User Manual

Model: ZM 110

BSL Bench Scale

AWT35-501876 Issue AD Page 2

Avery Weigh-Tronix is a trademark of the Illinois Tool Works group of companies whose ultimate parent company is

No part of this publication may be reproduced, stored in an electronic retrieval system, or transmitted in any form or by any

means, electronic, mechanical, photocopying, recording or otherwise without the prior written consent of the copyright owner, or

as permitted by law or under license. Full acknowledgment of the source must be given.

Avery Weigh-Tronix is a registered trade mark of the Avery Weigh-Tronix group of companies. This publication was correct at

the time of going to print however, Avery Weigh-Tronix reserves the right to alter without notice the specification, design, price

or conditions of supply of any product or service at any time.

All third party brands and product names used within this document are trademarks or registered trademarks of their respective

holders.

Aucune partie de cette publication ne peut être reproduite, enregistrée dans un système de récupération électronique ou

transmise sous quelque forme ou par quelque moyen que ce soit, électronique ou mécanique, par photocopie, enregistrement

ou autre, sans l’accord écrit préalable du propriétaire du droit d’auteur ou tel qu’autorisé par la loi ou dans le cadre d’une

licence. La source doit être reconnue dans son intégralité. Avery Weigh-Tronix est une marque déposée du groupe de sociétés

Avery Weigh-Tronix. Le contenu de cette publication était correct au moment de sa mise sous presse. Toutefois, Avery Weigh-

Tronix se réserve le droit de modifier à tout moment et sans préavis les spécifications, la conception, les tarifs ou les conditions

d’approvisionnement de tout produit ou service.

Toutes les marques et tous les noms de produits tiers utilisés dans ce document sont des marques de commerce ou des

marques déposées de leurs propriétaires respectifs.

AWT35-501876 Issue AD Page 3

Table of Contents

1. General information and Warnings

page 6

FCC Declaration of Compliance - Déclaration de conformité..……...…………..…...

Training - Formation……………………..………………………………...……………...

Battery Safe Disposal - Élimination sécurisée des batteries……...…………………..

Routine Maintenance - Entretien de routine……………………………………..……..

Cleaning the Machine - Nettoyage de la machine………………………….………….

Sharp Objects - Objets tranchants………………………….………………...…….......

2. Introduction

page 8

Unpacking…………………………………….………………………..…………………..

General Installation Guidelines……………………….…...……………………………..

Levelling the Scale………………..…………………………….……..…………………..

Scale Installation...………………..…………………………….……..…………………..

Battery Operation…………………………….………………………..…………………..

Powering UP/DOWN the Scale…………………………………………………………..

Front Panel………...…………………………………….…………………………….......

Display Annunciators………………………………………………………………….

Operation Keys...……………………….…………………………………..…………

Error Codes………..…………………………………….…………………………….......

3. Scale Operation

page 12

Gross Weighing……………………………………………………………………………

Tare Weighing.………………..……………………………………….………….……….

Clear a Tare………………….……………………….………………………………..

Counting Mode……………………………………………………………………………..

Sampling Parts Prior to Counting.………………….………………………………..

Check Counting………………………………………………………………………..

Checkweighing Mode....……..………………………………….…….………….……….

Setting the Checkweighing Limits………………….………………………………..

AWT35-501876 Issue AD Page 4

Checkweighing Beeper Modes…………………………..…………………………..

Hold Mode for Animal Weighing………………………………………......……..………

Setting the Hold Mode…………...………………….………………………………..

4. Menus

page 17

User Menu……………………..……………………………...……….………….……..….

User Menu Levels………………….………………...……….……………………..…

User Functions Descriptions [UF].………………….……….…………………..……

Supervisor Menu....………………………….……………..………………….……..…….

Quick Calibration Menu……..………………………..……………………….……..…….

5. Scale Configuration [LF 2]

page 19

6. RS232 Communications [UF-6]

page 19

7. Replacement Parts

page 20

8. Loadcell Pinouts

page 20

AWT35-501876 Issue AD Page 5

Manual revision history

Current Issue

Date Created

Details of Changes

May 2019

New

Aug 2019

RS232 Kit added and Chapter 6 amended

Jan 2020

Check Counting, UF5 amended

Feb 2023

Hold Mode, UF5 updated

Please be aware this product contains

a lead acid battery which MUST be

removed and disposed of safely prior

to any disposal of the scale.

AWT35-501876 Issue AD Page 6

1. General Information and Warnings

1.1. FCC Declarations of Compliance - FCC Déclaration de conformité

United States

This equipment has been tested and found to comply with the limits for a Class A digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference when the equipment is operated in a commercial environment. This

equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in

accordance with the instruction manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful interference in which case

the user will be required to correct the interference at his own expense.

Canada

This digital apparatus does not exceed the Class A limits for radio noise emissions from digital

apparatus set out in the Radio Interference Regulations of the Canadian Department of

Communications.

Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables

aux appareils numériques de la Classe A prescrites dans le Règlement sur le brouillage

radioélectrique edicté par le ministère des Communications du Canada.Interference Regulations of

the Canadian Department of Communications.

AWT35-501876 Issue AD Page 7

1.2. Training - Formation

Do not attempt to operate or complete any procedure on a machine unless you have received the

appropriate training or read the instruction books.

Ne pas tenter d’utiliser la machine ou lui appliquer une quelconque procédure sans avoir reçu une

formation adaptée ou lu les manuels d’instruction.

CAUTION! Risk of electrical shock. Refer to qualified service personnel for service.

ATTENTION! Risque de choc électrique. Confier la réparation de l’appareil à un

personnel qualifié.

1.3. Safe Battery Disposal - Élimination sécurisée des batteries

Please be aware this product contains a lead acid battery which MUST be removed and disposed of

safely prior to any disposal of the scale.

This battery can be easily accessed by removing the battery cover found on the underside of the

indicator.

CAUTION! Danger of explosion if battery is incorrectly replaced. Replace only with

the same or equivalent type recommended by the manufacturer.

ATTENTION! Il y a danger d'explosion s'il y a remplacement incorrect de la batterie,

remplacer uniquement avec une batterie du même type ou d'un type équivalent

recommandé par le constructeur.

1.4. Routine Maintenance - Entretien de routine

IMPORTANT: This equipment must be routinely checked for proper operation and calibration.

Application and usage will determine the frequency of calibration required for safe operation.

PRUDENCE: Le fonctionnement et l’étalonnage de cet équipement doivent être vérifiés

régulièrement. Les applications et l’utilisation déterminent la fréquence de l’étalonnage requis pour

une utilisation en toute sécurité.

1.5. Cleaning of Scale - Nettoyage de la machine

Do - Ce qu’il faut faire

Do NOT - Ce qu’il ne faut pas faire

Wipe down the outside of product with a clean

cloth, moistened with water and a small amount

of mild detergent cleaning fluid.

Essuyer la partie externe des produits standard à

l’aide d’un chiffon propre légèrement imprégné

d’eau et d’une petite quantité de détergent doux.

Use harsh abrasives, solvents, scouring

cleaners or alkaline cleaning solutions.

Utiliser des produits abrasifs, des solvants,

des produits de récurage ou des solutions de

nettoyage alcalines.

Spray on to the cloth when cleaning and not

directly onto the indicator area.

Pulvériser tout produit de nettoyage spécifique

sur le chiffon.

Do not attempt to clean the inside of the

machine.

Tenter de nettoyer l’intérieur de la machine.

Spray any liquid directly on to the display

windows.

Pulvériser des liquides directement sur les

écrans d’affichage.

1.6. Sharp Objects - Objets tranchants

Do not use any sharp objects such as screwdrivers or long fingernails to operate the keys.

Ne pas appuyer sur les touches avec des objets tranchants tels que des tournevis ou même des

ongles longs.

AWT35-501876 Issue AD Page 8

2. Introduction

The ZM110 is a general-purpose indicator ideal for connecting to most bench and floor scales.

This indicator can easily be desk or pole mounted and comes with a power adaptor along with a

rechargeable lead acid battery to allow the scale to be used in applications where power outlets are

limited.

This ZM110 indicator comes standard with a range of easy-to-operate General weighing functions

along with basic Check weighing, Counting and Hold modes.

2.1 Unpacking

Carefully take the scale out of its package, make sure it’s not damaged and all accessories are

included.

•Remove the scale from the carton;

•Remove the protective covering;

•Inspect the scale and indicator for damage;

•Make sure all components are included:

1. ZM110 Indicator

2. Adaptor plus plug adaptors

3. BSL Platform, column and brackets

4. Product manual

2.2. General Installation Guidelines

To get the best performance from the scale try to place the ZM110 in a location that will not degrade

its accuracy.

•Avoid extremes of temperature. Try to avoid placing the scale in direct sunlight or near air vents;

•Place the scale on a level flat surface. It is not advised to place the scale near vibrating machinery;

•Avoid unstable power sources. Do not use near large users of electricity e.g. welding equipment.

2.2.1 Levelling the Scale

Level the scale using the four adjustable feet on the bottom of the scale, Figure 1, and the bubble

level near the base of the column, Figure 2.

Always check the level prior to using scale.

Fig. 1 Adjust scale feet to level the scale

Fig. 2 Adjust feet until bubble is

centered in black circle

AWT35-501876 Issue AD Page 9

2.2.2 Scale Installation

1. Attach the support column to the bracket at the back of the scale base using the three

mounting screws. Use a 3mm hex (Allen) key to tighten the screws. See Figure 3.

Fig. 3 Insert column into bracket and secure with three screws

2. Place the indicator on the top bracket as shown in Figure 4 and slide it down until it snaps into

the final position. Loosen the adjustment knob shown in Figure 4 and adjust the indicator’s

angle for best viewing of the display, then tighten the knob.

Fig. 4 Slide indicator head onto column bracket

3. The cable from the base to the indicator is run through the column and out through the plastic

bracket at the top when you unpack the scale. Make sure the connector is free of

obstructions, i.e. packing foam, and plug the cable into the connector, as shown in Figure 5.

Tighten the threaded collar.

4. Attach the AC power adapter to the connector on the back of the indicator. See Figure 5.

Fig. 5 Signal cable plugged into back of the indicator

AWT35-501876 Issue AD Page 10

2.3. Battery Operation

The ZM 110 can be operated from a 6V 4Ahrs battery located inside the indicator or plugged into an

acceptable power outlet. Battery life is approximately 107 hours with the backlight off.

When the battery needs charging this symbol, , appears in the upper left corner of the weight

display. The scale will still operate for about 10 hours after which it will automatically switch off to

protect the battery.

When the scale is turned on, the battery status is:

-Green LED, the battery is fully charged;

-Red LED, the battery is low and needs to be recharged.

Do not use any other type of power adaptor other than the one supplied with the scale and verify that

the AC power socket outlet is properly protected.

Charge the battery before using (+12hrs).

2.4. Powering ON/OFF the Scale

With the platform connected and the battery fully charged or the charger plugged into the indicator,

press the ON key to power ON the scale. A display test will be performed on power up and the scale

will finish in normal weighing mode. Press the OFF key to turn the scale off.

2.5. Front Panel

The indicator has a sealed keypad and a 6 digits LCD display 0.59” (40mm) high with a white

backlight. Only the active annunciators are shown below.

2.5.1. Display Annunciators

Display reading is stable

Scale at Zero

NET

Indicates a Net weight

GROSS

Indicates a Gross weight

Under acceptable weight range

Within acceptable weight range

Over acceptable weight range

Battery needs to be recharged

kg lb g Pcs

Current unit of measure

Tabla de contenidos

Otros manuales de Escala de Avery Weigh-Tronix

Avery Weigh-Tronix

Avery Weigh-Tronix PC-820 Manual de usuario

Avery Weigh-Tronix

Avery Weigh-Tronix ZP900 Manual de usuario

Avery Weigh-Tronix

Avery Weigh-Tronix RLP Manual de usuario

Avery Weigh-Tronix

Avery Weigh-Tronix ZK840 Manual de usuario

Avery Weigh-Tronix

Avery Weigh-Tronix QC-3265 Manual de usuario

Avery Weigh-Tronix

Avery Weigh-Tronix BridgePort Manual de usuario

Avery Weigh-Tronix

Avery Weigh-Tronix PC-902 Manual de usuario

Avery Weigh-Tronix

Avery Weigh-Tronix TT-830 Manual de usuario

Avery Weigh-Tronix

Avery Weigh-Tronix PC-905 Manual de usuario

Avery Weigh-Tronix

Avery Weigh-Tronix ZK830 Manual de usuario

Avery Weigh-Tronix

Avery Weigh-Tronix TT-830 Manual de usuario

Avery Weigh-Tronix

Avery Weigh-Tronix PC-805 Manual de usuario

Avery Weigh-Tronix

Avery Weigh-Tronix 7820-50 Manual de usuario

Avery Weigh-Tronix

Avery Weigh-Tronix Reflex HP Series Manual de usuario

Avery Weigh-Tronix

Avery Weigh-Tronix HC12000 Manual de usuario

Avery Weigh-Tronix

Avery Weigh-Tronix AWB 120 Manual de usuario

Avery Weigh-Tronix

Avery Weigh-Tronix SCS 131107-20 Manual de usuario

Avery Weigh-Tronix

Avery Weigh-Tronix 3700LP Manual de usuario

Avery Weigh-Tronix

Avery Weigh-Tronix ZQ375 Checkweigher Manual de usuario

Avery Weigh-Tronix

Avery Weigh-Tronix ZP2 Series Manual de usuario

Avery Weigh-Tronix

Avery Weigh-Tronix 7821 Manual de usuario

Avery Weigh-Tronix

Avery Weigh-Tronix Brecknell B240 Manual de usuario

Avery Weigh-Tronix

Avery Weigh-Tronix 1000 Manual de usuario

Avery Weigh-Tronix

Avery Weigh-Tronix G235 Manual de usuario

Manuales populares de Escala de otras marcas

AWS

AWS ZEO-50 Manual de usuario

Gima

Gima Glass Body Fat Analyzer Manual de lista de piezas

Seca

Seca 374 Manual de usuario

TEC

TEC TEC SL59 SERIES Manual de usuario

Axis

Axis B/E Series Manual de usuario

Alecto

Alecto ACW-40 Manual de usuario

Rice Lake

Rice Lake MSI-4260 IS Manual de usuario

IKA

IKA RCT basic safety control Manual de usuario

ADE

ADE M20011 Manual de usuario

Duronic

Duronic KS3000 Manual de usuario

Digi

Digi SM-720 Manual de usuario

Cardinal

Cardinal CS Series Manual de usuario

Korona

Korona Kastella Manual de usuario

A&D

A&D FC-50Ki Manual de usuario

BDA

BDA CAMARGUE Manual de usuario

Tanita

Tanita HD-357 Manual de usuario

Leifheit

Leifheit 03173 Manual de usuario

Lumme

Lumme LU-1340 Manual de usuario
