mm
75
mm 200
mm
OPTION 2
I2x2
X 100mm
C
200mm
Y
Use spacer I2 between the bottom two holes of
the bracket and your TV.
OPTION 3
HOLES
TROUS
HOLES
TROUS
SLOTS / FENTES
SLOTS / FENTES
!
100
mm
X 300mm
Y
200
mm
X 300mm
Y
D D
CC
=
=
HOLES
SLOTS
When attaching adaptors D you
must always use HOLES x4 and
either of the SLOTS.
Example shown is
400mm x 400mm fixings.
Top
Fx8 Gx16
M6
Ex8
M6
G
F
E
C
D
D
D
D
Example shown is
400mm x 400mm fixings.
Top
G
F
E
C
D
D
D
D
Fx8 Gx16
M6
Ex8
M6
X 400mm
400
mm
Y
X 75mm - 400mm
D D
C C
Adaptors D can be fixed in different
positions in the slots on Plate C to
match your TV fixing holes.
75mm -
400mm
Y
200
mm
Y
X 400mm
300
mm
Y
X 400mm
D
D
CC
300
mm
Y
X 300mm
100
mm
Y
X 400mm
D
D
C C
=
=
HOLES
SLOTS
Spacers I1/I2
4
No Spacers
For Tvs with
flat/unobstructed back
For Tvs with irregular/obstructed back
Before you fully tighten the TV mounting plate please check that the
mounting plate holes line up with the fixing holes on the back of your TV.
Holes do not line up and
small adjustment is required
before you fully tighten
Holes line up and no
adjustment is required
before you fully tighten
Fitting the TV Mounting Plate
TV TV
TV
TV
WARNING
After completing step 4 you will have fittings left over, please keep
for future reference
!
