Atlantis Land A07-VR-200 Manual de usuario

Security Gateway

Edge-Core

ISO 9001:2000 Company Certied

VR-200 VPN Router

• Up to 200 VPNs

• Firewall with Stateful Packet Inspection (SPI)

• QoS Management

• High performances for enterprise solution

A07-VR-200 is a 16-poesrt Multi-WAN VPN Router which contains 2 WAN ports

and 2 congurable WAN/LAN ports, 11 dedicated Ethernet 10/100 LAN ports and

1 dedicated DMZ port and mainly supports small and medium size enterprise bu-

siness networks with a high security VPN. Through the 2 congurable WAN/LAN

ports, the VR-200 can provide up to 4 WAN ports (11 LAN, 4 WAN and 1 DMZ

ports) or up to 13 LAN ports (13 LAN, 2 WAN and 1 DMZ ports). It brings high-

speed network security to enterprise businesses, remote users, service providers,

and data centers. Its design combines rewall, VPN support, NAT, and powerful

trafc management with Fast Ethernet connections to provide consistent network

infrastructure security. The unique congurable WAN/LAN ports allow users to con-

gure as WAN port or LAN port for providing tremendous exibility. In addition, with

multi-WAN ports, the device can have backup WAN interfaces.

A07-VR-200

PRODUCT:

CODE:

EAN CODE:

Security Gateway

Edge-Core

Subject to change without notice

A07-VR-200_SE_067

AtlAntis lAnd S.p.A. - Viale De Gasperi 122

20017 Mazzo di Rho - Milano - ITALY

Phone: +39 - (0)2 - 93.90.60.85 Fax: +39 - (0)2 - 93.90.61.61

Web: www.atlantis-land.com

E-Mail: info@atlantis-land.com

VR-200 VPN Router

A07-VR-200

8026974008554

TECHNICAL FEATURES

Physical Configuration

11-13 x 10/100 Ports (RJ-45)

Up to 4 x 10/100 Internet Port (RJ-45)

1 x 10/100 DMZ Port (RJ-45)

FLASH: 16 MB

SDRAM: 64 MB

Firewall Security

Firewall Throughput

IP Filtering

Port Filtering (TCP/UDP)

Denial of Service (DoS)

Stateful Packet Inspection (SPI)

Firewall Detection

VPN Support

IPSec VPN

VPN Throughput: 68 Mbps

VPN Tunnels: 200

Group VPNs: 2

VPN Tunnel Management

IKE: Pre-Shared keys

IPSec Encryption: DES/3DES

IPSec Authentication: MD5/SHA1

PMTU

View Log

WAN

Type: Multi-WAN

Load Balance: Intelligent

CoS (Class of Service) by IP Group

Network Service Detection

Protocol Binding

Networking

Concurrent Sessions: 70000

DMZ

DHCP Client/Server,dynamic IP, static IP

TCP/IP

IP Routing

PPPoE

NAT (ALG, port forwarding and port tigger)

DNS (Relay/DDNS)

ARP

ICMP

FTP/TFTP

Password for web access

Network Management

Web based management

SNMP v1/ v2c

Firmware upgrade through Web browser

Logging and Alarms of system activities

QoS (Quality of service)

Guaratee/Minimum bandwidth

Maximum bandwidth

Priority for certain Service

Port-based QoS

VR-200 VPN Router
