AUTOOL X60

Car OBD Multi-function Meter

User Manual

www.autooltech.com

Trademar k

AUTOOL Technology Co, Ltd. has registered its

trademarks in several countries including China, the

trademark is . With regard to the other trademark,

service logo, domain name, icon and company name

mentioned in this manual, they shall all belong to AUTOOL

and its other affiliated company, in other countries without

the registration yet of these trademark, service logo,

domain name, icon and company name of AUTOOL, here

we announce they are owned by AUTOOL. Any company

or person shall not use the trademark, service logo,

domain name, icon and company name of AUTOOL before

getting approved by AUTOOL with written certificates.

Please visit our website www.autooltech.com or email to

[email protected] to contact us.

Caution

Please read this manual carefully as part of using the

product.

Please keep this manual in case of product

maintenance.

Please follow the operation instructions and use the

parts recommended by manufacturer.

The product is only used for functions as designed,

112

Warranty not Covered in

Conditions Listed Below

Product is bought through non-official AUTOOL

purchase channel.

Product failure is caused by incorrect use of the

product, use for other wrong purpose or human factors.

Disclaimer: The AUTOOL Technology Co, Ltd. reserves

the right to change product designs and specifications

without prior notice. The physical appearance and color

may differ from those shown in the instruction manual.

Please refer to the actual product. If you have any

questions, please contact the dealer or the Autool service

center. The company have the final explanation right of

product and shall not bear any consequences due to

misunderstanding.

please don’t use it for other purpose.

In term of improper usage or purpose usage of the

product, the manufacturer shall not be responsible for

the results.

Product Introduction

Suitable vehicle models

The product is suitable for standard OBD II protocol

compliant petrol and diesel vehicles, especially for

vehicles without a temperature gauge, tachometer

and fuel consumption meter.

Product installation

This product is a car OBD multi-function instrument

with a stylish and compact shape. It is designed for

installation through the plug and play OBD port

without cutting the wire, easy and simply to install.

Features of pr oduct hardware

32-bit ARM CORTEX-M3 CPU, with 72MHz maximum

operating frequency, in support of multiple high speed

automotive communication protocols.

Early Alar m Function

Support multiple early alarm functions: water temperature

Size(mm) 60*50*67

Product packing list

host, OBD cable, 3M double-sided tape, user manual,

quality certificate.

Warranty

There are 3 years’ warranty for AUTOOL products and

the accessories since the day the customers have

received the product parcel.

Warranty Access

Repair or replace the equipment will be done according

to the specific fault conditions;

We guarantee that all replacement parts, accessories or

equipment are brand new;

When there is a product breakdown that can not be

solved within 90 days, customer should provide video

and pictures as proof, we will bear the freight cost and

provide customer the accessories in need to replace.

After receiving the product for more than 90 days, the

customer shall bear the freight cost, we will provide the

accessory for free to replace.

early alarm, over-speed early alarm, shifting reminding

early alarm and vehicle fault early alarm; bring car owners

great convenience for safe driving.

Clearing Error Codes

Product Description

X60 OBD computer is a smart and powerful auto meter. It

is especially designed for vehicle without speedometer,

engine temperature gauge, oil thermometer, boost gauge

and fuel consumption meter.

X60 can also monitor and display battery voltage, engine

charging voltage, over-speed alarm, engine temperature

warning. It can even read the real-time data stream, scan

and clear trouble code.

Product Appearance

Car owners can scan and clear regular vehicle error

codes at their discretion and reduce repair costs, without

going to the 4S shop.

① Function button

② Display

③ OBD port

④ Ambient light detector

①

②

③④

Quick switch to displayed quantity and content.

Set more content.

Set to display instant fuel consumption or RPM bar.

The 10 round icons in the top are shift reminding

display. It is default off.

Product Information

It helps to check software version, vehicle protocol and

solution for protocol compatibility.

About protocol compatibility

When connecting with some vehicles, gauge LED or

trouble alarm LED may be lit. Please follow the

“Matching info” to operate - Please open OBD cable of

product, and cut off the corresponding pins to solve the

problem.

Product Parameter

Work voltage

Sleep mode current

10-18V DC

<15mA

Work current

Work temp.

<80mA

-20~75℃

display accurately.

Voltage warning - To remind the driver if the battery is

under charge.

Color of number - 7 colors to choose.

Speed to zero - In idle speed mode, speed will display

zero if it is lower than the scheduled.

Fuel consumption adjustment - Average fuel

consumption is less the actual. If it displays more,

adjust the percentage to be smaller, and vice versa.

Reset - X60 will revert to the initial state.

Display Setting

To set display

In working condition, 4 types of information will display.

They corresponds to the following content:

Turn right/left of function button to quick select from main

screen. In setting mode, turn right/left to choose menu.

Press down in the middle to confirm. Long press menu

button in the middle to exit or go　back.

Product Installation and Use

Connect one side of OBD cable with car OBD port, the

other side with X60 OBD port.

After connection with host, start the car and wait X60 to

connect with vehicle. Connecting successfully, the host

ticks, and X60 displays vehicle protocol. Then, it will show

parameter setting for the first use.

International universal OBD

plug protocol stipulated by

SAE:

Note:

The automobile dash-board must be kept clean, if there is

wax　on it, the double adhesive panel may not be

pasted on it, please clean it with a hot towel and then

start installation. When you install, heat the instrument

panel by hot blowing air, which can make the best achieve

effect.

Holder Installation

Tear 3M double-sided tape, and fasten it with holder

base.

Pull up the bottom center to right and left.

Insert the base of holder to the bottom of host.

Insert the bolt from right, and nut from left.

Fasten the screw with screwdriver.

Turn right/left of button in the top of host, the displayed large

character can be switched fast.

Product Operating Setting

If the device does not support current data display, red X will

be displayed. If function data needed cannot be selected,

please check in the data stream of Electronic Control

Diagnosis System.

Current speed Average speed

Water temperature Intake temperate

Outside temperature Battery voltage

Product Parameter Setting Including

Engine displacement - To accurately calculate instant

and average fuel consumption.

Fuel type - Choose petrol or other type fuel, fuel

consumption data will be much different.

Over-speed alarm - When it reaches to the scheduled

speed, it will tick to alarm, and the character for speed

will display in red.

Water temperature warning - When it reaches to the

scheduled engine temperature, it will tick to alarm, and

the character for temperature will display in red.

Shift reminding - When it reaches to the scheduled

speed, it will remind to shift, and display shift symbol.

Shift reminding limit - When it reaches to the scheduled

speed, it will turn off shift reminding, in case it exceeds

the scheduled speed, and cannot shift up.

Standby time - After the vehicle shuts down, and it

reaches to the scheduled standby time, X60 will change

to automatic sleep.

Speed error adjustment - when the speed is 100km,

adjust displayed speed of X60 to 100km.

Battery voltage adjustment - Adjust X60 voltage to

MAP (manifold absolute pressure) Fuel pressure

TAHCO/RPM (rotate per minute) Engine load

Fuel Level Distance

Average fuel average Clock

Instant Fuel consumption Ignition Turbine

OTL P. (engine oil pressure) Throttle position

OIL T. (engine oil temperature)

Electronic Control Diagnosis System

Press the function button to Electronic Control Diagnosis

System. It includes 3 functions. See the picture below:

Choose the function“Scan DTCs”, it can read trouble code,

and you can decide if clearing the code.

Vehicle Performance Test

Choose “Data Stream”. It will monitor real-time data. Turn

right/left of the button, it will show page up and down.

Vehicle performance test includes: speedup test, brake

test, target speedup, brake initial speed.

Before speedup test, please set target speedup. When

it reaches to the scheduled speed, finish speedup test.

Before brake test, please set brake initial speed. When

it reaches to brake initial speed, calculate the distance

from beginning to the end of acceleration.

Product Parameter Setting

In parameter setting, turn right/left of the button to set the

parameter value. Long press function key back to previous

menu.
