AUTODA AD2016SC3 Manual de usuario
AD2016SC3 hand-held push tension meter
Operating instruction
Suzhou Autoda automation equipment co. LTD
Suzhou Autoda automation equipment co. LTD
- 1 -
Contents
Specifications and Parameters……………………………………………… 2
Appearance and Dimensions ……………………………………………… 4
Precautions ………………………………………………………………… 6
Functions …………………………………………………………………… 7
Main Features ……………………………………………………………… 7
Parts & Buttons and Their Functions ……………………………………… 8
Interfaces and Their Functions………………………………………………11
Software ……………………………………………………………………18
Maintenance and After-Sales Service ………………………………………23
Battery Use and Maintenance ………………………………………………23
Packing List …………………………………………………………………24
Suzhou Autoda automation equipment co. LTD
- 2 -
SpecificationsandParameters
SC3-100000
1000N
0.5N
士0.2%FS 士1Digit
1%~100% f.s. (1KN, Measuring range 1%~75%f.s.)
±0.5%F.S
N、kg、lb
LCD
20±10℃
15%~80%RH
No vibration sources or corrosive materials exist.
1kg
SC3-500
500N
0.1N
SC3-200
200N
0.1N
SC3-100
100N
0.05N
SC3-50
50N
0.01N
SC3-20
20N
0.01N
SC3-10
10N
0.005N
Model
Range
Calibration
Accuracy
Measuring Range
Indication Error
Units
Display
Working
Temperature
Relative
Humidity
Working
Conditions
Weight
Suzhou Autoda automation equipment co. LTD
- 3 -
Appearance and Dimensions
尺寸图单位为 mm
Output Port Wiring
Suzhou Autoda automation equipment co. LTD
- 4 -
Precautions
Disoperation may cause damage to the force
gauge and even result in serious accidents.
This manual describes precautions against
accidents and operation methods of this
product. Make sure to read this manual carefully and safe keep it after the
reading. For impact test, select a force gauge whose maximum measurable value
is doubled the impact load to be applied. Effective measuring range of this
product is 10% ~ 75%.
1、Before the impact test, wear
mask and gloves; avoiding
personal injury in case of
object splash.
2、Do not use damaged or bent fixture; avoiding personal injury in case of
fixture fall or break.
3、If “Err-1” appears on the LCD display, it indicates that the test load the
sensor measures is 110% larger than the rated load. Decrease the load
immediately. Make sure the load applied is smaller than 105% the rated
load after the force gauge is restarted.
4、Make sure the force gauge is not overloaded. Overload, excessive impact
force, and forces other than pull force and push force may damage the
sensor.
5、Do not use sharp tools to press buttons.
6、Avoid the force gauge from water, oil, and other liquids. Put it in a cool, dry,
and vibration-free place.
7、Use the charger delivered with the force gauge for charging; otherwise,
circuit failure even fire may be caused.
Notes
Warning
Suzhou Autoda automation equipment co. LTD
- 5 -
8、Follow this document to wire ports; otherwise, circuit failure even PC fault
may be caused.
9、Make sure the AC charger is securely inserted into a socket if the product
needs to be charged. Looseness may cause short circuit, resulting in electric
shock or fire.
10、Remove the power adapter after the charging; avoiding accidents.
11、Do not touch the power adapter with wet hands; otherwise, electric shock
may occur.
12、This product is for measuring pull and push forces only. Do not bend or
twist the test head. See the following figure for correct operation method.
Functions
AD2016SC3 series digital force gauges are new-generation universal
portable instruments for testing pull and push forces. They are characterized by
compactness, lightness, portability, versatility, high precision, applicable to pull
& push test, insertion & extraction test, and impact test of various products.
They can be also designed into small-sized test machines for various purposes
when they are combined with different test benches and fixtures.
Main Features
1、LCD double digital display with backlight;
2、USB interface; hot swappable.
3、Free setting of fracture alarm value, and upper/lower offset; selection of
fracture alarm, alarm for not excess of limit, and alarm for excess of limit.
When alarm values are exceeded, the buzzer acts while the display shows
Suzhou Autoda automation equipment co. LTD
- 6 -
alarm information. The two SC open-collector level outputs drive the DC
12V relay or the solenoid to act, each output being 50mA. To use output
ports, connect the power adapter first.
4、Display can be rotated 180°.
5、Enable automatic unit conversion: N, kgf, and lbf.
6、Peaks can be held or cleared; clearing time can be set.
7、A maximum of 10 groups of test reports can be saved permanently. The
saved content includes peak, and average valley.
8、Shutdown and backlight can be set to perform automatically.
9、Relying on the PC dedicated test software, the force gauge can realize
unlimited storage, transmission, and reproduction of test curve data.
10、Installed on different test benches, the force gauge can implement various
tests.
Suzhou Autoda automation equipment co. LTD
- 7 -
Parts & Buttons and Their Functions (for Embedded Products)
Suzhou Autoda automation equipment co. LTD
- 8 -
Interfaces and Their Functions
一、Test Interface：
1. Number of Peak saved；
2. The values Meaning of the Peak window shows：
a) PEAK：Manual Peak Clear；
b) PEAK ATUO：Automatic peak Clear；
c) PEAK AVER：Average peak of the Saved peak data group；
d) PEAK MAX：maximum peak of the Saved peak data group；
e) PEAK MIN：minimum peak of the Saved peak data group；
3. Display the peak value hold and real time value；
4. Battery icon；
5. The online with computer software symbol；
6. Measuring unit；
7. Push(compression) sign；
Suzhou Autoda automation equipment co. LTD
- 9 -
8. Pull(tension) sign；
9. Alarm indicator：
a) “—”the display value is less than the lower force limit；
b) “○”Be tested or Fracture, end the test；
c) “＋”the display value is greater than the upper force limit；
二、Buttons and Their Functions
Button
Standalone
Test Mode
Online
Test
Mode
Storage &
Query Mode
Menu Operation
Mode
Shutdown
Shutdown
Invalid
Invalid
Unit
conversion
Invalid
Exit
Quit parameter
modification or
exit
Zero set
Zero set
Clear peak
value of
flashing number
Data cleared
Test output
Invalid
output peak
value test report
Up
Enter storage
& query
mode
Invalid
Switch to upper
window
Down
Enter
parameter
setting mode
Invalid
Invalid
Confirm
parameter
modification
