User Manual
Wireless Audio Receiver with NFC
English
Italiano
日本語
Deutsch
Français
Español
01 ~ 06
25 ~ 30
31 ~ 36
07 ~ 12
13 ~ 18
19 ~ 24
Contents
- 01 -
Thank you for purchasing the AUKEY BR-C16 Wireless Audio Receiver
with NFC. Please read this user manual carefully and keep it for future
reference. If you need any assistance, please contact our support
team with your product model number and Amazon order number.
Package Contents
Wireless Audio Receiver with NFC
Micro-USB Cable
3.5mm Audio Cable
3.5mm to Dual RCA Audio Cable
User Manual
Warranty Card
Product Diagram
Multi-Function Button
Microphone
LED Indicator
3.5mm Audio Output
Micro-USB Charging Input
Specifications
Model
Technology
Frequency Range
Input
Charging Time
Continuous Use Time
Battery Type
Operating Range
Dimensions
Weight
BR-C16
BT 4.1, AVRCP, HFP, HSP
2.402GHz– 2.480GHz
DC 5V
2.5 hours
10 hours
Li-Polymer (150mAh)
Up to 10m / 33’
56 x 56 x 14mm / 2.19” x 2.19” x 0.55”
25g / 0.86oz
- 02 -
Getting Started
Charging
Fully charge your product before first use. To charge, simply connect
one end of the micro-USB cable to a USB charging port and the other
end to the input port on the product. When the green LED indicator
turns off, your BR-C16 is fully charged and ready for use. Charging takes
around 2.5 hours.
To power on, press and hold the multi-function button for 2 seconds,
and the LED indicator will flash white and green simultaneously
To power off, press and hold the multi-function button for 4 seconds,
and the LED indicator will turn off
●
●
Powering On / Off
- 03 -
Pairing Using NFC
If your wireless-compatible audio device (like smartphone) has the NFC
(Near-Field Communication) pairing function, you can pair it more
easily using NFC. Apple devices don’t offer NFC pairing at this time.
Connect one end of the included 3.5mm audio cable (or 3.5mm to
dual RCA audio cable) to the 3.5mm audio jack on the BR-C16, and
connect the other end to your audio equipment (wired speaker or
stereo system)
Power on the BR-C16 and it will automatically enter pairing mode
with the LED indicator flashing white and green alternately
Activate the NFC function of your wireless-compatible audio device
(like a smartphone)
Hold your device on the BR-C16 until a pairing prompt appears and
select “YES” to pair. It will automatically switch on the pairing
function and connect
When successfully connected, the LED indicator will turn solid white
Once paired, you can reconnect with NFC by holding your device
on BR-C16 (you won’t need to click “YES” on a pairing prompt
again). Or reconnect automatically with wireless connection
switched on
1.
2.
3.
4.
5.
6.
Connect one end of the included 3.5mm audio cable (or 3.5mm to
dual RCA audio cable) to the 3.5mm audio jack on the BR-C16, and
connect the other end to your audio equipment (wired headphones,
speaker, or stereo system)
Power on the BR-C16 and it will automatically enter pairing mode
with the LED indicator flashing white and green alternately
Activate the pairing function of your wireless-compatible audio
device (like a smartphone) and select “AUKEY BR-C16”
If a code or PIN is required for pairing, enter “0000”
When successfully connected, the LED indicator will turn solid white
Once paired, you can reconnect automatically with wireless
connection switched on
Simultaneous Connection with Two Devices
Two wireless-compatible devices (such as phones) can be simultaneously
connected to one audio output device (such as a speaker), but sound
can only be received from one source at a time.
1.
2.
3.
4.
5.
6.
Follow the instructions in the “Pairing” section to pair the BR-C16 with
Device A
1.
Pairing Without NFC
- 04 -
Once paired, disable the wireless function on Device A
Activate the wireless function on Device B and select “AUKEY BR-C16”
Once paired with Device B, reactivate the wireless function on Device
A and select “AUKEY BR-C16” in the list of paired devices
2.
3.
4.
NFC is a very short-range system. NFC devices should be touching or
extremely close to pair or connect. The position of the NFC chip in
devices also varies
The BR-C16 will automatically enter standby mode after 1 minute in
pairing mode and automatically shut down after 10 minutes if no
devices are paired
If your paired device is turned off or disconnected, the BR-C16 will
automatically enter pairing mode for 1 minute and then go into
standby mode
The maximum wireless operating range is 10m (33ft). If you exceed this
range, the BR-C16 will disconnect from your paired device. The
connection will be re-established once you re-enter the wireless range
within 1 minute. The BR-C16 will automatically reconnect to the
last-paired device. To connect with other devices, repeat the previous
“Pairing” steps
●
●
●
●
Notes
Controls & LED Indicators
Functions Instructions
Answer or end a call
Reject an incoming call
Switch mic
Switch device
Redial last-called number
Play or pause
Cancel pairing
Short-press the multi-function button
Press and hold the multi-function button
for 2 seconds
Short-press the multi-function button
Press and hold the multi-function
button for 2 seconds
During a call, double-press the multi-function
button to switch between the BR-C16 and
your phone for talking
During a call, double-press the multi-function
button to switch between the BR-C16
and your phone for talking
When you have 2 phones connected and
get a call on one during a call on the other,
press and hold the multi-function
button for 2 seconds to switch between the
two phone calls
- 05 -
Keep away from liquids and extreme heat
Don’t use headphones or speakers at high volume for extended
periods, as this may cause permanent hearing damage or loss
Warranty & Customer Support
For questions, support, or warranty claims, contact us at the address
below that corresponds with your region. Please include your Amazon
order number and product model number.
*Please note, AUKEY can only provide after sales service for products purchased directly
from AUKEY. If you have purchased from a different seller, please contact them directly for
service or warranty issues.
Notice for the US
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions:
●
●
This device may not cause harmful interference.
This device must accept any interference received, including
interference that may cause undesired operation.
1.
2.
LED Indicators
White & green flashing alternately
White
White flashing rapidly
White flashing slowly
Green flashing
Green
Off (after charging)
Status
Pairing mode
Connected / Playing music
Incoming call / In call
Standby mode
Low battery
Charging
Fully charged
Product Care & Use
- 06 -
NOTE: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment.
●
●
●
●
- 07 -
Vielen Dank, dass Sie sich für den BR-C16 Kabelloser Audioempfänger
mit NFC von AUKEY entschieden haben. Bitte lesen Sie diese
Bedienungsanleitung aufmerksam durch und bewahren Sie sie für
zukünftige Referenz gut auf. Sollten Sie darüber hinaus Fragen oder
Probleme haben, hilft Ihnen unser freundlicher Kundenservice gerne
weiter. Halten Sie Ihre Produktmodell -Nummer und Amazon-Bestell-
nummer bereit.
Lieferumfang
Kabelloser Audioempfänger mit NFC
Micro-USB-Kabel
3,5mm Audiokabel
3,5mm auf 2-RCA Audiokabel
Bedienungsanleitung
Garantiekarte
Product Diagram
Multifunktionstaste
Mikrofon
LED-Anzeige
3,5mm Audio Anschluss
Micro-USB-Port
Spezifikationen
Modell
Technologie
Frequenzbereich
Eingang
Ladezeit
Arbeitszeit
Akku-Typ
Betriebsbereich
Abmessungen
Gewicht
BR-C16
BT 4.1, AVRCP, HFP, HSP
2.402GHz– 2.480GHz
DC 5V
2,5 Studen
10 Studen
Li-Polymer (150mAh)
Bis zu 10m / 33’
56 x 56 x 14mm / 2.19” x 2.19” x 0.55”
25g / 0.86oz
- 08 -
Erste Schritte
Laden
Laden Sie das Produkt vor der ersten Verwendung vollständig auf.
Verbinden Sie dafür ein Ende des Micro-USB-Kabels mit einem
USB-Ladeanschluss und das andere Ende mit dem Eingang des Produkts.
Sobald die grüne LED-Anzeige erlischt, ist der BR-C16 vollständig geladen
und einsatzbereit. Der Ladevorgang dauert ungefähr 2,5 Stunden.
Zum Einschalten halten Sie die Multifunktionstaste 2 Sekunden lang
gedrückt. Die LED-Anzeige blinkt dann gleichzeitig weiß und grün
Zum Ausschalten halten Sie die Multifunktionstaste 4 Sekunden lang
gedrückt. Die LED-Anzeige erlischt dann
●
●
Ein-/Ausschalten
