Asus WiMAX Manual de usuario

WiMAX

integrated broadband router

Quick Start Guide

QE4981 / August 2009

Inspiring Innovation · Persistent Perfection

Ethernet cable x 1

ASUS WiMAX

router x 1

Power adapter x 1

Quick Start Guide x 1

Check the package contents

Dimensions 155 mm x 42.6 mm x 225 mm (L x W x H)

Net weight 738 g

Operating temperature 0ºC ~ 40ºC

Power adapter Input: 100-240V ~ 50/60Hz 0.6A

Output: +12V 2A

Note: Contact your retailer if any of the above items is

damaged or missing.

Wired/cable connection

1. Connect one end of the bundled Ethernet cable into an

available LAN port on your ASUS WiMAX router.

2. Connect the other end of the Ethernet cable into your PC.

3. Connect the power cord into the power jack on your

ASUS WiMAX router.

4. Connect the power adapter into the electrical wall outlet.

5. Connect the phone cable into the phone port on your

ASUS WiMAX router.

Wi-Fi connection

The ASUS WiMAX integrated broadband router supports the

802.11b/g/n standard.

Set up your ASUS WiMAX router

RESET

EZSetup

LAN

PHONE2

PHONE1

PWR

Power

Wi-Fi

Phone

Electrical wall outlet

LAN

Connect to your WiMAX service provider

1. Launch your web browser and key in http://192.168.1.1

in the address bar.

          

graphics user interface (Web GUI), key in the default userkey in the default user

name (user) and password (user), then click OK.

3. On the home page of your ASUS WiMAX router's Web

GUI, key in the broadband user name and password,

then click Connect.

ASUS WiMAX router provides you with six LED indicators

which indicate signal strength. To get a strong signal, simply

move the router around, and use the signal LED as your guide.

The more signal LEDs that are lighting up, the stronger the

router signal is.

Note: As your router searches

for a signal, the signal LED

lights up from top to bottom. If

a signal is received, the signal

indicator stops blinking and

maintains a steady light.

When the signal LED indicators maintain steady light, you can



Verify your ASUS WiMAX router signal

Enjoy surng the Internet

Signal LED

Power LED

Wi-Fi LED
