Avenview HDM-C6MXIP-SET Manual de usuario
VIDEO WALLS VIDEO PROCESSORS
VIDEO MATRIX SWITCHES
EXTENDERS SPLITTERS WIRELESS
CABLES & ACCESSORIES
Control Your Video
HDMI H.264 IP MATRIX DECODER/ENCODER
OVER CAT/X WITH CEC & AUDIO SUPPORT
© 2015 Avenview Inc. All rights reserved.
The contents of this document are provided in connection with Avenview Inc. (“Avenview”) products. Avenview makes no representations or
warranties with respect to the accuracy or completeness of the contents of this publication and reserves the right to make changes to specifications
and product descriptions at any time without notice. No license, whether express, implied, or otherwise, to any intellectual property rights is granted
by this publication. Except as set forth in Avenview Standard Terms and Conditions of Sale, Avenview assumes no liability whatsoever, and claims any
express or implied warranty, relating to its products are is strictly prohibited.
Model #: HDM-C6MXIP-SET
Military Residential
Medical Aviation
Education Industrial
Corporate House Of Worship
www.avenview.com
Product Application & Market Sectors
www.avenview.com Page
3
TABLE OF CONTENTS
1. GETTING STARTED ..........................................................................................................................1
1.1 IMPORTANT SAFE GUARDS..............................................................................................................1
................................................................................................................1
1.2 SAFETY INSTRUCTIONS
1.3 REGULATORY NOTICES FEDERAL COMMUNICATIONS COMMISIION (FCC) ........................... 2
2. INTRODUCTION ..............................................................................................................................3
.....................................................................................................................4 2.1 PACKAGE CONTENTS
2.2 BEFORE INSTALLATION ................................................................................................................... 4
2.3 APPLICATION DIAGRAM ..................................................................................................................5
2.4 PANEl DESCRIPTION .......................................................................................................................6
2.4.1 FRONT PANEL (SENDER/ENCODER, HDM-C6MXIP-S)
...................................................6
2.4.2 REAR PANEL (SENDER/ENCODER, HDM-C6MXIP-S) ........................................................6
2.4.3 SOURCE SWITCH VALUE .........................................................................................................7
3. INSTALLATION (HDM-C6MXIP-SET) ...............................................................................................9
3.1 APPLICATION ....................................................................................................................................9
3.1.1 SOURCE SELECTION ..............................................................................................................9
3.1.2 IP MATRIX ................................................................................................................................9
4. PC CONFIGURATOR .....................................................................................................................10
4.1 USING MAINTAIN TOOL FOR UPGRADING...........................................................................14
5. SPECIFICATIONS .............................. .............................................................................................18
6. TROUBLESHOOTING ....................................................................................................................20
2.4.2 FROT PANEL (RECEIVER/DECODER, HDM-C6MXIP-R) .....................................................8
2.4.2 FRONT PANEL (RECEIVER/DECODER, HDM-C6MXIP-R) ..................................................8
www.avenview.com Page
1
SECTION 1: GETTING STARTED
1.1 IMPORTANT SAFE GUARDS
Please read all of these instructions carefully before you use the device. Save this manual for future reference.
What the warranty does not cover
•Any product, on which the serial number has been defaced, modified or removed.
•Damage, deterioration or malfunction resulting from:
•Accident, misuse, neglect, fire, water, lightning, or other acts of nature, unauthorized product modification, or failure to
follow instructions supplied with the product.
•Repair or attempted repair by anyone not authorized by us.
•Any damage of the product due to shipment.
•Removal or installation of the product.
•External causes to the product, such as electric power fluctuation or failure.
•u se of supplies or parts not meeting our specifications.
•Normal wear and tear.
•Any other causes which does not relate to a product defect.
•Removal, installation, and set-up service charges.
1.2 SAFETY INSTRUCTIONS
The Avenview HDM-C6MXIP-SET, HDMI H.264 IP Matrix Decoder/Encoder has been tested for conformance to safety regulations
and requirements, and has been certified for international use. However, like all electronic equipments, the HDM-C6MXIP-SET
should be used with care. Read the following safety instructions to protect yourself from possible injury and to minimize the risk of
damage to the unit.
! Do not dismantle the housing or modify the module.
! Dismantling the housing or modifying the module may result in electrical shock or burn.
! Refer all servicing to qualified service personnel.
! Do not attempt to service this product yourself as opening or removing housing may expose you to dangerous voltage
or other hazards
! keep the module away from liquids.
! Spillage into the housing may result in fire, electrical shock, or equipment damage. If an object or liquid falls or spills on
to the housing, unplug the module immediately.
! Have the module checked by a qualified service engineer before using it again.
! Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device before cleaning.
1. GETTING STARTED
www.avenview.com Page
2
1.3 REGULATORY NOTICES FEDERAL COMMUNICATIONS COMMISSION (FCC)
This equipment has been tested and found to comply with part 15 of the f CC rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation.
Any changes or modifications made to this equipment may void the user’s authority to operate this equipment.
Warning symbols Description
ONlY USE THE PROVIDED POWER CABLE OR POWER
ADAPTER SUPPLIED. DO NOT TAMPER WITH THE
ELECTRICAl PARTS. THIS MAY RESULT IN El ECTRICAL
SHOCK OR BURN.
DO NOT TAMPER WITH THE UNIT. DOING SO WIll
VOID THE WARRANTY AND CONTINUED USE OF
THE PRODUCT
THE VIDEO BOARDS ARE VERY SENSITIVE TO STATIC.
PLEASE ENSURE IF RACK MOUNTED OR INSTALLED ON
A SURFACE, IT SHOULD BE IN A GROUNDED
ENVIROMENT.
www.avenview.com Page
3
2. INTRODUCTION
The Avenview HDM-C6MXIP-SET, HDMI H.264 IP Matrix Decoder/Encoder delivers end-to-end streaming media over IP
networks. The HDM-C6MXIP-SET is composed of two units a Decoder and an Encoder. The Decoder H.264/MPEG-4 AVC
video compression format, it receives the encoded IP signal through LAN port and decodes video/audio signal out through
HDMI interface, it also supports stereo de-embeding and streaming resolutions up to 1920 x 1200@60Hz.
Point to Point - (Direct Connection with CAT5/6) - 330ft
Point to Multi - point with CAT5/6 requires a pOE Network Switch which supports port based, IGMp v2.0 or above protocol.
f or large application, we would recommend Dell Networking 5500 series, which use 2 HDMI port or 2 Sfp port to cascade.
Matrix Function – with CAT 5/6 cable without any signal loss add multiple Sources to multiple encoders which links via
lAN by cascading any pOE Gigabit Ethernet switches up to 3 levels, to the decoder connected to the HD Monitors at
different locations on the Network. Transporting full HD 1080p video and internally JpEG video compression adapts to
available network bandwidth if needed while retaining vivid picture with pCM audio.
- NOTE: The QUALITY and TRANSMISSION of the video signals depends on the characteristics and quality of the UTP cables
and Network Infrastructure . We recommend any Network Switches with 10GB POE IGMP v2.0 support . Tested and configured
on the below models
FEATURES:
- Flexible control and management options.
- CEC Function.
- Supports live IP video stream decoding
- Supports POE
- Capable of outputting two IP Streams (allows video previewing)
- Supports multiple interfaces HDMI, DVI, VGA, YPbPr or CVBS signals over IP networks
- Supports audio embedding and de-embedding
- Auto Scaler
- Supports H.264 features baseline profile, main profile and high profile.
- Supports H.264, TCP/IP, Telnet, UDP and IGMP
- Supports Auto IP, Zero-configuration networking (zeroconf)
- Seamless switching, no black screen, no frame lock.
- Configurable encoding bit rate up to 30 Mbps
- Auto input format detection
- HDCP compliant
Other features include:
www.avenview.com Page
4
2.1 PACKAGE CONTENTS
Before you start the installation of the HDMI Extender, please check the package contents.
1HDM-C6MXIP-SET
(HDM-C6XIP-S)
(HDM-C6XIP-R)
X 2
2
Power Brick (+12V DC 1A) + Power Cord X2
Available on Request for International Power
User Guide X 1
2.2 BEFORE INSTALLATION
•put the product in a level and stable location. If the product falls, it may cause damage or malfunction to components
within the casing.
•Do not place the product in temperatures under 0˚C or over 50˚C. High humidity may also cause the unit to malfunction.
•u se the DC power adapter with correct specifications supplied with the unit. If the improper power supply is used, this
may result in malfunction of the unit and may cause fire.
•Do not twist or pull by force the ends of the UTP cable. It will cause malfunction.
1 x Right and Left Ear Rack Sets X4
HDMI to DVI Adapter X 1
Phoenix Connector (Male, 3.5 mm, 3 pins) X 5
3
4
5
6
www.avenview.com Page
5
2.3 APPLICATION DIAGRAM
www.avenview.com Page
6
2.4 PANEL DESCRIPTION
2.4.1 FRONT PANEL (Sender/Encoder, HDM-C6MXIP-S)
1. Power LED: Indicates if unit is ON or OFF
2. Status lED: Light ON indicates unit is communicating properly
2.4.2 REAR PANEL (Sender/Encoder, HDM-C6MXIP-S)
3.
HDMI IN: Connect to HDMI/DVI Source.
4.
5.Stereo Audio OUT: Connects to an audio output
device such as an amplifier for audio de-embedding.
6.
LAN: Used for media streaming linking to Decoder
7.
RS 232: RS 232 Unit Control Port.
8.
1 2
45678
3
Power Jack: DC 12V
Ground Screw: Ground connection prevent device
damage.
www.avenview.com Page 7
PANEL DESCRIPTION
0 Indicates this source switch is up.
1 Indicates this source switch is down.
Source Switch Positions
Note:
S1, S2 and S3 are source switches 1~3 respectively.
0 0 0 Indicates DVI source input is selected, which is
required when connecting to a DVI video source.
0 0 1
Indicates HDMI source input is selected, which is
required when connecting to an HDMI video
source.
0 1 0 Indicates VGA source input is selected, which is
required when connecting to a VGA video source.
0 1 1 Indicates YPbPr source input is selected, which is
required when connecting to a YPbPr video source.
1 0 0 Indicates CVBS source input is selected, which is
required when connecting to a CVBS video source.
x x x
The other switch values are reserved. If they are
selected, DVI source input is used as the video
source.
Note:
By default, the source switch position is 000.
2.4.3 Source Switch Value
DescriptionSource Switch
Value
S1 S2 S3 Description
