Eee Pad User Manual

ME370TG

EXXXX

ASUS is devoted to creating environment-

friendly products/packagings to safeguard

consumers’health while minimizing the

impact on the environment. The reduction

of the number of the manual pages complies

with the reduction of carbon emission.

For the detailed user manual and related

information, refer to the user manual

included in the device or visit the ASUS

Support Site at http://support.asus.com or

the Eee Pad website at http://eee.asus.com/

eeepad for updated information.

There are three main types of airport security devices:

X-ray machines (used on items placed on conveyor

belts), magnetic detectors (used on people walking

through security checks), and magnetic wands

(hand-held devices used on people or individual

items). You can send your Eee Pad through airport

X-ray machines. But do not send your Eee Pad

through airport magnetic detectors or expose it to

magnetic wands.

Charging Your Batteries

If you intend to use battery power, be sure to fully charge

your battery pack before going on long trips. Remember

that the power adapter charges the battery pack as long as

it is plugged into the computer and an AC power source. Be

aware that it takes much longer to charge the battery pack

when the Eee Pad is in use.

Remember to fully charge the battery (8 hours or more)

before rst use and whenever it is depleted to prolong

battery life. The battery reaches its maximum capacity after

a few full charging and discharging cycles.

Airplane Precautions

Ask an airline personnel if you want to use your Eee Pad

onboard an aircraft. Most airlines have restrictions for using

electronic devices. Most airlines allow electronic use only

between and not during takeos and landings.

ASUS Eee Pad

Eee Pad Micro USB Cable

USB Charging Unit Warranty Card

User Manual

Package contents

• Ifanyoftheitemsisdamagedormissing,contact

your retailer.

• Thebundledpowerplugvarieswithcountryor

region.

ASUS Eee Pad

Your Eee Pad

ASUS Eee Pad

1Touch screen panel

The touch screen panel allows you to operate your

Eee Pad using the stylus or touch gestures.

2Built-in front camera

Use the built-in camera for picture taking,

video recording, video conferencing, and other

interactive applications.

3Audio speaker system

Your Eee Pad is equipped with a built-in high

quality stereo speaker. Audio features are software

controlled.

4Audio jack

The stereo combo jack (3.5mm) connects the Eee

Pad’s audio out signal to amplied speakers or

headphones. Using this jack automatically disables

the built-in speaker.

5Built-in side microphone

The built-in mono microphone can be used for

video conferencing, voice narrations, or simple

audio recordings.

ASUS Eee Pad

6Power button

Press and hold the Power button for four seconds

to power on your Eee Pad.

When your Eee Pad is powered on, press the

Power button to put the Eee Pad into sleep mode

or wake it up from sleep mode.

If the system becomes unresponsive, press and

hold the power switch for at least eight seconds to

force the Eee Pad to shut down.

Press the Power button for four seconds and when

prompted, tap OK to shut down your Eee Pad.

Forcing the system to shut down may result in

data loss. Please ensure that you back up all your

important data regularly.

7Micro USB port (2.0)

The Micro USB (Universal Serial Bus) port allows

you to charge the battery of your Eee Pad using

the USB charger or transfer data from or to your

computer.

Charging via USB: If you connect your Eee Pad to

the USB port on your computer, your Eee Pad will

be charged only when it is in sleep mode (screen

o) or powered o.

ASUS Eee Pad

8Reset button

Using a paper clip, press this button to reset the

system to its factory default settings.

9Volume key

Press this button to increase or decrease the

system volume.

10 SIM Tray

Put Micro-SIM card to connect the internet.

ASUS Eee Pad

Connecting to the power adapter

Connect the power adapter into the Eee Pad and to a power

outlet.

ASUS Eee Pad

• Useonlythepoweradapterthatcomeswith

your device. Using a dierent power adapter may

damage your device.

• Pleasepeeltheprotectivelmofromtheplug,

USB charging unit, and USB cable before charging

the Eee Pad to prevent risk or injury.

• UsingthebundledpoweradapterandUSBcableto

connect your Eee Pad to a power outlet is the best

way to charge the Eee Pad.

• Theinputvoltagerangebetweenthewalloutlet

and this adapter is AC 100V–240V, and the output

voltage of this adapter is DC 5V, 2A.

• Toprolongbatterylife,fullychargethebatteryfor

up to eight (8) hours when using the Eee Pad for

the rst time and whenever the battery power is

fully depleted.

• YourEeePadcanbechargedviatheUSBporton

the computer only when it is in sleep mode (screen

o) or powered o.

• ChargingthroughtheUSBportmaytakelonger

time to complete.

• Ifyourcomputerdoesnotprovideenoughpower

for charging your Eee Pad, charge your Eee Pad via

the power outlet instead.

ASUS Eee Pad

Setting up your Google account

Use your Google account to fully enjoy your Eee Pad's

Android features such as GTalk, Gmail, Navigation, Android

Market, and Maps.

If you have not set up your Google account the rst time

you turned on your Eee Pad, follow these steps to set up

your Google account:

1. From the upper right corner of the Home screen, tap

Apps.

2. Tap Settings > Accounts & sync > Add account.

3. Tap Google accounts.

4. Key in your e-mail address and password, then tap Sign

in. Wait for a few minutes until your Eee Pad connects to the

Google server.

If you do not have an existing Google account, create

one on the Google website at http://mail.google.

com
