ATP Instrumentation MT-913 Manual de usuario

4 1

Operation Instructions

Power on/off:

Press“ ” to power the meter on/off.

Data Hold:

Whilst in measurement mode, press “ ”, the LCD display will clearly

display “HOLD” which indicates the data is frozen, to release the held

reading. Press the “ ” button again the release the reading.

MAX/MIN:

Whilst in measurement mode, press“ ”，to cycle through the maximum

or minimum recorded measurements. The LCD display will clearly display

“MAX”, or “MIN” to indicate the displayed value. Press and hold “ ” to

exit MIN/MAX mode and return to normal measurement mode.

Unit:

Whilst the meter is turned on，press“ ”，it can select temperature, dew

point temperature and wet bulb temperature in turn.

°C / °F Mode:

Whilst the meter is turned off, press and hold “ ” and press “ ”. The

unit will power on with the temperature unit (°C/°F) toggled.

Auto Power Off

Whilst the meter is turned off, press and hold “ ” and press “ ”. The

unit will turn on with the auto power off feature toggled off.

Note: If the icon is displayed, the auto power off feature is enabled.

Additional Notes

1) Recommended recalibration cycle: 1 year.

2) Remove the battery when the meter is to be stored for long periods of time to avoid

battery leakage.

3) When the battery is low，the low battery indicator will appear.

A new battery is needed.

This unit complies with EMC

ATP INSTRUMENTATION LTD

THE ONE STOP INSTRUMENT SHOP

WWW.ATP-INSTRUMENTATION.CO.UK

Sales: 01530 566800 Technical: 01530 566804

UNIT 22 Tournament Way, Ashby-De-La-Zouch, Leicestershire, LE65 2UU

MINI COLOUR LCD HUMIDITY & TEMPERATURE METER

MT-913

USER MANUAL

Important Safety Notice

Read the following safety information carefully before attempting to operate or service the

meter. Use the meter only as specified in this manual; otherwise, the protection provided by

the meter may be impaired.

Environmental Operating Conditions

Humidity:

≤ 90% RH (Non-condensation)

Operating temperature:

-20 to 60°C / -4 to140°F

Maintenance

Repairs or servicing not covered in this manual should only be performed by qualified

personnel.

Wipe the unit with a dry soft cloth. Do not use abrasives or solvents on this instrument.

2 3

Application

This meter is widely used to measure the temperature and humidity of storage rooms, metro,

libraries, commercial centers etc.

Features

•Imported high accuracy humidity

&temperature sensor ,high accuracy, fast

response

•Color LCD display with backlight

•Temperature unit selection：℃/℉

•MAX/MIN

•HOLD

•Dew point temperature

•Wet bulb temperature

•Enable/Disable auto power off

•Over range indication

•Low battery indication

Specifications

Humidity

Range：0 to 100%RH

Range

Accuracy

Resolution

45to 75%RH

±3.0%RH

0.1

Others

±4.5%RH

Temperature

Range

Accuracy

Resolution

-20°C to 0℃/-4°F to 158°F

±1.0°C / ±1.8°F

0.1

Dew point temp.

20°C to 70°C /-4°F - 158°F

±1.5°C / ±2.7°F

0.1

Remark: Accuracy is based on environment condition of 25℃;

40%RH to 100%RH

Wet bulb temp.

20°C to 70°C / -4°F to 158°F

±1.5°C / ±2.7°F

0.1

Data update

0.5S

Enable/disable

auto power off

The meter shuts off automatically after 15 minutes of inactivity. Auto

power off can be disabled

Operating conditions

-20°C to 60°C, -4°F to 140°F,10%RH to 90%RH

Storage conditions

-20°C to 60°C, -4°F to 140°F,10%RH to 75%RH

Power supply

3 x 1.5V “AAA” batteries

Battery life

at least 50 hours

Dimensions

168 x 56 x 30.5mm

Weight

75g

Meter description

1. Temperature and humidity sensor

2. Color LCD display

3. Hold button

4. Power on/off button

5. MAX/MIN button

6. Mode selection button

7. Battery cover

8. Nameplate

LCD display description

1. Data hold Icon

2. Auto power off Icon

3. Temperature reading

4. Dew point temperature units icon

5. Wet bulb temperature units icon

6. Humidity reading

7. Humidity unit icon

8. Temperature unit icon

9. low battery Icon

10. MAX/MIN

Accessories

1. User Manual

2. 3 x 1.5V AAA Battery
