Audio Technica AT-LPW50BT Manual de usuario

AT-LPW50BT

Wireless Belt-Drive Turntable

User Manual

English

Introduction

This product can be used only in the countries where the product is sold. Make sure that the operating voltage and the

plug of AC adapter of the product are correct for the country you live in.

Safety precautions

Although this product was designed to be used safely, failing to use it correctly may result in an accident. To ensure

safety, observe all warnings and cautions while using the product.

Important information

Warning

To prevent fire or shock hazard, do not expose this apparatus to rain or moisture.

Caution

Do not expose this apparatus to drips or splashes.

To avoid electric shock, do not open the cabinet.

Refer servicing to qualified personnel only.

Do not expose this apparatus to excessive heat such as sunshine, fire or the like.

Do not subject this apparatus to strong impact.

This apparatus should be located close enough to the AC outlet so that you can easily grasp the AC adapter at any

time.

In case of emergency, disconnect the AC adapter quickly.

Do not place any objects filled with liquids, such as vases, on this apparatus.

To prevent fire, do not place any naked flame sources (such as lighted candles) on this apparatus.

Do not install this apparatus in a confined space such as a bookcase or similar unit.

Install this apparatus only in the place where ventilation is good.

The rating label is put on the bottom of this apparatus.

For customers in the USA

FCC Notice

Warning

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device

may not cause harmful interference, and (2) this device must accept any interference received, including interference

that may cause undesired operation.

Caution

You are cautioned that any changes or modifications not expressly approved in this manual could void your authority to

operate this equipment.

Safety precautions

Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part

15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a

residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful interference to radio communications. However, there is

no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following measures:

– Reorient or relocate the receiving antenna.

– Increase the separation between the equipment and receiver.

– Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

– Consult the dealer or an experienced radio/TV technician for help.

This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter used in other

systems.

RF Exposure Statement

This device complies with FCC radiation exposure limits set forth for an uncontrolled environment and meets the FCC

radio frequency (RF) Exposure Guidelines. This equipment has very low levels of RF energy that it deemed to comply

without maximum permissive exposure evaluation (MPE). But it is desirable that it should be installed and operated

keeping the radiator at least 20cm or more away from person’s body.

Contact

Responsible Company: Audio-Technica U.S., Inc.

Address: 1221 Commerce Drive, Stow, Ohio 44224, USA

Tel: 330-686-2600

For customers in Canada

ISED statement

CAN ICES-003 (B)/NMB-003(B)

This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic

Development Canada’s licenceexempt RSS(s). Operation is subject to the following two conditions:

1. This device may not cause interference.

2. This device must accept any interference, including interference that may cause undesired operation of the device.

This device complies with RSS-102 radiation exposure limits set forth for an uncontrolled environment.

This equipment should be installed and operated with minimum distance of 20 cm between the radiator & your body.

Notes on use

Turntable body

Do not set and use the product in locations that are considerably hot or humid, dirty, or subject to extreme vibrations.

The product should be positioned on a flat, level surface.

When closing the dust cover, close it completely.

When using this product with a Bluetooth device connected to it, be sure to also read the user manual for the

Bluetooth device.

Cartridge

Attach the provided protector to the cartridge when the product is not in use.

Do not touch the stylus of the cartridge with your finger.

Do not allow the stylus to bump against the platter, rubber mat, or edge of the record.

Package contents

Make sure that you have all the included items before using this product.

If some items are missing or damaged, contact your local Audio-Technica dealer.

After purchase, we suggest that you save all packaging materials for possible future storage, moving, or shipping.

89 10

64 5

12 13

Turntable body

Platter

Drive belt

Dust cover

Rubber mat

Dust cover hinges

Package contents

Headshell (AT-HS4 SV) with VM stereo cartridge (AT-VM95E BK)

Counterweight

45 RPM adapter

AC Adapter

RCA audio cable (Approx. 1.0 m (3.3'))

Quick Start Guide

Caution Guide

Part names and functions

Top view

Platter

Drive belt

Motor pulley (brass-colored)

Spindle

Rubber mat

Control knob

Use to select the platter speed (33-1/3 or 45 RPM) or start/stop the platter.

Tonearm

Rear view

1 12 23 6 7

Feet

Adjust the level of the product.

Dust cover hinge holders

Attachment points for dust cover hinges.

Part names and functions

Ground (earth) terminal

Connect the amplifier’s ground (earth) terminal to this terminal using the RCA audio cable’s ground line.

Stereo output terminals

Connect the RCA audio cable. Connect it to either the amplifier’s PHONO input jack or its line input jack. The red

terminal is the right channel and the white terminal is the left channel.

Pre-amplifier selector switch

If connecting to an amplifier’s PHONO input jack, set this switch to the PHONO position. If connecting to the AUX

jack of an amplifier, set this switch to the LINE position.

Power input jack

Connect the AC adapter.

Power switch

Turn on/off the power.

Tonearm

Counterweight

Balances the tonearm and adjusts to provide the proper tracking force.

Tracking force gauge ring

Use to adjust the tracking force.

Part names and functions

Tonearm lift

Moves the tonearm vertically to and from the face of the record.

Tonearm rest with clamp

Use the clamp to secure the tonearm so that it does not move.

Anti-skate control dial

While the record is playing, a force acts on the stylus tip to pull it inward. This force can be counteracted by setting

the same values for anti-skate and the tracking force.

Wireless function button

Use to connect this product to a Bluetooth device.

Bluetooth indicator LED

Indicates the Bluetooth connection status with solidly lit or flashing light.

Tonearm lift control lever

Operates the tonearm lift.

Tonearm

Locking ring

Rotate the ring to the left (counterclockwise) to secure the headshell. To remove the headshell, rotate the ring to the

right.

Headshell and cartridge

The cartridge is attached to the headshell.
