Aurora AU405MA Manual de usuario
AU405MA
Model No. Please read these operating instructions before using the unit.
Shredder User Manual
1-800-327-8508
USA Only
1-310-793-5650
International
Email: [email protected]
For more information, please visit us at:
www.auroracorp.com
3ENGLISH
WARNING:SAFETY INSTRUCTIONS, READ BEFORE USING!
DO NOT SHREDS:
Note: Do not open lid once shred cycle has started CONTINUED NEXT PAGE
u
n
o
p
e
n
e
d
m
a
i
l
/
e
n
v
e
l
o
p
e
s
>
1
/
4
”
(
6
m
m
)
h
e
a
v
y
d
u
t
y
s
t
a
p
l
e
s
l
a
m
i
n
a
t
e
d
s
h
e
e
t
s
/
m
a
g
a
z
i
n
e
s
Keep away from moving parts.
Read instructions before use.
Avoid touching the document
feed opening with hands.
Product is not intended for use by
children (product is not a toy).
Do not insert foreign objects into
the paper entry slot.
Do not spray or keep any
aerosol products in or around the
shredder.
Keep loose clothing or jewelry
away from the paper entry slot.
Avoid getting hair near the
paper entry slot.
Sharp blade edges!
Do not touch!
4ENGLISH
WARNING:SAFETY INSTRUCTIONS, READ BEFORE USING!
•AlwaysturntheshredderoffandunplugthepowercordfromtheACoutletwhen
notinuse,beforecleaning,moving,oremptyingthewastebasket.
•RISKOFFIRE.Neveruseanypetroleumbasedorflammableoilsorlubricantsin or
around the machine as some oils can combust causing serious injury.
•NEVER dispose of flammable chemicals or materials that have come into contact with flammable
chemicals (for example, nail polish, acetone and gasoline) in the shredder basket.
•Nevershredmetalcreditcards,largepaperclips,windoworinsulatedenvelopes,
continuousforms,newsprint,boundpages(forexample:notepads,checkbooks,
magazines,etc...),transparencies,laminateddocuments,cardboard,anyitemswith
adhesives,hardmaterialsorplastic(exceptplasticCreditCardsandCDs).
•DonotholdCD/DVDwithfingerthroughthecenterringwhilefeedingintothe
shredder.Seriousinjurymayoccur.
•A socket-outlet should be near the equipment and be easily accessible.
•Never let the wastebasket become full. This will lead to shredded material being pulled back up into
the shredder and cause jams.
•Never place the shredder near water or any heat source.
•Do not use the shredder if the power cord is damaged in any way.
•Do not attempt to service this product yourself as doing so may expose you to sharp cutting blades
and/or electricity and will void the manufacturer's warranty.
•Never try to clean or clear the shredder blade.
•Never shred beyond the specified sheet capacity. This may result in extensive damage to the machine.
5ENGLISH
1. Make sure basket door is shut and securely closed. The safety power cut off will not operate if
door is open. Shredders with pull-out wastebaskets will also cut power upon bin removal. The sup-
plied wastebasket activates a safety switch, which allows the shredder to be operable.
(FIGURE 1).
2. The socket-outlet should be near the equipment and easily accessed.
3. Connect the power cord to any standard 120-V AC outlet.
Micro-cut shredders have very sharp exposed
blades on the underside.
PaperShredderOperatingInstructions
• Warning • Installation • Operation • Maintenance • Troubleshooting
*ManualFeed:
• Shreds credit cards, CDs/DVDs, small paper clips, staples
• One folded sheet of paper equates to 2 sheets of paper
• Heavier paper, humidity or electrical voltage other than the rated voltage may reduce shredding capacity
Sheet Capacity
Paper Shred Size
Paper Tray Size:
Paper Entry Width
Duty Cycle
Voltage
400 Sheets of 20 lb. letter size bond paper
5/64 in. x 15/32 in. pieces
(2.0 mm x 12 mm pieces)
Letter size- 8.5” x 11”
9.45 in / 240 mm
240 min. on / 45 min. off
120-V~60Hz / 4.0 A
10 Sheets of 20 lb. bond paper*
5/64 in. x 15/32 in. pieces
(2.0 mm x 12 mm pieces)
N/A
9.45 in / 240 mm
30 min. on / 45 min. off
120-V~60Hz / 4.0 A
AutoFeedTray: ManualFeedSlot:
INSTALLATION
!Caution:
FIGURE1
6ENGLISH
Casters
ControlPanel
TopLidSecurityLock
Manual-FeedSlot
TopLidButton
MainPowerSwitch (at back of machine)
The Main Power Switch must be “ON” to operate. In an emergency,
stop the shredder immediately and turn switch to “OFF” mode. This
completely disconnects all power to the machine.
ControlPanel:
•Auto-On(blue):
This setting automatically starts the shredder by loading paper into the paper tray or
inserting paper into the manual-feed slot. When the paper has passed through, the
shredder automatically stops.
ONOFF
–O
CONTINUED NEXT PAGE
OPERATION
PulloutBin
MainPowerOn/OffSwitch
(atbackofmachine)
7ENGLISH
OPERATION
•Off:
This setting turns off all features of the shredder. For safety reasons, we recommend that
you leave shredder in the OFF position when it is unattended or not in use.
•Reverse:
In the unlikely event of a paper jam, use the reverse setting to help clear the cutters of
paper that did not pass through. IMPORTANT: Never attempt to clear a jam using the
reverse function until you have emptied the wastebasket.
•Forward:
The forward setting can also be used to help clear the cutters in the event of a paper
jam. This allows you to manually activate the shredder into cutting mode.
LEDStatusIndicators:
•Overheat:
Red LED light indicates the shredder has shredded continuously beyond the maximum
running time, has overheated, and will automatically shut off. If this happens, switch the
shredder to Off for 45 minutes or longer before resuming normal operation.
•Overload:
Red LED light indicates when too much paper is inserted. Use the "Reverse" mode to
back up and reduce number of sheets.
•DoorOpen:
Red LED light indicates the shredder basket or top lid is not closed properly. Shredders
with pullout wastebaskets feature a safety power cut off upon bin removal. Make sure
the pull-out wastebasket is properly set back into place and the blue “Power On” indica-
tor is lit.
•BinFull:
When basket is full, RED light will indicate it needs to be emptied. While lit, the shred-
der will not operate until the wastebasket is cleared.
•FeedError:
RED light indicates paper in the paper tray cannot be grabbed by the feeders, Open
lid to make sure papers are unfolded and positioned properly.
TopLidSecurityLock:
•Tolockthetoplid: Enter any 4-digit code during shredding
•Toopenthetoplid:Enter the same 4-digit code to unlock
CONTINUED NEXT PAGE
8ENGLISH
OPERATION
CONTINUED NEXT PAGE
Toplidunlocksautomaticallywhen:
1.Shredding is complete.
2.Shredder is inactive for 30 minutes when documents remain in the paper tray or shedding error
occurs.
Features:
•Auto-ReverseTechnology:
When shredder detects over-capacity shredding, the motor will immediately stop and
reject paper before actual shredding begins.
•EnergySavingAutoPower-Sleep:
This setting turns off all features of the shredder. For safety reasons, we recommend
that you leave shredder in the OFF position whenever it is unattended or not in use.
•TopLidSecurityLock:
To lock the top lid: Enter any 4-digit code during shredding
To open the top lid: Enter the same 4-digit code to unlock
Top lid unlocks automatically when:
1. Shredding is complete.
2. Shredder is inactive for 30 minutes when documents remain in the paper tray or
shedding error occurs.
•FeaturesaCD/DVDandCreditCarddestroyer:
1. Lift up the top lid.
2. Insert CDs/DVDs or credit cards into the CD/DVD/Credit Card slot. Only shred credit
cards by feeding them horizontally into the middle of the entry, releasing when
shredding begins. Never feed more than one credit card at a time.
3. Close the top lid.
4. Shredder will stop when the entire disc or credit card has been destroyed.
9ENGLISH
OPERATION
Auto-FeedShreddingOperation:
Put main power switch
in ON (–) position.
Turn power on.
Plug into ground standard US
household power outlet (120-V).
•Poweronshredder
•Openlidandloadpaper*
Shreds:
• Maximum 400 sheets of letter size (8-1/2” x 11”) 20 lb bond paper per load
• Up to 20 sheets stapled paper stacks
• Up to 20 sheet clipped paper stacks
•Auto-FeedShreddingCapacity:
•Closelid:
The shredder automatically starts when you
close the lid.
CONTINUED NEXT PAGE
*Papershouldbeflatandalignedwith
papertray.
10 ENGLISH
CONTINUED NEXT PAGE
NOTE:
• Always turn off and unplug the shredder when not in use.
• This shredder will shred staples and small paper clips. It is recommended that you remove paper clips
whenever possible to extend the lifespan of your shredder.
• Only shred credit cards by feeding them vertically i nto the middle of the entry, releasing when
shredding begins. Never feed more than one credit card at a time.
• Overfeeding the shredder: Shredding beyond the specified sheet capacity can result in extensive
damage to the shredder. Overfeeding will strain the machine and quickly wear and break the cutting
blades and internal components.
• Overheating with extended use: In the event that the shredder has shred continuously beyond the
maximum running time and overheating, the unit will automatically shut off. If this happens, switch the
shredder off for 45 minutes or longer before resuming normal operation.
OPERATION
Only shred credit card by feeding it vertically into
the middle of the entry, releasing when shredding
begins. Never feed more than one credit card at
a time.
Make sure you do not exceed sheet count per
pass (10 sheets max). Insertpaperas
straightaspossibleintofeedslotand
release.
•Poweronshredder
Plug into ground standard
US household power outlet
(120-V).
Turn power on.
Put main power switch
in ON (–) position.
Manual-FeedShreddingOperation:
