Atlas Copco P2550 Hoja de instrucciones
P2550
Printed Matter No. 9839 0711 01 Scaler
Valid from Serial No. -
2017-03-31 Product Instructions
P2550 8425010350
WARNING
Read all safety warnings and instructions
Failure to follow the safety warnings and
instructions may result in electric shock, fire
and/or serious injury.
Save all warnings and instructions for
future reference
2© Atlas Copco Industrial Technique AB - 9839 0711 01
Table of Contents
Product information..................................................................... 3
General information................................................................. 3
Safety signal words........................................................ 3
Warranty ........................................................................ 3
ServAid .......................................................................... 4
Website .......................................................................... 4
Safety Data Sheets MSDS/SDS .................................... 4
Country of origin............................................................. 4
Dimensional drawings.................................................... 4
Service overview ..................................................................... 4
Service recommendations ............................................. 4
Installation .................................................................................... 6
Installation requirements ......................................................... 6
Air quality ....................................................................... 6
Air lubrication guide ....................................................... 6
Compressed air connection ........................................... 6
Installation instructions............................................................ 6
Installation of vibrating tools........................................... 6
Operation ...................................................................................... 7
Ergonomic guidelines.............................................................. 7
Service .......................................................................................... 8
Maintenance instructions......................................................... 8
Overhaul and lubrication ................................................ 8
Lubrication instructions............................................................ 8
Rust protection and cleaning ......................................... 8
Lubricating guide............................................................ 8
Recycling .................................................................................... 10
Recycling instruction ............................................................. 10
P2550 EN Product information
© Atlas Copco Industrial Technique AB - 9839 0711 01 3
Product information
General information
WARNING Risk of Property Damage or Severe Injury
Ensure that you read, understand and follow all instructions before operating
the tool. Failure to follow all the instructions may result in electric shock,
fire, property damage and/or severe bodily injury.
►Read all safety Information delivered together with the different parts of
the system.
►Read all product Instructions for installation, operation and maintenance
of the different parts of the system.
►Read all locally legislated safety regulations with regard to the system
and parts thereof.
►Save all safety information and instructions for future reference.
Safety signal words
The safety signal words Danger, Warning, Caution, and Notice have the follow-
ing meanings:
DANGER DANGER indicates a hazardous situation which, if not avoided, will result in death or
serious injury.
WARNING WARNING indicates a hazardous situation which, if not avoided, could result in death
or serious injury.
CAUTION CAUTION, used with the safety alert symbol, indicates a hazardous situation which, if
not avoided, could result in minor or moderate injury.
NOTICE NOTICE is used to address practices not related to personal injury.
Warranty
• Product warranty will expire 12 months after the product is first taken into
use, but will in any case expire at the latest 13 months after delivery.
• Normal wear and tear on parts is not included within the warranty.
• Normal wear and tear is that which requires a part change or other ad-
justment/overhaul during standard tools maintenance typical for that pe-
riod (expressed in time, operation hours or otherwise).
• The product warranty relies on the correct use, maintenance, and repair of
the tool and its component parts.
• Damage to parts that occurs as a result of inadequate maintenance or per-
formed by parties other than Atlas Copco or their Certified Service Partners
during the warranty period is not covered by the warranty.
• To avoid damage or destruction of tool parts, service the tool according to
the recommended maintenance schedules and follow the correct instruc-
tions.
• Warranty repairs are only performed in Atlas Copco workshops or by Certi-
fied Service Partners.
Atlas Copco offers extended warranty and state of the art preventive mainte-
nance through its ToolCover contracts. For further information contact your lo-
cal Service representative.
Product information EN P2550
4© Atlas Copco Industrial Technique AB - 9839 0711 01
For electrical motors:
• Warranty will only apply when the electric motor has not been opened.
ServAid
ServAid is a portal that contains the most up-to-date product information such
as:
- Safety Information
- Installation, Operation and Service Instructions
- Exploded views
It is also possible to order spare parts, service tools and accessories for the
product of your choice directly from ServAid. It is continuously updated with
information about new and redesigned products.
If translations exist, you can view content in the language of your choice. Ser-
vAid offers advanced search functionality of our entire product range and can
also be used to display information about obsolete products.
ServAid is available on DVD and on the website:
https://servaid.atlascopco.com
For further information contact your Atlas Copco sales representative or e-mail
us at:
Website
Log in to Atlas Copco: www.atlascopco.com.
You can find information concerning our products, accessories, spare parts and
published matters on our website.
Safety Data Sheets MSDS/SDS
The safety data sheets describes chemical products sold by Atlas Copco.
For more information, consult the website:
www.atlascopco.com
Choose Products - Safety Data Sheets, and follow the instructions on the
page.
Country of origin
Please refer to the information on the product label.
Dimensional drawings
For information about the dimensions of a product, see the Dimensional draw-
ings archive:
http://webbox.atlascopco.com/webbox/dimdrw
Service overview
Service recommendations
Preventive maintenance is recommended at regular intervals. See the detailed
information on preventive maintenance. If the product is not working properly,
take it out of service and inspect it.
P2550 EN Product information
© Atlas Copco Industrial Technique AB - 9839 0711 01 5
If no detailed information about preventive maintenance is included, follow
these general guidelines:
• Clean appropriate parts accurately
• Replace any defective or worn parts
Installation EN P2550
6© Atlas Copco Industrial Technique AB - 9839 0711 01
Installation
Installation requirements
Air quality
• For optimum performance and maximum product life we recommend the
use of compressed air with a maximum dew point of +10°C (50°F). We also
recommend to install an Atlas Copco refrigeration type air dryer.
• Use a separate air filter which removes solid particles larger than 30 mi-
crons and more than 90% of liquid water. Install the filter as close as possi-
ble to the product and prior to any other air preparation units to avoid pres-
sure drop.
Make sure that the hose and couplings are clean and free from dust before
connecting to the tool.
Both lubricated and lubrication free products will benefit from a small
quantity of oil supplied from a lubricator.
Air lubrication guide
Brand Air lubrication
Atlas Copco Optimizer (1 liter) 9090 0000 04
Q8 Chopin 46
Shell Shell Air Tool Oil S2 A 320
Compressed air connection
WARNING Compressed air can cause serious injury
►Always shut off the air supply, drain hose of air pressure and disconnect
the tool from air supply; when not in use, before making any adjustments
to the product - for example changing accessories, or when making re-
pairs.
WARNING Whipping hoses can cause serious injury
►Always make sure that there are no damaged or loose hoses or fittings.
WARNING Compressed Air
High air pressure can cause severe damage and injury.
►Do not exceed maximum air pressure.
For correct air pressure and hose size, see section Technical data.
Make sure that the hose and couplings are clean and free from dust before
connecting to the tool.
Installation instructions
Installation of vibrating tools
It is recommended that a minimum length of 300 mm (12") of flexible hose for
compressed air is inserted between a vibrating tool and the quick-action cou-
pling.
P2550 EN Operation
© Atlas Copco Industrial Technique AB - 9839 0711 01 7
Operation
Ergonomic guidelines
Consider your workstation as you read through this list of general ergonomic
guidelines and see if you can identify areas for improvement in posture, compo-
nent placement, or work environment.
• Take frequent breaks and change work positions frequently.
• Adapt the workstation area to your needs and the work task.
• Adjust for convenient reach range by determining where parts or tools
should be located to avoid static load.
• Use workstation equipment such as tables and chairs appropriate for the
work task.
• Avoid work positions above shoulder level or with static holding during as-
sembly operations.
• When working above shoulder level, reduce the load on the static mus-
cles by reducing the weight of the tool, using for example torque arms,
hose reels or weight balancers. You can also reduce the load on the static
muscles by holding the tool close to the body.
• Make sure to take frequent breaks.
• Avoid extreme arm or wrist postures, particularly for operations requir-
ing a degree of force.
• Adjust for convenient field of vision by minimizing movement of the eyes
and head during the work task.
• Use the appropriate lighting for the work task.
• Select the appropriate tool for the work task.
• Use ear protection equipment in noisy environments.
• Use high-quality inserted tools or consumables to minimize exposure to ex-
cessive levels of vibration.
• Minimize exposure to reaction forces.
• When cutting:
A cut-off wheel can get stuck if the wheel is either bent or if it is not
guided properly. Make sure to use the correct flanges for cut-off wheels
and avoid bending the wheel during cut-off operation.
• When drilling:
The drill might stall when the drill bit breaks through. Makes sure you
use support handles if the stall torque is too high. The safety standard
ISO11148 part 3 recommends using something to absorb the reaction
torque above 10 Nm for pistol grip tools and 4 Nm for straight tools.
• When using direct-driven screw or nutrunners:
Reaction forces depend on tool setting and joint characteristics. The abil-
ity to bear reaction forces depends on the operator’s strength and pos-
ture. Adapt the torque setting to the operator's strength and posture and
use a torque arm or reaction bar if the torque is too high.
• Use dust extraction system or mouth protection mask in dusty environments.
Service EN P2550
8© Atlas Copco Industrial Technique AB - 9839 0711 01
Service
Maintenance instructions
Overhaul and lubrication
If the tool is normally used as a heavy-duty tool it should be dismantled, over-
hauled and cleaned after 120 hours in operation. If the tool is not operating cor-
rectly, it should be taken out of service for inspection. Use lubricants of good
quality. The air motor oils and greases mentioned in the grease guide are exam-
ples of lubricants which are recommended.
At the overhaul, do the following:
• Inspect all disassembled parts for wear.
• Replace the cylinder ball and all the o-rings.
• Clean the dismantled parts with highly refined paraffin.
• Lubricate sliding parts before assembly.
NOTICE Risk of Cylinder Ball Damage
A metallic cylinder ball will damage the cylinder valve seat and piston valve
pin.
►Do not replace the plastic cylinder ball with a metallic version.
Lubrication instructions
Rust protection and cleaning
Water in the compressed air can cause rust. To prevent rust we strongly recom-
mend to install an air dryer.
Water and particles can cause sticking of vanes and valves. This can be pre-
vented by installing an air filter close to the product to avoid pressure drop.
Before longer standstills always protect your tool by adding a few drops of oil
into the air inlet. Run the tool for 5–10 seconds and absorb any access oil at the
air outlet in a cloth.
NOTICE Do not try to clear the air path using sharp tools.
The air inlet is equipped with a strainer. If this is punctured, foreign objects
may harm the valves, resulting in overspeed.
Lubricating guide
Use lubricants of good quality. The oils and greases listed in the lubrication ta-
ble are examples of lubricants that can be recommended.
Brand
General purpose
Bearings
BP Energrease LS-EP2
Castrol Spheerol EP L2
Esso Beacon EP2
Q8 Rembrandt EP2
Mobil Mobilegrease XHP 222
Shell Alvania EP2
Texaco Multifak EP2
P2550 EN Service
© Atlas Copco Industrial Technique AB - 9839 0711 01 9
Brand
General purpose
Bearings
Molycote BR2 Plus
Recycling EN P2550
10 © Atlas Copco Industrial Technique AB - 9839 0711 01
Recycling
Recycling instruction
When a product has served its purpose it has to be recycled properly. Dismantle
the product and recycle the components in accordance with local legislation.
Batteries shall be taken care of by your national battery recovery organization.
Este manual sirve para los siguientes modelos
1
Tabla de contenidos
Otros manuales de Herramientas de Atlas Copco
Atlas Copco
Atlas Copco P2541 Manual de usuario
Atlas Copco
Atlas Copco TEX 05P Manual de usuario
Atlas Copco
Atlas Copco RRF 21-01 Hoja de instrucciones
Atlas Copco
Atlas Copco P2530-R Manual de usuario
Atlas Copco
Atlas Copco 4220 4522 82 Hoja de instrucciones
Atlas Copco
Atlas Copco Tensor STB Manual de usuario
Atlas Copco
Atlas Copco SMC-50-2100-POSI-L Hoja de instrucciones
Atlas Copco
Atlas Copco LH804 Guía de mantenimiento y servicio
Atlas Copco
Atlas Copco RBU Manual de usuario
Atlas Copco
Atlas Copco ETP TBP131-150-13 Manual de usuario
Atlas Copco
Atlas Copco TEX P Especificaciones
Atlas Copco
Atlas Copco SMC-100-1600 Hoja de instrucciones
Atlas Copco
Atlas Copco PHE 20 Guía de configuración
Atlas Copco
Atlas Copco PRO P2520 Manual de usuario
Atlas Copco
Atlas Copco P2530-H Instrucciones originales
Atlas Copco
Atlas Copco P2535-H Manual de usuario
Atlas Copco
Atlas Copco SMC 100 2100 POSI 3 Hoja de instrucciones
Atlas Copco
Atlas Copco RRD37 Hoja de instrucciones
Atlas Copco
Atlas Copco FlexiROC T20 R Manual de usuario
Atlas Copco
Atlas Copco PRO P2535-H Hoja de instrucciones
