TR2650A
2022-02-7 © Automotive Data Solutions Inc. 1/21
OWNER’S MANUAL
TERMS OF USE
INSTALLER TERMS OF USE
Automotive Data Solutions Inc. (“ADS”) products are strictly intended for installation by Certified Technicians
who are employed by a registered business specialized in the installation of automotive aftermarket electronics
products. Prior to beginning installation of an ADS product in a vehicle, it is the Certified Technician’s
responsibility to review the most current Product Guide, Install Guide and vehicle-specific notes available in
Weblink®. ADS is not responsible for any damages whatsoever, including but not limited to any consequential
damages, incidental damages, damages for loss of time, loss of earnings, loss of profit, commercial loss, loss of
economic opportunity and the like that may or may not have resulted from the use, misuse, improper
installation or operation of its products. Purchasers sole contractual remedy is refund of the purchase price of
the ADS product(s). ADS reserves itself the right to suspend any Weblink® account without notice and decline
to offer technical support to non-Certified Technicians, non-compliant Certified Technicians or end users.
END USER TERMS OF USE
ADS products are designed to remote start vehicles from a distance. In order to ensure your iDatastart system
meets all safety regulations and operates as intended by the manufacturer, please follow the usage
recommendations below:
• DO NOT use this product for any purpose other than its intended usage.
• DO NOT remote start a vehicle in an indoor or enclosed area (i.e. garage). Exhaust fumes are extremely
dangerous and can cause personal injury or death. Install carbon monoxide detectors in every living area that
can be exposed to vehicle exhaust fumes.
• DO NOT remote start a vehicle while it is being serviced. Follow the Valet Mode procedure as outlined in your
Owner’s Manual.
• DO NOT remote start a vehicle in gear.
• DO NOT remote start a vehicle with the key in the ignition.
• DO NOT remote start a vehicle left unattended with open windows, unlocked doors or open convertible top.
• DO NOT allow children handle or operate long range remotes.
• ALWAYS engage your emergency brake prior to exiting your vehicle. This may limit motion if the vehicle is
accidentally started in gear.
• AVOID remote starting your vehicle while passengers or pets are on board. This may increase the risk of
TR2650A
2022-02-7 © Automotive Data Solutions Inc. 2/21
shifter being put in gear after vehicle has been remote started.
• AVOID parking your vehicle on an inclined surface or an area surrounded by obstacles. For manual vehicles,
ALWAYS ensure the Reservation Mode sequence, as outlined in your Owner’s Manual, is correctly engaged prior
to the next remote start.
• AVOID delaying the inspection of your iDatastart system in the event of malfunction. Immediately contact a
Certified Technician to ensure that installation or defective equipment is properly addressed.
REMOTE OVERVIEW
Your iDatastart remote start system may include one or both long-range remotes listed below.
Please take a moment to familiarize yourself with their general features.
REMOTE MODEL TR2650A
Technology LORA 2-WAY
Max. Range 1 mile
Buttons 5
Transmit Confirmation (TX) Chime
Receive Confirmation (RX) LCD icon + Chime + Vibration
Batteries Required 1 x CR2450
Avg. Battery Life 8-15 months
Warranty 1 year
TR2650A
2022-02-7 © Automotive Data Solutions Inc. 3/21
Your iDatastart TR2650A LCD remote can display several icons following a command (button press) or
command notification. Please take a moment to familiarize yourself with their descriptions below:
TR2650A
2022-02-7 © Automotive Data Solutions Inc. 4/21
ICON DESCRIPTION
Lock
Unlock
Alarm Armed
Engine Key Started / Remote Started
Ignition On
Shock Sensor Disabled
Shock Sensor Triggered
Shock Sensor Warn Away
Valet Mode
Turbo Mode
Vibration Mode
Mute Mode
Battery Level
Time or Engine Runtime, or Temperature or Error Codes or Other
Door Open
Trunk Open
Hood Open
Transmitting
Timer Alarm
AUX 2
AUX 3
AUX 4
Parking Light / Car Finder
Car Call
Time Start
Shift
Keypad Lock
Pit Stop
Save
REMOTE COMMANDS & CONFIRMATIONS
In order to get the most out of your iDatastart remote, please take a moment to get acquainted with the
following commands and confirmations below:
NOTES:
1. All functions must be enabled by an Authorized Dealer during installation to be functional on remote
TR2650A
2022-02-7 © Automotive Data Solutions Inc. 5/21
2. Non-highlighted icons = Press & release button
3. Highlighted (grey) icons = Press & hold button for 2.5 seconds
4. Coma (,) between icons = Press buttons one after the other
5. Plus (+) between icons = Press buttons together
6. Timeout between each button press = 3 seconds
7. Function* = Available in 2nd Car Mode
8. 3 chirps following a remote command = Option not available. Contact your Authorized Dealer.
COMMAND Power ON Remote
BUTTON
DESCRIPTION Turns remote on.
COMMAND Power OFF Remote
BUTTON
DESCRIPTION Turns remote off to save battery life.
COMMAND Lock & Arm
BUTTON
DESCRIPTION Secures your vehicle by locking the doors and arming
the alarm.
CONFIRMATION • 1 chirp, display and
COMMAND Unlock & Disarm
BUTTON
DESCRIPTION Accesses your vehicle by unlocking the doors and disarming the alarm.
CONFIRMATION • 2 chirps, display and
TR2650A
2022-02-7 © Automotive Data Solutions Inc. 6/21
COMMAND Query*
BUTTON
DESCRIPTION Queries vehicle and vehicle battery voltage and
interior temperature.
CONFIRMATION
• Query voltage: 1 chirp, display voltage ex:
for 3 seconds.
• Query temperature: 1chirp, display temperature ex:
for 3 seconds.
• Query shut down error: 3 chirps, display error ex:
for 3 seconds.
COMMAND Panic*
BUTTON
DESCRIPTION Triggers the panic siren.
CONFIRMATION • 1 chirp, and flash 5 times.
COMMAND AUX 5*
BUTTON
DESCRIPTION To be completed by Authorized Dealer if applicable
CONFIRMATION • 1 chirp, display
COMMAND Trunk Release*
BUTTON
DESCRIPTION Releases the trunk or hatch.
CONFIRMATION • 1 chirp, display
TR2650A
2022-02-7 © Automotive Data Solutions Inc. 7/21
COMMAND Engine Start/Stop*
BUTTON
DESCRIPTION Starts and stops the engine.
CONFIRMATION
• Engine start: 1 chirp.
• Engine run: 4 chirps, display and remaining
runtime.
• Start error: 1 long chirp, display start error ex:
+ for 3 seconds.
• Engine stop: 2 chirps.
COMMAND AUX 1
BUTTON
DESCRIPTION To be completed by Authorized Dealer if applicable
CONFIRMATION • 1 chirp, display
COMMAND AUX 2
BUTTON
DESCRIPTION To be completed by Authorized Dealer if applicable
CONFIRMATION • 1 chirp, display
COMMAND AUX 3
BUTTON
DESCRIPTION To be completed by Authorized Dealer if applicable
CONFIRMATION • 1 chirp, display
TR2650A
2022-02-7 © Automotive Data Solutions Inc. 8/21
COMMAND AUX 4
BUTTON
DESCRIPTION To be completed by Authorized Dealer if applicable
CONFIRMATION • 1 chirp, display
COMMAND 2nd Car Mode
BUTTON *
DESCRIPTION
Controls two iDatastart-equipped vehicles using one
remote. Works with all functions marked with an
asterisk (*).
CONFIRMATION • Same as 1st car.
COMMAND Silent Lock*
BUTTON
DESCRIPTION Disables the vehicle’s horn and alarm siren.
CONFIRMATION • 1 chirp, display and
COMMAND Silent Unlock*
BUTTON
DESCRIPTION Disables the vehicle’s horn and alarm siren.
CONFIRMATION • 2 chirps, display and
TR2650A
2022-02-7 © Automotive Data Solutions Inc. 9/21
COMMAND Valet Mode ON/OFF
BUTTON
DESCRIPTION
Turns off remote start and security features when
servicing your vehicle or valet parking. Keyless entry
features remains functional.
CONFIRMATION • ON: 1 chirp, display
• OFF: 2 chirps, disappears.
COMMAND Runtime Extend
BUTTON
DESCRIPTION Seamlessly extends your engine runtime without
restarting your vehicle.
CONFIRMATION • 4 chirps, display runtime minutes ex:
COMMAND Mute ON/OFF
BUTTON
DESCRIPTION
Disables the vehicle’s horn and alarm siren even
when alarm is triggered. Remote will still receive
alarm notification.
CONFIRMATION
• ON: 1 chirp.
• OFF: 2 chirps, display
COMMAND Ignition Lock ON/OFF
BUTTON
DESCRIPTION Automatically locks doors when engine is running.
CONFIRMATION • ON: 1 chirp, display for 3 seconds.
• OFF: 2 chirps, display for 3 seconds.
TR2650A
2022-02-7 © Automotive Data Solutions Inc. 10/21
COMMAND Passive Lock & Arm ON/OFF
BUTTON
DESCRIPTION Automatically locks and arms your vehicle 60 seconds
after you unlock it.
CONFIRMATION • ON: 1 chirp, display for 3 seconds.
• OFF: 2 chirps, display for 3 seconds.
COMMAND Turbo ON/OFF
BUTTON
DESCRIPTION Cools down your turbo before turning the engine off.
Programmable runtime from 30 seconds to 4 minutes.
CONFIRMATION • ON: 1 chirp, display
• OFF: 2 chirps, disappears.
COMMAND Weather Start ON/OFF
BUTTON
DESCRIPTION
Sets your vehicle to automatically remote start every
2, 3 or 4 hours (programmable) or from a temperature
sensor sold separately.
CONFIRMATION • ON: 1 chirp, display
• OFF: 2 chirps, disappears.
