ATI Technologies RADEON X1950 XTX Manual de usuario

ATI

Radeon

X1950 XTX

User’s Guide

P/N 137-41074-10

ATI, the ATI logo, and ATI product and product-feature names are trademarks and/or registered

trademarks of ATI Technologies Inc. All other company and/or product names are trademarks and/or

registeredtrademarksoftheirrespective owners.Features,performanceandspecificationsaresubject

to change without notice. Product may not be exactly as shown in diagrams.

Reproductionofthismanual,orpartsthereof,inanyform,withouttheexpresswrittenpermissionofATI

Technologies Inc. is strictly prohibited.

Disclaimer

While every precaution has been taken in the preparation of this document, ATI Technologies Inc.

assumes no liability with respect to the operation or use of ATI hardware, software or other products

and documentation described herein, for any act or omission of ATI concerning such products or this

documentation, for any interruption of service, loss or interruption of business, loss ofanticipatory

profits, or for punitive,incidental or consequential damages in connection with the furnishing,

performance, or use of the ATI hardware, software, or other products and documentation provided

herein.

ATI Technologies Inc. reserves the right to make changes without further notice to a productor system

described herein to improve reliability, function or design. With respect to ATI products which this

document relates, ATI disclaims all express or implied warranties regarding such products, including

but not limited to, the implied warranties of merchantability, fitness for a particular purpose, and non-

infringement.

Macrovision

Apparatus Claims of U.S. Patent Nos.4,631,603; 4,819,098; 4,907,093; and 6,516,132 licensed for

limited viewing uses only.

This product incorporates copyright protection technology that is protected by US patents and other

intellectual property rights. Use of this copyright protection technology must be authorized by

Macrovision,andisintendedfor home andother limited viewing uses only unlessotherwiseauthorized

by Macrovision. Reverse engineering or disassembly is prohibited.

iii

Note: This graphics card is for use only with compatible UL Listed

personal computers that have Installation Instructions detailing user

installation of card cage accessories.

LIMPORTANT SAFETY INSTRUCTIONS

•Read Instructions - All the safety and operating instructions should

be read before the product is operated.

•Retain Instructions - The safety and operating instructions should be

retained for future reference.

•Heed Warnings - All warnings on the product and the operating

instructions should be adhered to.

•Compatibility - This option card is for use only with IBM AT or

compatible UL Listed personal computers that have Installation

Instructions detailing user installation of card cage accessories.

•Grounding - For continued protection against risk of electric shock

and fire, this accessory should be installed only in products equipped

with a three-wire grounding plug, a plug having a third (grounding) pin.

This plug will only fit into a grounding-type power outlet. This is a

safety feature. If you are unable to insert the plug into the outlet,

contact your electrician to replace the obsolete outlet. Do not defeat

the safety purpose of the grounding-type plug.

•Secure Attachment - All card securement pins shall be completely

tightened as to provide continuous bonding between the option card

and the PC chassis.

•Lightning - For added protection for this product during a lightning

storm, or when it is left unattended and unused for long periods of

time, unplug it from the wall outlet, and disconnect the antenna or

cable system. This will prevent damage to the product due to lightning

and power-line surges.

•Power Lines - An outside antenna system should not be located in

the vicinity of overhead power lines or other light or power circuits, or

where it can fall into such power lines or circuits.

•Antenna Installation - When installing an outside antenna system,

extreme care should be taken to keep from touching such power lines

or circuits, as contact with them may be fatal.

Table of Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Radeon® X1950 XTX Features 1

Before You Begin 4

Installing Hardware . . . . . . . . . . . . . . . . . . . . . . . . . 7

Connecting Devices 9

Using Multiple Displays . . . . . . . . . . . . . . . . . . . . 11

Connecting Your Monitors 11

Display Configurations 13

Installing Software and Drivers . . . . . . . . . . . . . . 15

Installing Drivers and Software in Windows®15

Monitor Configuration 16

To set up a multi-monitor display 17

Reinstalling Drivers 17

Installing the Catalyst™Software Suite 18

Catalyst™Control Center . . . . . . . . . . . . . . . . . . . 21

Help 21

Displays Manager 21

Video 22

Display Options 22

Color 23

Monitor Properties 23

CrossFire™23

Component Video Properties 24

Digital Panel Properties 24

Hotkeys Manager 25

Profiles Manager 25

Preferences 25

CrossFire™26

Profiles Manager 27

Using TV Display and Capture Features . . . . . . . 29

Using TV Out 29

Connecting to HDTV 31

Using the Radeon® X1950 XTX

with CrossFire™. . . . . . . . . . . . . . . . . . . . . . . . . . . 35

CrossFire™Overview 35

CrossFire™Rendering Modes 35

Super Anti-aliasing Mode 39

CrossFire™FAQ. . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Troubleshooting 49

Product Registration 53

Customer Care 53

Additional Accessories 55

Compliance Information 55

Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Radeon® X1950 XTX Features 1

CHAPTER 1:

Introduction

Congratulations on the purchase of your ATI Radeon® X1950 XTX

graphics card. We hope that you will enjoy countless hours of trouble-free

computing.

Radeon® X1950 XTX Features

Graphic Features

• Native PCI Express®X16 bus support.

• 256MB or 512 MB GDDR4\GDDR3 on-board memory.

• Full support for Microsoft ® DirectX®Shader Model 3.0.

• High performance Ultra-Threaded shader engine.

• Eight vertex shader processors.

• Forty-eight pixel shader processors.

• 512-bit internal ring-bus memory controller.

• 256-bit 8-channel memory interface.

• Native PCI Express®x16 bus interface.

SmoothVision™

• Full-scene anti-aliasing method that smooths uneven edges and

improves blurred images.

• 2x/4x/6x Anti-aliasing modes with a loss-less compression up to a

ratio of 6:1 at all resolutions.

• 2x/4x//8x/16x Anisotropic Filtering modes with up to 128-tap

texture filtering.

HyperZ™

• Ensures optimal hardware performance by discarding irrelevant

object data that is not visible to the user.

2 Radeon® X1950 XTX Features

• Conserves video memory bandwidth.

• Loss-less Z-buffer compression

• Z Cache optimized for real-time shadow rendering.

VideoShader™

• Seamlessly integrates pixel shaders with video in real time.

• All format DTV/HDTV decoding.

• Adaptive Per-Pixel- De-interlacing and Frame Rate Conversion.

512-bit Ring Bus Memory Controller

• Programmable intelligent arbitration logic.

• New fully associative texture, color, and Z/stencil cache designs.

• Hierarchal Z-buffer with Early Z test.

• Lossless Z Compression (up to 48.1)

• Fast Z-Buffer Clear.

• Z Cache optimized for real-time shadow rendering.

• Optimized for performance at high display resolutions, including

widescreen HDTV resolutions.

Ultra-Threaded Shader Engine

• Support for Microsoft ® DirectX®9.0 Shader Model 3.0

programmable vertex and pixel shaders in hardware.

• Full speed 128-bit floating point processing.

• Up to 512 simultaneous pixel threads.

• Dedicated branch execution units for high performance dynamic

branching and flow control.

• Dedicated texture address units for improved efficiency.

• High resolution texture support (up to 4k x 4k).

• Up to 1,536 instructions per rendering pass.

• 3Dc+ texture compression

• High quality 4:1 compression for normal maps and luminance

maps.

• Works with any single-channel or two-channel data format.

• Multiple Render Target (MRT) support.

Radeon® X1950 XTX Features 3

• Render-to-vertex buffer support.

• Complete feature set also supported in OpenGL®2.0

High Dynamic Range (HDR) Rendering

• 64-bit floating point HDR supported throughout the pipeline

• Includes support for blending and multi-sample anti-aliasing.

• High precision 10:10:10:2 integer format support.

• Includes support for blending and multi-sample anti-aliasing.

• 2x/4x/6x Anti-Aliasing modes

• Sparse multi-sample algorithm with gamma correction,

programmable sample patterns, and centroid sampling.

• New Adaptive Anti-Aliasing modes.

• Temporal Anti-Aliasing mode.

• Lossless Color Compression (up to 6:1) at all resolutions,

including widescreen HDTV resolutions.

• 2x/4x/8x/16x Anisotropic Filtering modes

• Up to 128-tap texture filtering.

• Adaptive algorithm with performance and quality options.

4 Before You Begin

System Requirements

Before You Begin

Before you begin installing your new graphics card, please do the

following.

Hardware • Intel® Pentium® 4 or AMD Athlon®.

• 512MB of system memory; 1GB or more for best

performance.

• Optical drive for installation software (CD-ROM or

DVD-ROM drive).

• Specialized PCI Express® 550 watt or greater power

supply recommended. Consult your computer system

manual to ensure the power supply is designed to

accommodate a high-end graphics card with a peak

dissipation above 75 watts.

Operating

System • Windows® XP with Service Pack 2 (SP2).

• Windows® XP Professional x64 Edition.

• Windows® 2000.

•Windows®Vista.

Monitor • High-resolution MultiSync or multi-frequency monitors

or any other type of VGA monitor.

• Digital flat-panel (DFP) displays or digital CRT display.

CrossFire™

Compatibility If you are planning on using this graphics card as part of a

CrossFire™ system, the following is required:

• A CrossFire™ certified motherboard with two (2) PCI

Express® X16 slots and correct PCIe™ chipset driver.

(See ati.com/crossfire for a list of CrossFire™

certified motherboards.)

• a CrossFire™ Edition graphics card from the same

product series that works as the Master graphics card.

More information on the requirements for each of these

components can be found within the CrossFire™ FAQ.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Tarjeta de video de ATI Technologies

ATI Technologies

ATI Technologies All-in-Wonder X800 PCI Express Manual de usuario

ATI Technologies

ATI Technologies V7350 - 100-505143 FireGL 1GB 512-bit GDDR3 PCI Express Video... Manual de usuario

ATI Technologies

ATI Technologies 3D XPRESSION Manual de usuario

ATI Technologies

ATI Technologies 100-436012 - Radeon 9250 256MB 128-bit DDR PCI Video... Manual de usuario

ATI Technologies

ATI Technologies Radeon X300 Series Manual de usuario

ATI Technologies

ATI Technologies 9800PRO - 128MB Dell - Radeon AGP 8x Vga DVI Tv-out DDR... Instrucciones de montaje

ATI Technologies

ATI Technologies X1650 - AMD Radeon XT 256MB PCI-E Graphics... Manual de usuario

ATI Technologies

ATI Technologies Workstation x1000 Manual de usuario

ATI Technologies

ATI Technologies X800 - 100-435317 Radeon XT Mac Edition Manual de usuario

ATI Technologies

ATI Technologies X1900GT - Radeon 256MB Pcie Manual de usuario

ATI Technologies

ATI Technologies Radeon HD 3450 Manual de usuario

ATI Technologies

ATI Technologies HD3800 Series Manual de usuario

ATI Technologies

ATI Technologies Radeon X1950 Pro Manual de usuario

ATI Technologies

ATI Technologies 9550 - X Radeon 256MB Agp Manual de usuario

ATI Technologies

ATI Technologies X1800 - 100-435705 Radeon XT 512MB GDDR3 SDRAM PCI Express x16 Graphics... Manual de usuario

ATI Technologies

ATI Technologies ALL-IN-WONDER PRO Manual

ATI Technologies

ATI Technologies 3D XPRESSION Manual de usuario

ATI Technologies

ATI Technologies V7100 - 100-505090 FireGL 256MB GDDR3 SDRAM PCI Express x16 Graphics... Manual de usuario

ATI Technologies

ATI Technologies V3300 - Firegl Tm Pcie Manual de usuario

ATI Technologies

ATI Technologies FIRE GL1 Manual de usuario

ATI Technologies

ATI Technologies 9800XT - 100-505076 FireGL 256MB DDR SDRAM AGP 8x Graphics... Manual de usuario

ATI Technologies

ATI Technologies Radeon 9800 Series Manual de usuario

ATI Technologies

ATI Technologies X800XL - 100-435502 Radeon 256MB GDDR3 SDRAM PCI Express x16 Graphics... Manual de usuario

ATI Technologies

ATI Technologies AT-009 Series Manual de usuario

Manuales populares de Tarjeta de video de otras marcas

Gainward

Gainward GeForce GTX 690 4GB Manual de usuario

MSI

MSI N220GT series Manual de usuario

SIIG

SIIG aurora Manual de usuario

ClearSpeed

ClearSpeed ClearSpeed Advance e720 Manual de usuario

MSI

MSI R7850 series Manual de usuario

DVS

DVS Atomix HDMI Manual de usuario

Aztech

Aztech VGS3D-AGP Manual de usuario

Advoli

Advoli TB4 Standard Manual de usuario

ELSA

ELSA ERAZOR III LT Manual de usuario

Gigabyte

Gigabyte GV-R7500L Manual de usuario

Themis

Themis TGA-7000 PMC Manual de usuario

EMS

EMS XtremeRGB-Ex1 Manual de usuario

Nvidia

Nvidia Quadro Workstation Manual de usuario

Pioneer

Pioneer PDA-5003 Manual de usuario

QDI

QDI N2 Manual de usuario

NEC

NEC N8116-48 Manual de usuario

MSI

MSI R7770 PoweR Edition Manual de usuario

Gigabyte

Gigabyte GV-N68T256D Manual de usuario
