Asus E8124 Manual de usuario

E8124

tablet

user manual

Charging your batteries

Ensure to fully charge your battery pack before using your

ASUS Tablet in battery mode for extended periods. Remember

that the power adapter charges the battery pack as long as it is

plugged into an AC power source. Be aware that it takes much

longer to charge the battery pack when the ASUS Tablet is in

use.

IMPORTANT! Do not leave the ASUS Tablet connected to

the power supply once it is fully charged. ASUS Tablet is not

designed to be left connected to the power supply for extended

periods of time.

Airplane precautions

Contact your airline provider to learn about related inight

services that can be used and restrictions that must be followed

when using your ASUS Tablet in-ight.

IMPORTANT! You can send your ASUS Tablet through x-ray

machines (used on items placed on conveyor belts), but do not

expose them from magnetic detectors and wands.

Safety precautions

This ASUS Tablet should only be used in enviroments with

ambient temperatures between 0°C (32°F) and 35°C (95°F).

Long time exposure to extremely high or low temperature

may quickly deplete and shorten the battery life. To ensure the

battery’s optimal performance, ensure that it is exposed within

the recommended environment temperature.

ASUS Tablet

Package contents

NOTES:

• If any of the items is damaged or missing, contact your

retailer.

• The bundled power adapter varies with country or region.

Micro USB cable

ASUS Tablet Power adapter

Technical documentations

and warranty card

Micro SIM card tray

eject pin

ASUS Tablet

Your ASUS Tablet

Front view

Ambient light sensor

The ambient light sensor detects the amount of

ambient light in your environment. It allows the

system to automatically adjust the brightness of the

display depending on the ambient light condition.

Front camera

This built-in 1.2-megapixel camera allows you to take

pictures or record videos using your ASUS Tablet.

Touch screen panel

The touch screen panel allows you to operate your

ASUS Tablet using touch gestures or a stylus pen.

ASUS Tablet

Rear view

Speaker/Headset port

This port allows you to connect your ASUS Tablet to

amplied speakers or a headset.

IMPORTANT! This port does not support an external

microphone.

Volume button

The volume button allows you to increase or decrease

the volume level of your ASUS Tablet.

Audio speakers

Your ASUS Tablet allows you to hear audios straight

from your ASUS Tablet. Audio features are software

controlled.

ASUS Tablet

Rear camera

This built-in 5-megapixel camera allows you to take

pictures or record videos using your ASUS Tablet.

Power button

Press the power button for about two (2) seconds to

turn your ASUS Tablet on or wake it up from standby

mode.

To turn your ASUS Tablet o, press the power button

for about two (2) seconds and when prompted, tap

Power O then tap OK.

To lock your ASUS Tablet or to put it to standby mode,

press and quickly release the power button.

In the event that your ASUS Tablet becomes

unresponsive, press and hold the power button for

about ten (10) seconds to force it to shut down.

IMPORTANT!

• When your ASUS Tablet is inactive for one (1)

minute, it will automatically go to standby mode.

• Forcing the system to restart may result to data

loss. We strongly recommend that you back up

your data regularly.

ASUS Tablet

Microphone

The built-in microphone can be used for video

conferencing, voice narrations or simple audio

recordings.

Micro USB 2.0 port

Use the micro USB (Universal Serial Bus) 2.0 to charge

the battery pack or supply power to your ASUS Tablet.

This port also allows you to transfer data from your

computer to your ASUS Tablet and vice versa.

NOTE: When you connect your ASUS Tablet to the

USB port on your computer, your ASUS Tablet will be

charged only when it is in sleep mode (screen o) or

turned o.

Micro HDMI port

This port is for a micro HDMI (High-Denition

Multimedia Interface) connector and is HDCP

compliant for HD DVD, Blu-ray and other protected

content playback.

ASUS Tablet

Micro SIM card slot

The ASUS Tablet comes with a built-in micro SIM

(Subscriber Identity Module) card slot that supports

GSM, WCDMA, and LTE network bands.

NOTE: Refer to section Installing a micro SIM card

for more details.

Micro SIM card tray eject hole

Insert the bundled micro SIM card tray eject pin

into this hole to eject the micro SIM card tray.

MicroSD card slot

The ASUS Tablet comes with an additional built-in

memory card reader slot that supports microSD and

microSDHC card formats.

Manual reset hole

If your system becomes unresponsive, push inside the

manual reset hole using a straightened paper clip to

force-restart your ASUS Tablet.

IMPORTANT! Forcing the system to restart may

result to data loss. We strongly recommend that you

back up your data regularly.

ASUS Tablet

Charging your ASUS Tablet

To charge your ASUS Tablet:

Connect the micro USB cable to the power adapter.

Plug the micro USB connector into your ASUS Tablet.

Plug the power adapter into a grounded power outlet.

Charge your ASUS Tablet for eight (8) hours before

using it in battery mode for the rst time.

ASUS Tablet

IMPORTANT!

• Use only the bundled power adapter and micro USB cable

to charge your ASUS Tablet. Using a dierent power adapter

may damage your ASUS Tablet.

• Peel the protective lm o from the power adapter and micro

USB cable before charging the ASUS Tablet to prevent risk or

injury.

• Ensure that you plug the power adapter to the correct power

outlet with the correct input rating. The output voltage of this

adapter is DC 5V, 2A.

• Do not leave the ASUS Tablet connected to the power supply

once it is fully charged. ASUS Tablet is not designed to be left

connected to the power supply for extended periods of time.

• When using your ASUS Tablet while plugged-in to a power

outlet, the grounded power outlet must be near to the unit

and easily accessible.

NOTES:

• Your ASUS Tablet can be charged via the USB port on the

computer only when it is in sleep mode (screen o) or turned

o.

• Charging through the USB port may take longer time to

complete.

• If your computer does not provide enough power for

charging your ASUS Tablet, charge your ASUS Tablet via the

grounded power outlet instead.
