AT&T TL30100 Manual de usuario

User’s manual

TL30100

DECT 6.0 expansion handset

for use with AT&T models

TL32100/TL32200/TL32300

Audio assist™ is a trademark of Advanced American Telephones.

the AT&T logo are trademarks of AT&T Intellectual Property licensed to

Advanced American Telephones, San Antonio, TX 78219. Printed in China.

Congratulations

on purchasing your new AT&T product. Before using this AT&T

product, please thoroughly read this user’s manual for the

information necessary to install your new AT&T product. For

complete instructions, please refer to the manual provided with

your TL32100/TL32200/TL32300 telephone. For customer

service or product information, please visit our website at

www.telephones.att.com or call 1 (800) 222-3111. In

Canada, dial 1 (866) 288-4268.

The ENERGY STAR® program (www.energystar.gov) recognizes

and encourages the use of products that save energy and

help protect our environment. We are proud to mark this

product with the ENERGY STAR® label indicating it meets the

latest energy efficiency guidelines.

Telephones identified with this logo have reduced noise and

interference when used with most T-coil equipped hearing

aids and cochlear implants. The TIA-1083 Compliant Logo is

a trademark of the Telecommunications Industry Association.

Used under license.

Model #: TL30100

Type: DECT 6.0 expansion handset

Serial #:

Purchase date:

Place of purchase:

Both the model and serial number of your AT&T product can be

found on the bottom of the charger.

Parts checklist

Your telephone package contains the following items. Save

your sales receipt and original packaging in the event warranty

service is necessary.

Charger for cordless handset

with power adapter installed

Cordless handset

User’s manual

Battery compartment cover

Battery for cordless handset

User’s manual

TL30100

DECT 6.0 expansion handset

for use with AT&T models

TL32100/TL32200/TL32300

Table of contents

Getting started

Quick reference guide .................................2

Charger installation.......................................5

Battery installation and charging...........6

Battery installation.................................6

Battery charging......................................7

Adding the handset to your

telephone base

Adding and registering a handset .........9

About expansion handsets.................9

Registering a handset...........................9

Deregistering all handsets......................11

Appendix

Troubleshooting ...........................................13

Maintenance...................................................23

Important safety information ................24

Safety information ...............................24

Especially about cordless

telephones...............................................25

Precautions for users of implanted

cardiac pacemakers ............................26

Pacemaker patients ............................26

Especially about telephone

answering systems..............................26

FCC Part 68 and ACTA..............................27

FCC Part 15....................................................29

Limited warranty..........................................30

Technical specifications ...........................33

DECT 6.0 digital technology ...........33

Telephone operating range.............33

Your product may be shipped with a protective sticker covering

the handset - remove it before use.

For customer service or product information, visit our website at

www.telephones.att.com or call 1 (800) 222-3111. In

Canada, dial 1 (866) 288-4268.

Avoid placing the telephone base too close to:

Communication devices such as television sets, VCRs, or other

cordless telephones.

Excessive heat sources.

Noise sources such as a window with traffic outside, motors,

microwave ovens, refrigerators, or fluorescent lighting.

Excessive dust sources such as a workshop or garage.

Excessive moisture.

Extremely low temperature.

Mechanical vibration or shock such as on top of the washing

machine or work bench.

•

You must install and

charge the battery

before using the cordless

handset.

See pages 5 and 6 for

easy instructions.

Getting started

Quick reference guide

DIR/VOLUME

Press to scroll up while

in menus.

Press to increase the

listening volume.

Press to show directory

entries when the

handset is not in use.

While entering names or

numbers in the directory,

press to move the cursor

to the right.

REDIAL/PAUSE

Press repeatedly to view

the last 20 numbers

dialed.

While entering numbers,

press and hold to insert

a dialing pause.

PHONE/FLASH

Press to make or answer

a call.

During a call, press to

answer an incoming call

when you receive a call

waiting alert.

MENU/SELECT

Press to display the

menu.

Once in the menu, press

to select an item or save

an entry or setting.

OFF/CLEAR

During a call, press to

hang up.

While using menus,

press to cancel an

operation, back up to

the previous menu, or

exit the menu display.

Press and hold while the

handset is not in use to

erase the missed calls

indicator.

CID/VOLUME

Press to scroll down

while in menus.

Press to decrease the

listening volume.

Press to show the caller

ID history when the

handset is not in use.

While entering names or

numbers in the directory,

press to move the cursor

to the left.

Getting started

Audio assist™ is a trademark of Advanced American Telephones.

Quick reference guide

While entering names in

the directory, press to

add a space.

While reviewing a caller

ID history entry, press

repeatedly to add or

remove 1 in front of

the telephone number

before dialing or saving

it in the directory.

TONE

During a call, press to

send touch-tone signals

temporarily.

SPEAKER

Press to turn on the

handset speakerphone.

Press again to resume

normal handset use.

MUTE/REMOVE

During a call, press to

mute the microphone.

While predialing, press

to delete digits.

While reviewing the

redial list, directory,

speed dial list or caller

ID history, press to delete

an individual entry.

When reviewing a caller

ID history entry, press

repeatedly to view the

dialing options.

AUDIO ASSIST™

During a call, press to

enhance the clarity and

loudness of your caller’s

voice.

Getting started

Quick reference guide

EQUALIZER

During an outside call, intercom call, message

or announcement playback, press to change the

quality of the audio to best suit your hearing.

Using menus

Press MENU/SELECT to enter the main menu.

Press DIR or CID to scroll through menu items.

Press MENU/SELECT to select or modify an item.

Press OFF/CLEAR to cancel an operation, back

up to the previous menu, or exit the menu display.

Main menu

Play messages

Answering sys

Directory

Call log

Intercom

Ringers

Settings

Website

The > symbol indicates

the feature to select.

>Play messages

Answering sys

Getting started

Install the charger as shown below.

Charger installation

IMPORTANT INFORMATION:

Use only the power adapter provided with this product. To obtain a replacement,

visit our website at www.telephones.att.com or call

1 (800) 222-3111. In Canada, dial 1 (866) 288-4268.

Plug the large end of

the power adapter into

an electrical outlet not

controlled by a wall

switch.

Ensure the small end

of the power adapter is

plugged into the power

jack on the back of the

charger.

Route the cord through

the slot.

Getting started

Battery installation and charging

Battery installation

Install the battery as shown below.

IMPORTANT INFORMATION:

Use only the supplied rechargeable battery or replacement battery (model

BT166342). To order, visit our website at www.telephones.att.com,

or call 1 (800) 222-3111. In Canada, dial 1 (866) 288-4268.

To replace the battery, press the tab

and slide the battery compartment

cover downwards. Lift out the old

battery and disconnect it from the

handset. Follow the instructions above

to install and charge the new battery.

Plug the battery

connector securely

into the socket

inside the handset

battery compartment,

matching the color-

coded label.

1. Insert the supplied

battery with the label

THIS SIDE UP facing

up as indicated.

2. Align the cover flat

against the battery

compartment, then

slide it upwards until it

clicks into place.

Charge the handset by placing

it face up in the charger. The

CHARGE light is on when charging.

CHARGE light
