Autonics TM Series Manual de usuario

User Manual

Preface

Thank you for purchasing an Autonics product.

Please familiarize yourself with the information contained in the Safety Precautions

section before using this product.

This user manual contains information about the product and its proper use, and should

be kept in a place where it will be easy to access.

User Manual Guide

iv © Copyright Reserved Autonics Co., Ltd.

User Manual Guide

This user manual contains information about the product and its proper use.

It should be kept in a place where it will be easy to access.

Please familiarize yourself with the information in this manual before using the product.

This manual provides detailed information on the product's features. It does not offer

any guarantee concerning matters beyond the scope of this manual.

This manual may not be edited or reproduced in either part or whole without

permission.

A user manual is not provided as part of the product package.

Please visit www.autonics.com to download a copy.

The manual's content may vary depending on changes to the product's software and

other unforeseen developments within Autonics; therefore, the content of this manual

is subject to change without prior notice.

User Manual Symbols

Symbol Description

Supplementary information for a particular feature.

Failure to follow instructions can result in serious injury or death.

Failure to follow instructions can lead to a minor injury or product

damage.

An example of the concerned feature's use.

※1 Annotation mark.

Safety Precautions

vi © Copyright Reserved Autonics Co., Ltd.

Safety Precautions

Please follow safety precautions to ensure the safe and proper use of the product and

prevent accidents, as well as minimizing possible hazards.

Safety precautions are categorized as Warnings and Cautions, as defined below:

Warning Cases that may cause serious injury or fatal accident if

instructions are not followed.

Caution Cases that may cause minor injury or product damage if

instructions are not followed.

In case of using this unit with machinery (Ex: nuclear power control, medical

equipment, ship, vehicle, train, airplane, combustion apparatus, safety device,

crime/disaster prevention equipment, etc) which may cause damages to human life or

property, it is required to install fail-safe device.

It may cause a fire, human injury or damage to property.

Always install the unit on a panel.

It may cause an electric shock if not followed.

Never wire, repair, or inspect the unit while electricity is flowing through it.

It may cause an electric shock if not followed.

Check the input power specifications and terminal polarity before connecting the

wires.

It may cause a fire if not followed.

Only Autonics technicians are authorized to service or modify the product.

It may cause an electric shock or fire if not followed.

Do not use outdoors.

It may shorten the life of the product and/or cause an electric shock if not followed.

Always use AWG 20 (0.5 mm2) or higher when wiring to the relay's output terminals.

It may pose a fire risk if not followed.

Always use within the range of rated specifications and performance.

Safety Precautions

It may shorten the lifespan of the product and/or pose a fire risk if not followed.

Do not allow loads in excess of the rated switching capacity on relays.

It may damage the insulation, relays and/or cause a fire or faulty connection if not

followed.

Do not use water or an oil-based solvent to clean the product. Use a dry towel instead.

It may pose an electric shock or fire risk if not followed.

Do not use the product in a place where it is exposed to flammable or explosive

gases, humidity, direct light, radiant heat, vibration, or impact.

It may pose a fire or an explosion risk if not followed.

Do not allow dust or wiring fragments to get inside the product.

It may pose a fire or a malfunction risk if not followed.

Check the terminal's polarity first to properly wire the temperature sensor.

It may pose a fire or an explosion risk if not followed.

Handling Precautions

viii © Copyright Reserved Autonics Co., Ltd.

Handling Precautions

These handling precautions address issues that can potentially cause the product to

malfunction.

Power and Usage Environment

Use the rated power only.

Maintain the controller's ambient temperature between -10℃ and 50℃.

Turn the power on and allow the temperature controller to warm-up for twenty

minutes before use.

A power switch or a circuit-breaker is necessary to supply and cut off power to the

product.

Install the switch or circuit-breaker in the vicinity of the product to facilitate easy

access.

Use the product in a well-ventilated environment. Otherwise, arrange for ventilation if

necessary.

Recommended usage conditions are as follows:

Indoors

Below 2,000 m altitude

Pollution Degree 2

Installation Category II

Sensor Input

If using in an environment where the margin of sensor error cannot be avoided, use

the Input Bias feature to minimize the error margin.

If using a thermocouple sensor, make sure to use prescribed compensation wire as

extension wire. Failure to do so will produce temperature distortion at the junction

between the thermocouple and the extension wire.

If using a resistance temperature detector (RTD) sensor, always make connection

with three-wire configuration. In addition, only use three wires of identical material,

thickness and length if you need to extend the line. Variance in wire resistance will

lead to temperature distortion.

Handling Precautions

When changing an input sensor, first disconnect power to the product and then

connect the new sensor. Restore power to the product and update the related

parameters either directly from the product or using the PC loader program.

Always use a line filter on the controller's power line. Also, use shielded wire for the

input signal line, provided it is necessary for the power line and the input signal line

must remain close to one another.

Noise Effect

Isolate the product's wiring from high-voltage lines and power lines to prevent impulse

noise.

Avoid using the product in the vicinity of high-frequency noise generating devices,

such as: welding machines, sewing machines, high-capacity SCR controllers, and

high-capacity motors.

Avoid using the product in the vicinity of radio, television, and wireless devices that

may cause high-frequency interference.

Communication

Only use twisted pair wires for the communication lines. Attach round ferrules at the

ends of the lines to reduce the impact of external noise.

Do not have the communication lines in close proximity of the AC power line.

If possible, use a separate power source (24 VDC) for the communication converter

(SCM-38I, sold separately).

Handling Precautions
