ATEN VS-201 Manual de usuario
VS-201
USER MANUAL
Video Auto Switch
vs201.fm Page 1 Thursday, June 12, 2008 10:42 AM
FCC Information
WARNING!!! This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instruction manual, may cause interference to radio communications.
This equipment has been tested and found to comply with the limits
for a Class A computing device pursuant to Subpart J of Part 15 of the
FCC Rules, which are designed to provide reasonable protection
against such interference when operated in a commercial
environment. Operation of this equipment in a residential area is likely
to cause interference, in which case the user, at his own expense, will
be required to take whatever measures may be required to correct the
interference.
vs201.fm Page 2 Thursday, June 12, 2008 10:42 AM
- 3 -
VS-201 User Manual
Package Contents
The VS-201 Video Auto Switch package contains the following
items:
1 VS-201 Video Splitter
1 DC 9V Power Adapter
1 User Manual*
Check to make sure that all the components are present and that
nothing got damaged in shipping. If you encounter a problem,
contact your dealer.
Read this manual thoroughly and follow the installation and
operation procedures carefully to prevent any damage to the unit,
and/or any of the devices connected to it.
*Features may have been added to the VS-201 since this
manual was printed. Please visit our website to download the
most up-to-date version of the manual.
Copyright © 1996–2008 ATEN® International Co., Ltd.
Manual Part No. PAPE-XXXX-XXXX
Manual Date: 2008-06-12
ATEN and the ATEN logo are trademarks of ATEN International Co., Ltd. All rights
reserved. All other trademarks are the property of their respective owners.
vs201.fm Page 3 Thursday, June 12, 2008 10:42 AM
- 4 -
Overview
The VS-201 Video Auto Switch is an automatic video switch that
is ideal for monitors using analog signals. In addition, the VS-201
boosts signals, allowing long distance transmission of up to 210
feet.
A slide switch sets the priority for the incoming video signals for
display on the monitor, and the VS-201 automatically selects the
proper input signal for its output port. Both features make the VS-
201 an excellent choice for educational environments.
Features
Suitable for SVGA, VGA and multisync monitors.
Switch setting to automatically select the incoming video
signal.
Extends video signals up to 210 feet (65M).
Daisy-chainable to VS-104 and VS-108 switches.
vs201.fm Page 4 Thursday, June 12, 2008 10:42 AM
- 5 -
Installation
1. Use a VGA cable with high density DB-15 Male/Female
connectors to connect the video output port of your Local
computer to the VS-201's Local port.
2. Use a VGA cable with high density DB-15 Male/Female
connectors to connect a remote video signal (from another
computer or another video switch) to the VS-201's Remote
port.
3. Plug your monitor's cable into the VS-201's Video Out port.
4. Power on the VS-201 by plugging in its AC adapter.
Example 1
Stand-Alone Connection - 2 Computers:
vs201.fm Page 5 Thursday, June 12, 2008 10:42 AM
- 6 -
Example 2
Daisy Chained to VS-104:
Example 3
Daisy Chained to two VS-104s:
vs201.fm Page 6 Thursday, June 12, 2008 10:42 AM
- 7 -
Operation
When the Slide Switch is set to Local:
Normally, the remote signal is sent to the output port. When
the local signal is detected, its LED illuminates and the VS-
201 automatically switches to transmit the local signal to the
output port.
When the Slide Switch is set to Remote
Normally, the local signal is sent to the output port. When the
remote signal is detected, its LED illuminates and the VS-201
automatically switches to transmit the remote signal to the
output port.
vs201.fm Page 7 Thursday, June 12, 2008 10:42 AM
- 8 -
Specifications
Function Specification
Power Consumption AC 9V, 100mA (max.)
Cable length (output) 65M (210 ft.) (max.)
Signal Type VGA, SVGA, Multisync
Video Input Connectors 2 x HDB-15 Male
Video Output Connectors 1 x HDB-15 Female
VGA Res/Vert Freq. 1920 x 1440 @80 Hz
Operating Temperature 5 - 40oC
Storage Temperature -20 - 60oC
Humidity 0 - 80% RH, Non-condensing
Housing Metal
Weight 0.165 kg
Dimensions (L x W x H) 10.4 x 9.8 x 2.4 (cm)
vs201.fm Page 8 Thursday, June 12, 2008 10:42 AM
- 9 -
Limited Warranty
IN NO EVENT SHALL THE DIRECT VENDOR'S LIABILITY EXCEED THE PRICE
PAID FOR THE PRODUCT FROM THE DIRECT, INDIRECT, SPECIAL,
INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE
OF THE PRODUCT, DISK OR ITS DOCUMENTATION.
The direct vendor makes no warranty or representation, expressed, implied, or
statutory with respect to the contents or use of this documentation, and specially
disclaims its quality, performance, merchantability, or fitness for any particular
purpose.
The direct vendor also reserves the right to revise or update the device or
documentation without obligation to notify any individual or entity of such revisions,
or update. For further inquires please contact your direct vendor.
