Audionet WATT Manual de usuario

WATT

Integrated Stereo Amplifier

User’s Manual

Contents

1!Preface 5!

1.1!Included items 6!

1.2!Transport 6!

2!Overview front panel 7!

3!Overview back panel 8!

4!Installation and power supply 9!

4.1!Placement 9!

4.2!Mains connection 10!

4.3!Orientation of mains plug 11!

5!Inputs and outputs 12!

5.1!Inputs 12!

5.2!Optional phono input 12!

5.3!Speaker terminals 13!

5.4!Preamplifier Output 14!

5.5!Headphones socket 14!

5.6!Audionet Link 14!

5.7!Control connection 15!

6!Usage 16!

6.1!Powering up 16!

6.2!Switching on and off 16!

6.3!Using Audionet Link 17!

6.4!Control elements on the front panel 18!

6.5!Volume control 18!

6.6!Display 19!

6.7!Input selection 20!

6.8!Muting 21!

7!Audionet Metal Remote Control 22!

7.1!Key assignment WATT 23!

7.2!Changing the batteries 23!

7.3!Settings for Audionet WATT 24!

8!Setup menu 27!

8.1!Overview setup menu 28!

8.2!Select Input 29!

8.3!Global Setup 29!

8.3.1!Headphones 29!

8.3.2!Display 30!

8.3.3!Balance Left/Right 31!

8.3.4!AutoStart 32!

8.3.5!AutoOff 33!

8.3.6!By-Pass Channel 33!

8.3.7!Phono Card 36!

8.3.8!Serial Port 37!

8.3.9!Channel Name 38!

8.3.10!Volume Offset 38!

8.4!Reset factory defaults 39!

8.5!Device Info 40!

9!Protection system 41!

10!Security advice 42!

11!Technical data 43!

1 Preface

The Audionet Scientists Team and its leading scholars congratulate you on your

purchase of this unit, sending cheers directly from our research and development

center.

Audionet components are no marketing products, they are authentic. Conceived

and developed with scientific inspiration, professional engineering expertise and

a deep passion for achieving the truly perfect sound. They are unique creations

designed to inspire musical enjoyment and have an excellent reputation amongst

all connoisseurs throughout the world. Each and every one of our precision-man-

ufactured devices is individually crafted by hand at our new Berlin headquarters.

Built by audiophiles for audiophiles. With the utmost precision and total control

of each and every perceptible detail.

Even if you're an experienced aficionado of ultra-highend components, please

start listening to your new Audionet WATT by reading this manual carefully be-

fore you plug it in. This will ensure you'll enjoy all functions of this unit without

any compromise or potential disruption.

1.1 Included items

You will find the following items included:

• The stereo integrated amplifier WATT

• The user's manual (that you are currently reading)

• One standard mains cord

• Audionet Metal Remote Control

1.2 Transport

Important

• Only transport the WATT in the original packaging.

• Always use the provided cloth bag to prevent scratches on the casing.

• Please allow the WATT to adapt to the climatic conditions in your listening

room before you switch the unit on for the first time after the transport.

2 Overview front panel

WATT

audionet

Power

Input

Select

Mute

IR remote

control receiver

Volume

controller

Display

3 Overview back panel

1Speaker output right channel

Cinch input no. 2, right channel

Cinch input no. 3, right channel

Cinch input no. 4, right channel (optional Phono)

Mains input and fuse compartment

Marking mains phase

Cinch input no. 2, left channel

Cinch input no. 3, left channel

Cinch input no. 4, left channel (optional Phono)

Speaker output left channel

11 Control input RS232

12 Additional earth connection

13 Preamplifier output PRE OUT, left channel, Cinch

14 Balanced input (XLR) no. 1, left channel

15 Headphones output

16 Balanced input (XLR) no. 1, right channel

17 Preamplifier output PRE OUT, right channel, Cinch

18 Earth connection for phono

19 Audionet Link outputs OUT 1 and OUT 2

ANALOG LEFT

PHASE

MAINS

HEADPHONES

DISCONNECT POWER CORD BEFORE OPENING

ANALOG RIGHT

RIGHT

GND

ENGINEERED AND HANDMADE BY IDEKTRON GMBH & CO. KG, BERLIN, GERMANY

SPEAKER

OUTPUT

GND

SPEAKER

OUTPUT

LEFT

THIS UNIT MUST BE EARTHED

WATT

220-240V / 50-60Hz / 900W MAX.

FUSE T10A

RS232

CONTROL

OUT 1 OUT 2

AUDIONET LINK

IN 1

IN 2

IN 3

IN 4

PRE-OUT

(PHONO)

IN 1

IN 2

IN 3

IN 4

(PHONO)

PRE-OUT

4 Installation and power supply

Important

• During connecting and removing sources or amplifiers to the WATT, all units

of your audio system have to be switched off to prevent damage to the WATT

or any of the other connected units.

• Please make sure that all cables are in absolute best conditions! Broken shields

or short-cut cables could damage the WATT and/or any other units con-

nected.

4.1 Placement

Important

• It is recommended to place the WATT in a high quality rack or onto a stable

table.

• Do not expose the unit to direct sunlight.

• Do not cover the ventilation slots.

• Do not place the WATT in close range to heat sources like radiators.

• Do not place the WATT on top of other units, especially not on top of power

amplifiers, preamplifiers or similar devices that produce heat. Both units could

suffer damage from thermal overload.

• Do not use the unit in places where it is exposed to vibrations.

• Do not place the unit close to loudspeakers or in corners of a room where

it is exposed to high levels of sonic energy, which might reduce the sound

quality of the unit.

4.2 Mains connection

The mains input * is on the back panel of the WATT. Use the included mains

cord to connect the unit to mains. If you prefer to use a different power cord,

make sure that it meets the specifications for your home country.

Important

• The electrical specifications of your home country must meet the electrical

specifications printed onto the back panel.

• The WATT is a Class I unit and must be earthed. Please ensure a stable earth

connection. The phase ('hot' pin) is marked on the back panel (PHASE) .

• Never pull the mains plug while the WATT is switched on! Before you pull the

mains cord off its socket at the back panel, power down the unit to stand-by

mode.

The WATT should only be switched off from the mains in cases of extended

absence (like vacations) or if massive trouble on the mains power is to be ex-

pected. Pull the mains plug to completely disconnect the unit from mains.

Tip

• The use of high quality mains cords (e.g. Audionet P10) could improve

the sound quality of your Audionet WATT. Please refer to our website

(www.audionet.de) or ask your local dealer for further information.

*Please refer to section "Overview back panel" on page 8.
