ASUS Tablet User Manual
TF810C
E7492
ASUS is devoted to creating environment-friendly products/packagings
to safeguard consumers’ health while minimizing the impact on the en-
vironment. The reduction of the number of the manual pages complies
with the reduction of carbon emission.
For the detailed user manual and related information, refer to the user
manual included in the device or visit the ASUS Support Site at
http://support.asus.com/
Charging your battery pack
If you wish to use the battery power, ensure to fully charge your battery pack before
going on long trips. Remember that the power adapter charges the battery pack
as long as it is plugged to an AC power source. It takes much longer to charge the
battery pack when your device is in use.
Airplane precautions
Ask an airline personnel if you want to use your device onboard the aircraft. Most
airlines have restrictions in using electronic devices, and allow its use only when the
plane reaches its cruising altitude.
There are three types of airport security devices: X-ray scanner (for luggages placed
on conveyor belts), metal detectors (a walk-through security checking device), and
magnetic wands (hand-held devices for checking on passengers). You can send your
device through the X-ray scanner, but do not send your device through the metal
detectors or checked by magnetic wands.
ASUS Tablet Manual
2
Package Contents
• If any of the items is damaged or missing, contact your retailer.
• The bundled power plug varies with country or region.
ASUS Tablet USB charger USB Dock cable
User Manual
User manual USB Dongle Warranty card
User Guide
Cleaning cloth Sleeve Windows 8® User guide
ASUS Tablet Manual 3
Getting to know your ASUS Tablet
3
1
13
4
6
79
8
15
8
16
2
12
14
16
10
11
5
ASUS Tablet Manual
4
1Reset hole
If the system becomes unresponsive, insert a paper clip into the hole to
force-restart your device.
Forcing the system to restart may result to data loss. We strongly
recommend that you back up your data regularly.
2Power button
Press and hold the Power button to turn on your device.
When your device is on, press the Power button to put it in sleep mode
or wake it up from sleep mode.
Battery charge indicator (dual-color)
Dim: The power charger is not plugged to the device.
White: The battery is 100% charged.
Orange: The device is in battery charging mode.
3Built-in microphone
The built-in mono microphone can be used for video conferencing, voice
narrations, or simple audio recordings.
43.5mm Headphone output/Microphone input combo jack
Connect an amplied speaker or headphones to this port. You can also
connect a microphone for voice narrations or simple audio recording.
5Micro SD card slot
Insert Micro SD card into this slot.
6Mobile dock latch
Move the mobile dock latch to the left to release the tablet from the
mobile dock.
7Light sensor
The light sensor detects the amount of light in your environment and
automatically adjusts the brightness of your device’s touch screen panel.
8Built-in camera (front and rear)
Use the built-in camera to take pictures, record videos, video
conferencing, and other interactive applications.
ASUS Tablet Manual 5
9Lighting indicator
This indicator lights up when you are using your camera to take pictures
and record videos.
10 Touch screen panel
The touch screen panel allows you to operate your device using touch
gestures.
11 Windows Iogo
Tap this logo to go back to Metro UI screen.
12 Dock connector
• Insert the power adapter into this connector to supply power to
your device and charge the internal battery pack.
• Connect the USB Dock cable to the device and another system
(notebook or desktop PC) for data transmission.
• Dock the device to the mobile dock for keyboard and USB
connectivity.
• Connect the bundled USB Dongle for USB extension function.
13 Micro HDMI port
Insert a micro HDMI cable into this port to connect to an HDMI device.
14 Volume button
Press this button to increase or decrease the volume.
15 Camera LED ash
Use the ash to take photos when lighting conditions are poor.
16 Audio speaker system
Your device is equipped with a built-in high quality stereo speakers.
ASUS Tablet Manual
6
• Use only the power adapter and the USB Dock cable to charge your device.
Using a dierent power adapter may damage your device.
• Ensure that the 36-pin USB connector is fully inserted into your device.
• The input voltage range between the wall outlet and the power adapter is AC
100V–240V, and the output voltage of the power adapter is DC 15V, 1.2A.
Fully charge the battery up to eight hours for rst-time use.
Charging your device
1
2
3
ASUS Tablet Manual 7
Using the USB dongle
The USB dongle allows you to connect a USB device to your tablet. You can access
the contents of your ash drives or external HDDs, connect a speaker, use a mouse
or a keyboard and other USB devices.
To use the USB dongle:
1. Connect the bundled USB dongle’s connector to your tablet’s dock port.
2. Insert the USB device to the USB dongle’s USB port.
Ensure that the 36-pin USB dongle is fully inserted to your device.
Turning your device on
To turn your device on:
Press and hold the power button for one (1)
second.
ASUS Tablet Manual
8
Turning your device off
Putting on sleep mode
To put your device on sleep mode:
Press the Power button once.
Forcing your device to shut down
To force shutdown your device:
If your device is unresponsive, press and hold the power button for at least
eight (8) seconds.
Shutting down your device
To shut down your device:
1. Launch the Charm bar and tap .
2. Tap > Shut down to turn o your device.
•
ASUS Tablet Manual 9
Declarations and Safety Statements
Federal Communications Commission Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
This device has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiated radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment o and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit dierent from that to which
the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Changes or modications not expressly approved by the party responsible for
compliance could void the user‘s authority to operate the equipment.
The antenna(s) used for this transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
RF Exposure Information (SAR)
This device meets the government’s requirements for exposure to radio waves.
This device is designed and manufactured not to exceed the emission limits for
exposure to radio frequency (RF) energy set by the Federal Communications
Commission of the U.S. Government.
The exposure standard employs a unit of measurement known as the Specic
Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg. Tests for SAR are
conducted using standard operating positions accepted by the FCC with the EUT
transmitting at the specied power level in dierent channels.
The highest SAR value for the device as reported to the FCC is 0.869 W/kg when
placed next to the body.
•
•
•
•
ASUS Tablet Manual
10
The FCC has granted an Equipment Authorization for this device with all reported
SAR levels evaluated as in compliance with the FCC RF exposure guidelines. SAR
information on this device is on le with the FCC and can be found under the
Display Grant section of www.fcc.gov/oet/ea/fccid after searching on FCC ID:
MSQTF810C.
This device is compliance with SAR for general population /uncontrolled exposure
limits in ANSI/IEEE C95.1-1999 and had been tested in accordance with the
measurement methods and procedures specied in OET Bulletin 65 Supplement C.
Canada, Industry Canada (IC) Notices
This Class B digital apparatus complies with Canadian ICES-003 and RSS-210.
Operation is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.
Radio Frequency (RF) Exposure Information
The radiated output power of the Wireless Device is below the Industry Canada
(IC) radio frequency exposure limits. The Wireless Device should be used in such
a manner such that the potential for human contact during normal operation is
minimized.
This device has been evaluated for and shown compliant with the IC Specic
Absorption Rate (“SAR”) limits when installed in specic host products operated in
portable exposure conditions.
Canada’s REL (Radio Equipment List) can be found at the following web address:
http://www.ic.gc.ca/app/sitt.reltel/srch/nwRdSrch.do?lang=eng
Additional Canadian information on RF exposure also can be found at the
following web address: http://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf08792.html
Canada, avis d’Industry Canada (IC)
Cet appareil numérique de classe B est conforme aux normes canadiennes
ICES-003 et RSS-210.
Son fonctionnement est soumis aux deux conditions suivantes : (1) cet appareil ne
doit pas causer d'interférence et (2) cet appareil doit accepter toute interférence,
notamment les interférences qui peuvent aecter son fonctionnement.
