AT&T TL80133 Manual de usuario

User’s manual

TL80133

Cordless Accessory Speakerphone

for use with many AT&T business

phones and AT&T CL, CRL, CLP, TL

and VTech DS, SN, IS series home

cordless phones

Congratulations

on your purchase of this AT&T product.

Be more mobile by using the AT&T TL80133 DECT 6.0 cordless

accessory speakerphone for everyday conversations. Plus, the

speakerphone fits easily in your hand or a pocket, making it

easy to stay connected as you go about your day. Enjoy a sound

that can keep up with your calls. Increase participation by

allowing both ends to speak

–

and to be heard

–

at the same time,

for conversations that are more true to life. With up to 500 feet

of range, you will experience the best in long-range coverage

and clarity.

Before using this AT&T product, please read Important safety

information on pages 30-33 of this manual. Please thoroughly

read this user’s manual for all the feature operations and

troubleshooting information necessary to install and operate

your new AT&T product. You can also visit our website at

www.telephones.att.com or call 1 (800) 222-3111.

In Canada, dial 1 (866) 288-4268.

Visit www.telephones.att.com for a complete list of

phones that have been tested and found to be compatible with

the TL80133.

This telephone meets the California Energy Commission

regulations for energy consumption. Your telephone is set up to

comply with the energy-conserving standards right out of the

box. No further action is necessary.

Model number: TL80133

Type: Cordless Accessory Speakerphone

Serial number:

Purchase date:

Place of purchase:

Both the model and serial numbers of your AT&T product can be

found on the bottom of the speakerphone charger.

Save your sales receipt and original packaging in case it is

necessary to return your telephone for warranty service.

the AT&T logo are trademarks of AT&T Intellectual Property licensed to

Advanced American Telephones, San Antonio, TX 78219. Printed in China.

Parts checklist

Check to make sure the package includes the following items.

Save your sales receipt and original packaging in the event

warranty service is necessary.

Battery

compartment

cover

Power adapter

for speakerphone

charger

User's manual Cordless speakerphone

Battery for cordless

speakerphone

Speakerphone

charger

Battery Pack :

2.4V Ni-MH

WARNING :DO NOT BURN OR

PUNCTURE BATTERIES.

THISSIDE UP

User’s manual

TL80133

Cordless Accessory Speakerphone

for use with many AT&T business

phones and AT&T CL, CRL, CLP, TL

and VTech DS, SN, IS series home

cordless phones

User’s manual

TL80133

Cordless accessory speakerphone

for use with many AT&T business

phones and AT&T CL, CRL, CLP, TL

and VTech DS, SN, IS series home

cordless phones

Table of contents

Getting started

Installation...................................... 1

Charger installation.................... 2

Battery installation and

charging........................................ 3

Adding and registering a

speakerphone ............................ 5

to a telephone base............ 5

Replacing a speakerphone ..... 8

Deregister all

speakerphones....................... 8

Quick reference guide -

speakerphone ............................ 9

Speakerphone lights ..........10

Speakerphone alert

tones..........................................11

Speakerphone voice

prompts ....................................12

Operation

Speakerphone operation ........13

Make a call.............................. 13

Answer a call.........................13

End a call.................................13

Auto-off ....................................14

Speakerphone ringer .........15

Temporary ringer

silencing...................................15

Speakerphone paging .......16

Options while on calls.............17

Volume control .....................17

Mute ...........................................17

Flash/call waiting................ 18

Join a call in progress.......19

Intercom..........................................20

Intercom calls and

transfers ...................................20

Answer an incoming call

during an intercom call.... 21

Appendix

Troubleshooting ..........................22

Important safety

information.................................30

Safety information...............30

Especially about

cordless speakerphones... 31

Precautions for users

of implanted cardiac

pacemakers ............................33

Pacemaker patients............ 33

Maintenance..................................34

FCC, ACTA and IC

regulations .................................35

California Energy Commission

battery charging testing

instructions...................................40

Limited warranty.........................41

Technical specifications .......... 45

DECT 6.0 digital

technology..............................45

Operating range...................45

Simulated full-duplex

speakerphone........................45

Extended range and

clarity.........................................46

Index

Index.................................................47

Getting started

Installation

See pages 3-4 for

easy instructions.

You must install and

charge the battery before

using the speakerphone. STOP!

For customer service or product information, visit our website at

www.telephones.att.com or call 1 (800) 222-3111.

In Canada, dial 1 (866) 288-4268.

Getting started

Charger installation

Install the speakerphone charger as shown below.

Plug the small end of the

charger power adapter into

the power adapter jack on the

back of the charger.

Plug the large end of the

charger power adapter into a

power outlet not controlled by

a wall switch.

Route the power adapter cord

through this slot.

IMPORTANT INFORMATION

• Use only the power adapter provided with this product. To obtain aUse only the power adapter provided with this product. To obtain a

replacement, visit our website at www.telephones.att.com or

call 1 (800) 222-3111. In Canada, dial 1 (866) 288-4268.

• The power adapter is intended to be correctly oriented in a vertical orThe power adapter is intended to be correctly oriented in a vertical or

floor mount position. The prongs are not designed to hold the plug in

place if it is plugged into a ceiling, under-the-table or cabinet outlet.

Getting started

Battery installation and charging

Install the battery as shown below.

Battery Pack :

2.4V Ni-MH

WARNING :DO NOT BURN OR

PUNCTURE BATTERIES.

THISSIDE UP

Battery Pack :

2.4V Ni-MH

WARNING :DO NOT BURN OR

PUNCTURE BATTERIES.

THISSIDE UP

Plug the battery connector

securely into the socket inside

the speakerphone battery

compartment, matching the

color-coded label.

1. 2.

Insert the supplied battery

with the label THIS SIDE UP

facing up, as indicated.

3. Insert the tab on the bottom

of the battery compartment

cover into the battery

compartment, then press

down gently on the cover

until it snaps into place.

4. Charge the speakerphone

by placing it face upward in

the charger. The CHARGE

light on the speakerphone

turns red during charging.

CHARGE light

turns red

To replace the battery, push the tab and lift the

battery compartment cover up and off.

Lift out the old battery and disconnect it from

the speakerphone. Follow the instructions

above to install and charge the new battery.

Battery Pack :

2.4V Ni-MH

WARNING :DO NOT BURN OR

PUNCTURE BATTERIES.

THISSIDE UP

Getting started

IMPORTANT INFORMATION

• Use only the supplied rechargeable battery or replacement batteryUse only the supplied rechargeable battery or replacement battery

(model BT185742/BT285742). To order, visit our website at

www.telephones.att.com or call 1 (800) 222-3111.

In Canada, dial 1 (866) 288-4268.

• If you do not use the speakerphone for a long time, disconnect andIf you do not use the speakerphone for a long time, disconnect and

remove the battery to prevent possible leakage.

Battery installation and charging

Once you have installed the battery, the CHARGE light on the

speakerphone indicates the battery status (see the table below).

If necessary, place the speakerphone in the charger to charge

the battery. For optimal performance, keep the speakerphone in

the charger when not in use. The battery is fully charged after

11 hours of continuous charging. See Technical specifications on

page 45 for battery operating times.

NOTES:

If you are on a call in low battery mode, you hear a low battery alert tone

every 60 seconds.

If the battery is not properly installed or no battery is installed in the

speakerphone, when you place it in the charger, the CHARGE light is off.

Follow the instructions on page 3 to install the battery.

•

CHARGE light Battery status

Red: Flashes every 10 seconds. Battery has very little charge and needs

charging when the speakerphone is out

of the charger.

Red: Steadily on. Battery is charging.

Green: Steadily on. Battery is fully charged when the

speakerphone is in the charger.
