ATCOM AX-2G4A Manual de usuario
AX2G4A User Manual
ATCOM®GSM Card AX2G4A
User Manual
Version: 2.0
2013-06-03
AX2G4A User Manual
Release note
Version Changed note Editor Date
1.0 First Release Robert 2011-01-20
2.0 Release the User manual Deniel 2013-06-03
AX2G4A User Manual
Content
Contact ATCOM..................................................................................................................................1
Chapter 1 the Introduction of AX4G...................................................................................................1
Chapter 2 Hardware Introduction........................................................................................................3
Chapter 3 Test Environment................................................................................................................5
Chapter 4 Software Installation...........................................................................................................6
Chapter 5 Software Configuration...................................................................................................... 7
Chapter 6 Test....................................................................................................................................11
Chapter 7 Sending and Receiving SMS............................................................................................14
Chapter 8 Reference.......................................................................................................................... 16
AX2G4A User Manual
Contact ATCOM
The Introduction of ATCOM
ATCOM is the leading VoIP hardware manufacturer in global market. We have been keeping
innovating with customer’s needs oriented , working with partners to establish a total solution for
SMB VoIP with IP phone , IP PBX and Asterisk cards.
With over 10 years’ experience of R&D, manufacturing and service in network and VoIP filed;
mission of creating the biggest value for IP terminals, we commit ourselves in supplying the
competitive IP phone and other terminals for IP PBX, softswitch, IMS, NGN providers and
carriers; supplying the competitive total VoIP solution for SMB market. We keep improving the
customer’s experience and creating the bigger value with our reliable products. Until now , our
VoIP products has been sold to over 60 countries and used by millions of end users.
Contact sales:
Address District C, east of 2nd floor, #3, Crown industry buildings, Chegongmiao
Industry area, Futian district, Shenzhen, China
Tel +(86)755-23487618
Fax +(86)755-23485319
E-mail sales@atcomemail.com
Contact Technical Support:
Tel +(86)755-23481119
E-mail Support@atcomemail.com
Website address: http://www.atcom.cn/
Download Center: http://www.atcom.cn/download.html
AX2G4A User Manual
1
Chapter 1 the Introduction of AX2G4A
Overview of the AX-2G4A
AX-2G4A Asterisk card is a hybrid card, which support two GSM channels and 4 FXO/FXS
analog ports. Using AX-2G4A, open source Asterisk PBX and stand alone PC, users can create
their SOHO telephony solution which includes all the sophisticated features of traditional PBX,
and extended features in IP PBX, such as voicemail, call transfer, call park, call pick up, call
forward, bulk SMS sending, SMS receiving and so on.
Features
Two GSM channels and four analog ports
Bulk SMS sending
SMS receiving and storage
Multi-language for SMS content
IMEI changeable
PIN-Number unlock for the SIM card
Hardware echo cancellation embedded on the GSM module
Monitor GSM signal strength by command and LEDs
Monitor communication status by command line
Send SMS by Asterisk CLI, and dial-plan
Detect accurately when the called party answers the call
GSM quadband frequency(850/900/1800/1900MHz)
DTMF detection
Suitable for 3.3 volts and 5.0 volts 32 bit PCI slots
PCI slot or 4-pin connector for power feeding
Support Elastix 2.0.3, Trixbox 2.8.0.4
Applications
GSM and analog connectivity for PBX
Mobile and analog PBX
GSM and analog VoIP gateway
SMS gateway
GSM callback services
Billing system
AX2G4A User Manual
2
Hardware Requirement
500-Mhz Pentium III
64MB RAM
3.3V or 5V PCI 2.2 slot
Measurement and Weight
Inner box 221 * 142 * 62mm
G.W./unit 0.25kg
Card Size 174mm *104 mm
Package
Item Quantity
AX-2G4A mother board 1
GSM module (GX01) 1-2
Dual ports analog module 1-2
AX2G4A User Manual
3
Chapter 2 Hardware Introduction
GX01: GSM module, one GX01 supports one GSM channel.
AX210S: FXS module, it supports two FXS ports.
AX210X: FXO module, it supports two FXO ports.
Slot1: A slot for plugging GX01, it is the first channel of the card.
Slot2: A slot for plugging GX01, it is the second channel of the card.
Slot3: A slot for plugging FXS/FXO module, it is the third and fourth channels of the card.
Slot4: A slot for plugging FXS/FXO module, it is the fifth and sixth channels of the card.
CON1: 4 pin power connector.
SW100: Used for selecting the way of power feeding, set it to 1 ON and 2 OFF, the CON1 provide
s the power for the card; set it to 1 OFF and 2 ON, the PCI slot provides the power for the
card. If the FXS port is used, the card must be provided power by the CON1. To ensure
the enough power feeding, user should choose the CON1 to provide power for the card,
and the SW100 is set to 1 ON and 2 OFF by default.
Hole: used for fixing the line which connect the GX01 to antenna.
Antenna: the antenna in the picture above is omnidirectional, the model is TS01
Attention: In order to enhance the GSM signal in some hard environment, except the Antenna in
the illustration above, ATCOM can also provide one other type of antenna(TL01)
which has long cable(about one meter long) and can be connected to outside.
RJ45: Used for connecting a splitter to the card, the splitter supports four RJ11 ports and one RJ45
port.
LED3: Used for checking if the FXS/FXO module is detected or not. When the FXS/FXO ports
are detected correctly, the LED3 will be on.
AX2G4A User Manual
4
LED11: When the channel 1 is in communication status, LED11 will be green steady.
LED12: Network status indicator of SIM card of the first channel. When the SIM card is searching
network, the LED12 will blink fast; when the SIM card has found the GSM network and
registered successfully, the LED12 will flip at lower frequency.
LED21: When the channel 2 is in communication status, LED21 will be green steady.
LED22: Network status indicator of SIM card of the second channel. When the SIM card is
searching network, the LED22 will blink fast; when the SIM card has found the GSM
network and registered successfully, the LED22 will flip at lower frequency.
Button: used for turning off the GX01.
AX2G4A User Manual
5
Chapter 3 Test Environment
Test Environment:
dahdi-linux-complete-2.6.2+2.6.2 (download from ATCOM website)
asterisk-11.1.2 (download from ATCOM website)
Centos6.0 (kernel version: 2.6.18-348.3.1.el5)
AX-2G4A+2*GX01+1*AX210S+1*AX210X
AX2G4A User Manual
6
Chapter 4 Software Installation
After inserting the card into the PCI slot and boot your server, please use the “lspci” command to
check the PCI bus compatibility. From the correct output, you can see the following line:
----------------------------------------------------------------------------------------------------------------------
01:01.0 Communication controller: Tiger Jet Network Inc. Tiger3XX Modem/ISDN interface
----------------------------------------------------------------------------------------------------------------------
A Tiger Jet device will be found, if you can not see the Tiger Jet device, please poweroff your
server and try another PCI slot, if it still does not help, you have to check the compatibility issue
between the card and your PCI bus.
1. To install asterisk and dahdi, we have to use “yum” command to install the following
prerequisite packages:
yum install -y bison bison-devel zlib zlib-devel openssl openssl-devel gnutls-devel gcc
gcc-c++ libxml2 libxml2-devel ncurses ncurses-devel
yum install update
yum install bison openssl gcc libxml2 libxml2-dev ncurses-dev gawk
yum install sqlite3 libsqlite3-dev
2. Download the dahdi and asterisk packages from the link: http://www.atcom.cn/dl_ax4g.html
Attention: users need download dahdi and asterisk packages for ax4g/ax2g4a card from
ATCOM website.
3. Install dahdi-linux-complete package
1) [root@localhost src]# tar -xvzf dahdi-linux-complete-2.6.2+2.6.2.tar.gz
2) [root@localhost dahdi-linux-complete-2.6.2+2.6.2]# make
3) [root@localhost dahdi-linux-complete-2.6.2+2.6.2]# make install
4) [root@localhost dahdi-linux-complete-2.6.2+2.6.2]# make config
4. Install asterisk
1) [root@localhost src]# tar -xvzf asterisk-11.2.0.tar.gz
2) [root@localhost asterisk-11.2.0]# ./configure
3) [root@localhost asterisk-11.2.0]# make
4) [root@localhost asterisk-11.2.0]# make install
5) [root@localhost asterisk-11.2.0]# make samples
