Audio Technica BP3600 Manual de usuario

BP3600

Immersive Audio Microphone

User Manual

English

Safety precautions

Although this product was designed to be used safely, failing to use it correctly may result in an accident. To ensure

safety, observe all warnings and cautions while using the product.

Cautions for the product

Do not subject the product to strong impact to avoid malfunction.

Do not disassemble, modify or attempt to repair the product.

Do not handle the product with wet hands to avoid electric shock or injury.

Do not store the product under direct sunlight, near heating devices or in a hot, humid or dusty place.

Do not place the product on an unstable surface to avoid injury or malfunction due to falling or the like.

Notes on use

Be sure to read the connected device’s user manual before use.

When the product is used for a long time, the product may become discolored due to ultraviolet light (especially

direct sunlight) and wear.

Make sure to hold the plug when connecting and disconnecting the cable. The cable may become severed or an

accident may occur if you pull on the cable itself.

When using the cable, be careful not to twist it to prevent damage to the cable.

Do not wind the cable at the base of the plug. Doing so may result in disconnection.

When plugging the cable into the microphone and the connected device, check that the connector is facing in the

correct direction before inserting it straight. Inserting the connector or plug diagonally may cause a malfunction.

For important recordings, perform a trial recording beforehand to make sure that the sound is recorded correctly.

Audio-Technica will not be liable in any way for any loss or damage to software or data connected to the product.

Do not apply excessive force to the connector by rotating the microphone module.

When installing the product in a suspended position, be sure to attach a wire to prevent the product from falling.

When installing the product in a suspended position, Audio-Technica will not be liable in any way for accidents such

as falling due to inadequate strength of the installation or equipment.

Package contents

3 4

Microphone module × 8

Core body

The AT8476 stand clamp for 5/8”-27 threaded stands and the 5/8”-27 to 3/8”-16 threaded adapter are attached to

the core body in advance. The stand clamp cannot be removed.

Case

5 m (16') microphone cable (BP3600/CABLE)

Windscreen × 8 (AT8172)

Caution Guide

Accessories (sold separately)

1 2 3

20 m (66') microphone cable (BP3600/CABLE20EXT)

Use this accessory to extend the microphone cable.

Windshield (× 1) (BP3600/WS)

Use this accessory to reduce wind and other noises when outside, etc.

Windjammer (× 1) (BP3600/WJ)

Use this accessory with the windshield to further reduce wind and other noises.

Storage in the case

The case contains the microphone modules, core body, and windscreens. Make sure to check the storage direction

indicators on the bottom of the case before storing parts.

Windscreen × 8

Core body

Microphone module × 8

Part names and functions

Microphone (BP3600/MIC)

Windscreen (AT8172)

Microphone module

Connector lock

Core body

Channel ID color ring

Grip

Output connector

Strap for seismic cable

AT8476 stand clamp for 5/8”-27 threaded stands

The 5/8”-27 to 3/8”-16 threaded adapter is attached in advance.

Using the product

Assembling the microphone

1Attach the windscreen to the microphone module.

Push the windscreen all the way on.

2Attach the microphone module to the core body.

Check the connector orientation before attaching the microphone module.

3Rotate the connector lock clockwise to secure the microphone module to the core body.

If the marking on the microphone module is aligned with the marking on the core body, the lock is

disengaged. Rotate the connector lock to misalign the marking and engage the lock to secure the microphone

module to the core body.

Using the product

4Repeat steps 1 to 3 to attach all eight microphone modules to the core body.

5Connect the microphone cable to the core body output connector.

6Connect the microphone cable to a device (mixer or recorder) that has a microphone input (balanced

input) compatible with a phantom power supply.

Before recording, make sure an audio signal is being output from all eight channels.

Using the product

Mixer

Recorder

Extending the cable

When using the 20 m (66') microphone cable (BP3600/CABLE20EXT) (sold separately) to extend the cable, connect

them as shown in the figure.

1 2

20 m (66') microphone cable (BP3600/CABLE20EXT) (sold separately)

5 m (16') microphone cable (BP3600/CABLE)
