ATI Technologies X1650 - AMD Radeon XT 256MB PCI-E Graphics... Manual de usuario

Radeon®X1650

GTO

User’s Guide

P/N 137-41163-10

ATI, the ATI logo, and ATI product and product-feature names are trademarks and/or registered

trademarks of ATI Technologies Inc. All other company and/or product names are trademarks and/or

registeredtrademarksoftheirrespectiveowners.Features,performanceand specificationsaresubject

to change without notice. Product may not be exactly as shown in diagrams.

Reproductionofthismanual,orpartsthereof,in anyform,withouttheexpresswritten permissionofATI

Technologies Inc. is strictly prohibited.

Disclaimer

While every precaution has been taken in the preparation of this document, ATI Technologies Inc.

assumes no liability with respect to the operation or use of ATI hardware, software or other products

and documentation described herein, for any act or omission of ATI concerning such products or this

documentation, for any interruption of service, loss or interruption of business, loss ofanticipatory

profits, or for punitive,incidental or consequential damages in connection with the furnishing,

performance, or use of the ATI hardware, software, or other products and documentation provided

herein.

ATI Technologies Inc. reserves the right to make changes without further notice to a product or system

described herein to improve reliability, function or design. With respect to ATI products which this

document relates, ATI disclaims all express or implied warranties regarding such products, including

but not limited to, the implied warranties of merchantability, fitness for a particular purpose, and non-

infringement.

Macrovision

Apparatus Claims of U.S. Patent Nos.4,631,603; 4,819,098; 4,907,093; and 6,516,132 licensed for

limited viewing uses only.

This product incorporates copyright protection technology that is protected by US patents and other

intellectual property rights. Use of this copyright protection technology must be authorized by

Macrovision,and isintended forhome andother limited viewing uses only unlessotherwiseauthorized

by Macrovision. Reverse engineering or disassembly is prohibited.

Documentation Updates

ATI is constantly improving its product and associated documentation. To maximize the value of your

ATI product,you should ensure that you have the latest documentation. ATI’s documentation contains

helpful installation/configuration tips and other valuable feature information.

iii

Note: This graphics card is for use only with compatible UL Listed

personal computers that have Installation Instructions detailing user

installation of card cage accessories.

LIMPORTANT SAFETY INSTRUCTIONS

•Read Instructions - All the safety and operating instructions should

be read before the product is operated.

•Retain Instructions - The safety and operating instructions should be

retained for future reference.

•Heed Warnings - All warnings on the product and the operating

instructions should be adhered to.

•Compatibility - This option card is for use only with IBM AT or

compatible UL Listed personal computers that have Installation

Instructions detailing user installation of card cage accessories.

•Grounding - For continued protection against risk of electric shock

and fire, this accessory should be installed only in products equipped

with a three-wire grounding plug, a plug having a third (grounding) pin.

This plug will only fit into a grounding-type power outlet. This is a

safety feature. If you are unable to insert the plug into the outlet,

contact your electrician to replace the obsolete outlet. Do not defeat

the safety purpose of the grounding-type plug.

•Secure Attachment - All card securement pins shall be completely

tightened as to provide continuous bonding between the option card

and the PC chassis.

•Lightning - For added protection for this product during a lightning

storm, or when it is left unattended and unused for long periods of

time, unplug it from the wall outlet, and disconnect the antenna or

cable system. This will prevent damage to the product due to lightning

and power-line surges.

•Power Lines - An outside antenna system should not be located in

the vicinity of overhead power lines or other light or power circuits, or

where it can fall into such power lines or circuits.

•Antenna Installation - When installing an outside antenna system,

extreme care should be taken to keep from touching such power lines

or circuits, as contact with them may be fatal.

Table of Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Radeon®X1650 GTO Features 1

System Requirements 3

Using Multiple Displays . . . . . . . . . . . . . . . . . . . . . 5

Catalyst™Control Center . . . . . . . . . . . . . . . . . . . . 9

Launching Catalyst™Control Center 9

Catalyst™Control Center Dashboard 11

Catalyst™Control Center Views 12

Hotkeys Manager 13

Profiles Manager 15

Preferences 17

Help 19

Information Center 20

Displays Manager 22

Display Options 27

Monitor Properties 31

Monitor Attributes 32

Digital Panel Properties 33

Attributes 34

HDTV Support 37

3D 39

Standard Settings 40

Anti-aliasing 42

Adaptive Anti-aliasing 44

Anisotropic Filtering 44

Catalyst™A.I. 46

Mipmap Detail Level 48

All Settings 50

API Specific 53

Color 55

Color Desktop 56

Color - FullScreen 3D 59

Avivo™ Video 61

Standard Settings 62

Video Overlay Theater Mode 64

Deinterlacing 66

All Settings 67

VPU Recover 71

Using TV Display and Capture Features . . . . . . . 75

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

Radeon®X1650 GTO Features 1

CHAPTER 1:

Introduction

Congratulations on the purchase of your ATI Radeon®X1650 GTO

graphics card. We hope that you will enjoy countless hours of trouble-free

computing.

Radeon®X1650 GTO Features

Features

• HDMI™and VGA output.

• 256MB of DDR2 memory.

• PCI Express®X16 bus interface.

Ultra-Threaded Shader Engine

• Support for Microsoft ® DirectX®9.0 Shader Model 3.0

programmable vertex and pixel shaders in hardware.

• Full speed 128-bit floating point processing.

• Dedicated branch execution units for high performance dynamic

branching and flow control.

• Dedicated texture address units for improved efficiency.

• 3Dc+ texture compression

• High quality 4:1 compression for normal maps and two-channel

data formats.

• High quality 2:1 compression for luminance maps and single-

channel data formats.

• Multiple Render Target (MRT) support.

• Render-to-vertex buffer support.

• Complete feature set also supported in OpenGL®2.0

2 Radeon®X1650 GTO Features

Advanced Image Quality Features

• 64-bit floating point HDR rendering supported throughout the

pipeline.

• Includes support for blending and multi-sample anti-aliasing.

• 32-bit integer HDR (10:10:10:2) format supported throughout the

pipeline.

• Includes support for blending and multi-sample anti-aliasing.

• 2x/4x/6x Anti-Aliasing modes.

• Multi-sample algorithm with gamma correction, programmable

sparse sample patterns, and centroid sampling.

• New Adaptive Anti-Aliasing feature with Performance and

Quality modes.

• Temporal Anti-Aliasing mode.

• Lossless Color Compression (up to 6:1) at all resolutions,

including widescreen HDTV resolutions.

• 2x/4x/8x/16x Anisotropic Filtering modes.

• Up to 128-tap texture filtering.

• Adaptive algorithm with Performance and Quality options.

• High resolution texture support (up to 4k x 4k).

Avivo™ Video and Display Platform

• High performance programmable video processor.

• Accelerated MPEG-2, MPEG-4, DivX, WMV9, VC-1, and

H.264 decoding and transcoding.

• DXVA support.

• De-blocking and noise reduction filtering.

• Motion compensation, IDCT, DCT and color space conversion.

• Vector adaptive per-pixel de-interlacing.

• 3:2 pulldown (frame rate conversion).

• Seamless integration of pixel shaders with video in real time.

• HDR tone mapping acceleration.

• Maps any input format to 10 bit per channel output.

• Flexible display support.

• Dual integrated 10 bit per channel 400 MHz DACs.

• 16 bit per channel floating point HDR and 10 bit per channel

DVI output.

• Programmable piecewise linear gamma correction, color

correction, and color space conversion (10 bits per color).

System Requirements 3

• Complete, independent color controls and video overlays for

each display.

• High quality pre- and post-scaling engines, with underscan

support for all outputs.

• Content-adaptive de-flicker filtering for interlaced displays.

• Xilleon™ TV encoder for high quality analog output.

• Spatial/temporal dithering enables 10-bit color quality on 8-bit

and 6-bit displays.

• Fast, glitch-free mode switching.

• VGA mode support on all outputs.

• Drive two displays simultaneously with independent resolutions

and refresh rates.

• Compatible with ATI TV/Video encoder products, including

Theater 550.

System Requirements

External Connections

• 15-pin D-shell (female) VGA output.

• HDMI™output.

Operating

System •Windows

® XP with Service Pack 2 (SP2).

•Windows

® XP Professional x64 Edition.

•Windows

® XP Media Center Edition.

Monitor • High-resolution MultiSync or multi-frequency monitors

or any other type of VGA monitor.

• Digital flat-panel (DFP) displays capable of HDMI™

input.

4 System Requirements
