210A GPS TRACKING
INSTALLATION GUIDE
210A GPS TRACKING
INSTALLATION GUIDE
© Directed Electronics—Vista, CA
INS210A 07-05

The GPS 210 Series Installation Manual is the exclusive property or Directed
Inc. or its content suppliers and is protected by Canadian and international
copyright, trademark and intellectual property laws. You may not modify, copy,
reproduce, republish, post, transmit or distribute in any way material from this
document without the prior permission of Directed Inc.
For the purpose of this document, reference to GPS 210 Series shall mean and
include Directed Inc., including its subsidiaries and affiliates. Directed and GPS
210 Series are trademarks of Directed Inc.
Responsibility
Directed assumes no responsibility or liability for the improper installation, oper-
ation or maintenance of GPS 210 Series Onboard, including, without limitation,
the installation or removal thereof by personnel who have not successfully com-
pleted the GPS 210 Series Installation Training and Certification program.
2© 2005 Directed Electronics—all rights reserved

Table of Contents
Responsibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
General Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Vehicles Equipped with AirBags . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Damage to equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Basic Tools Needed for Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Stealth Antenna Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
The GPS 210 Series Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Connecting the Power Harness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Feature Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Wiring Color Coding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Connecting the Starter Disable Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Connecting the Door Unlock Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Connecting the Alarm Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Powering the GPS 210 Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
GPS 210 Series Installation Testing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Starting the GPS 210 Series Application on the Palm210 . . . . . . . . . . .17
Record Vehicle VIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
210 Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Installation Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Ignition Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Door Unlock Test (if option available) . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Starter Disable Test (if option available) . . . . . . . . . . . . . . . . . . . . . . . . .20
Alarm Test (if option available) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Communications Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
© 2005 Directed Electronics—all rights reserved 3

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Transmission Unsuccessful message on Palm210: . . . . . . . . . . . . . . . .23
No GPS Fix message on Palm210: . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
No Wireless Network message on Palm210: . . . . . . . . . . . . . . . . . . . . .26
Test Incomplete message on Palm210: . . . . . . . . . . . . . . . . . . . . . . . . .27
Vehicle engine shuts off when “Disabled”: . . . . . . . . . . . . . . . . . . . . . . .27
Starter Disable relay buzzes or chatters: . . . . . . . . . . . . . . . . . . . . . . . .27
Vehicle engine will not start: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
VIN Messages: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
LED Operation: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Wireless Coverage Area: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Wireless Network Service Problem: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
GPS Drift, Urban Canyon: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Tampering with the Unit - Human Intervention: . . . . . . . . . . . . . . . . . . . . . . .32
Defective Units: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
4© 2005 Directed Electronics—all rights reserved

Introduction
Satellites are in a 12-hour orbit at 12,000 miles above the earth. There are 24
satellites in the system and generally there are at least 5 satellites orbiting
overhead at any one time. The GPS 210 Series relies on the signal from mul-
tiple satellites to determine its location on earth. The satellite signal is received
via the combination GPS / Cellular antenna supplied with the GPS 210 Series.
This antenna must be installed in a location with an unobstructed view to the
outside of the vehicle to receive signals from these satellites. This network cov-
ers virtually the entire population of U.S, Canada,and Mexico that is within
reach of a cellular network.
General Safety
This installation manual covers the installation of the GPS 210 Series. This
manual is for the professional and novice installer and should be used to
ensure a safe and functional install of the GPS 210 Series. The following infor-
mation should be noted with respect to operating the GPS 210 Series in vari-
ous environments, since the cellular transceiver component works through RF
(Radio Frequency).
Vehicles Equipped with AirBags
• DO NOT place objects, including communication equipment, in the area
over the airbag or in the air bag deployment area.
• If the communications equipment is improperly installed and the airbag
inflates, this could cause serious injury.
• Contact the vehicle manufacturer's corporate headquarters, if necessary,
for specific airbag information for the vehicle.
• DO NOT run cables under the area reserved for the driver’s feet.
© 2005 Directed Electronics—all rights reserved 5

Damage to equipment
• DO NOT install components that have been dropped, even if they appear
to be functional.
• Internal damage is likely to occur.
Basic Tools Needed for Installation
• Metric and standard socket set
• Screwdriver set
• Side cutters, wire cutters
• Knife or box cutter
• Wire strippers
• Hand Crimper for insulated terminals
• Pliers
• Electrical tape
• Automotive upholstery or trim remover
• Flashlight or trouble light
• Cordless drill with accessories
• Assorted common bit set
• Palm210 with Palm LS210 Serial Cable
• Digital Multimeter (recommended), or 12 volt test light
It is strongly recommended that a Digital Multimeter be used when probing
electrical systems in the vehicle to avoid any damage to computers or airbag
systems.
6© 2005 Directed Electronics—all rights reserved

Antenna
Antenna location is critical to the operation of the system. The antenna provid-
ed is a combined GPS/RF antenna. The GPS/RF combined antenna must be
mounted flat with the GPS receiver facing up (square portion on antenna). The
antenna does not require a ground plane to function properly.
Stealth Antenna Mounting
The best location for a stealth installation is beneath the rear speaker deck
panel or below the front window concealed in the dash of the vehicle. The
GPS/RF combination antenna will work best if it has a clear view to the sky and
as much of the horizon as possible. Any metallic objects between the antenna
and the satellites will degrade the signal and reduce the overall performance.
© 2005 Directed Electronics—all rights reserved 7

• The GPS signals will travel through the clear glass but will be reduced if
the window has any metallic coating or tint applied.
• The antenna must be mounted securely so that it does not become a pro-
jectile in an accident or move during normal operation.
The GPS 210 Series Device
The GPS 210 Series may be installed in any type of 12-volt vehicle. The unit
should be mounted so it will not be exposed to damage from people or objects.
The GPS 210 Series has four mounting holes. Use nylon tie straps to firmly
mount the GPS 210 Series. Some examples of mounting locations include
under the dash above the knee bolster, under the centre console, side kick
panel and behind the glove compartment. The backup battery should be
mounted in the same manner, close to the GPS 210 Series.
8© 2005 Directed Electronics—all rights reserved

Connecting the Power Harness
Main Harness
Orange 12 Volts Constant
Green 12 Volts Constant
Blue 12 Volts Ignition
Black (X2) Ground
Green/Yellow Test (not used)
The following wires require connection to the vehicle wiring harness.
• Constant Power Wires (orange and green) +12VDC when the key is
removed from the ignition.
Note: There are two fuses inline.
• 5 amp fuse for constant power
© 2005 Directed Electronics—all rights reserved 9

• Ignition Sense Wire (Blue) +12VDC when the key is in the “Run/On” posi-
tion only.
• Ground Wire (Black) to a metal surface on the vehicle frame or kick panel.
• A good ground connection must be established for the GPS 210 Series to
operate properly. Resistance to ground is the main cause of failure.
• Ensure the location you choose for your ground connection is made of
metal, not plastic.
• Scrape away any paint on the vehicle ground to make a clean mounting
surface.
Feature Module
The GPS 210 Series uses a feature module to control external features such
as:
• Starter Disable, Door Unlock, and Alarm trigger notification.
BLUE
