© 2015 Avenview Inc. All rights reserved.
The contents of this document are provided in connection with Avenview Inc. (“Avenview”) products. Avenview makes no representations or
warranties with respect to the accuracy or completeness of the contents of this publication and reserves the right to make changes to specifications
and product descriptions at any time without notice. No license, whether express, implied, or otherwise, to any intellectual property rights is granted
by this publication. Except as set forth in Avenview Standard Terms and Conditions of Sale, Avenview assumes no liability whatsoever, and claims any
express or implied warranty, relating to its products are is strictly prohibited.
HDMI TO VGA/COMPONENT
CONVERTER
Model #: C-HDM-COMPVGA-A
Rev. 6.15
Military Residential
Medical Aviation
Education Industrial
Corporate House Of Worship
www.avenview.com
Product Application & Market Sectors
Page|2
www.av
enview.com
1.1 IMPORTANT SAFEGUARDS ................................................................................................. 3
1.2 SAFETY INSTRUCTIONS ...................................................................................................... 3
1.3 REGULATORY NOTICES FEDERAL COMMUNICATIONS COMMISSION (FCC) ........... 4
2. INTRODUCTION AND FEATURES..................................................................................... 5
2.1 PACKAGE CONTENTS......................................................................................................... 5
2.2 BEFORE INSTALLATION ...................................................................................................... 6
2.2.1 Installation (C-HDM-COMPVGA-A) ............................................................................. 6
3APPLICATION DIAGRAM ..................................................................................................... 7
2.2.2 Cable Specification ........................................................................................................ 6
SECTION 5: SPECIFICATIONS ....................................................................................................... 10
TABLE OF CONTENTS
3.1 PANEL DESCRIPTION ..............................................................................................................8
3.1.1 FRONT PANEL (C-HDM-COMPVGA-A) ...........................................................................8
3.1.2 REAR PANEL (C-HDM-COMPVGA-A) ................................................................................8
4.GENERAL TROUBLESHOOTING........................................................................................ 9
Page|3
www.avenview.com
SECTION 1: GETTING STARTED
1.1 IMPORTANT SAFEGUARDS
Please read all instructions carefully before you use the device. Save this manual for future reference.
What the warranty does not cover
Any product, on which the serial number has been defaced, modified or removed.
Damage, deterioration or malfunction resulting from:
Accident, misuse, neglect, fire, water, lightning, or other acts of nature, unauthorized product
modification, or failure to follow instructions supplied with the product.
Repair or attempted repair by anyone not authorized by us.
Any damage of the product due to shipment.
Removal or installation of the product.
Causes external to the product, such as electric power fluctuation or failure.
Use of supplies or parts not meeting our specifications.
Normal wear and tear.
Any other causes which does not relate to a product defect.
Removal, installation, and set-up service charges.
1.2 SAFETY INSTRUCTIONS
The C-HDM-COMPVGA-A HDMI to VGA/Component Converter has been tested for conformance to safety
regulations and requirements, and has been certified for international use. However; like all electronic
equipments, the C-HDM-COMPVGA-A should be used with care and precaution. Read the following safety
instructions to protect yourself from possible injury and to minimize the risk of damage to the unit.
Do not dismantle the housing or modify the module.
Dismantling the housing or modifying the module may result in electrical shock or burn.
Refer all servicing to qualified service personnel.
Do not attempt to service this product yourself as opening or removing housing may expose you to
dangerous voltage or other hazards.
Keep the module away from liquids.
Spillage into the housing may result in fire, electrical shock, or equipment damage. Should an object or
liquid falls or spills on to the housing, unplug the module immediately.
Have the module checked by a qualified service engineer before using it again.
Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device before
cleaning.
Page|4
www.avenview.com
1.3 REGULATORY NOTICES FEDERAL COMMUNICATIONS COMMISSION (FCC)
This equipment has been tested and found to comply with Part 15 of the FCC rules. These limits are
designed to provide reasonable protection against harmful interference in a residential installation.
Any changes or modifications made to this equipment may void the users authority to operate this
equipment.
Warning Symbols
Description
ONLY USE THE PROVIDED POWER
CABLE OR POWER ADAPTER SUPPLIED.
DO NOT TAMPER WITH THE
ELECTRICAL PARTS. THIS MAY RESULT IN
ELECTRICAL SHOCK OR BURN.
DO NOT TAMPER WITH THE UNIT. DOING
SO WILL VOID THE WARRANTY AND
CONTINUED USE OF THE PRODUCT.
THE VIDEO BOARDS ARE VERY SENSITIVE
TO STATIC. PLEASE ENSURE IF RACK
MOUNTED OR INSTALLED ON A SURFACE,
IT SHOULD BE IN A GROUNDED
ENVIRONMENT.
Page|5
www.avenview.com
2. INTRODUCTION AND FEATURES
Avenview C-HDM-COMPVGA-A HDMI down converter with digital and analog audio support was designed to
accept a HDMI signal and convert Full HD along with audio to either VGA+SPDIF/LR sink or YPbPr+SPDIF/LR sink
to a monitor or projector.
FEATURES:
- Support video input: HDMI;
- Toggle switch YPbPr/VGA;
- Support audio output: SPDIF (Optical) + R/L analog;
- Support output: Support up to PC UXGA and Video1080I (50/60Hz);
- HDCP compliant;
- LED: Source / Sink working, LED
- No loss of quality;
- DC 5V/1A power supply.
2.1 PACKAGE CONTENTS
Before you start the installation of the converter, please check the package contents.
1 C-HDM-COMPVGA-A
2
3
Power Adapter
User Guide
Page|6
www.avenview.com
2.2 BEFORE INSTALLATION
Put the product in an even and stable location. If the product falls down or drops, it may cause an
injury or malfunction.
Do not place the product in high temperature (over 50°C), low temperature (under 0°C) or
high humidity.
Use the DC power adapter with correct specifications supplied with the unit. If improper
power supply is used the unit may malfunction and cause a fire.
Do not twist or pull by force ends of the video cable. It can cause malfunction.
2.2.2 CABLE SPECIFICATIONS
To achieve best results with our C-HDM-COMPVGA-A we highly recommend a premium quality 26
or 24 AWG HDMI cable with the below specifications to maintain signal integrity and distances.
Length: 5m (16ft) to 15m (50ft)
Bandwidth: 10.2 Gbps data transfer rate
Supports Resolution: Up to 3840x2160 @ 24Hz and 4096x2160 @ 24Hz, 1080p @ 24Hz / 50/60Hz/3D
Conductor gauge: 26 / 24 AWG
Deep Color
3D Capable
CEC
Ethernet Channel
Audio Return Channel
Connector 1: HDMI (Type A) Male
Connector 2: HDMI (Type A) Male
FEATURES:
2.2.1 INSTALLATION (C-HDM-COMPVGA-A )
1. Connect your source device such as digital signage player to HDMI Input on the C-HDM-COMPVGA-A.
2. Connect all displays/screens to VGA/COMPONENT Outputs on the C-HDM-COMPVGA-A.
3. Power up the C-HDM-COMPVGA-A.
4.Switch on all devices connected.
Page|7
www.avenview.com
3.APPLICATION DIAGRAM
Page|8
www.av
enview.com
3.1.1 FRONT PANEL (C-HDM-COMPVGA-A)
3.1 PANEL DESCRIPTION
1.2.
VGA / COMPONENT Switch
3.4.
5.
HDMI Input
6.
Power Supply Connector
3.1.2 REAR PANEL (C-HDM-COMPVGA-A)
7.
VGA Output
Audio Output
Power Indicator
Component Output
8.Optical Output
1
2
345678
4.GENERAl TROuBlESHOOTING
PROBLEM SOLUTION
No Power
- Check the power connector is correctly inserted into the power connector socket.
- Check the power switch ON status.
No Picture
- Make sure the TV is on and is connected to the converter.
- Check if the signal source is on.
- Check power supply connection to the converter.
- Check HDMI cable quality (compliant with the HDMI V1.3).
Picture Not Clear - Check HDMI cable quality (HDMI Cable is compliant with the HDMI V1.3).
Page|9
