Asus RT-AC750GF Manual de usuario

User Guide

RT-AC750GF

Wireless-AC750 Dual-Band

Gigabit Router

No part of this manual, including the products and software described

in it, may be reproduced, transmitted, transcribed, stored in a retrieval

system, or translated into any language in any form or by any means, except

documentation kept by the purchaser for backup purposes, without the

express written permission of ASUSTeK Computer Inc. (“ASUS”).

Product warranty or service will not be extended if: (1) the product is repaired,

modied or altered, unless such repair, modication of alteration is authorized

in writing by ASUS; or (2) the serial number of the product is defaced or

missing.

ASUS PROVIDES THIS MANUAL “AS IS”WITHOUT WARRANTY OF ANY KIND,

EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED

WARRANTIES OR CONDITIONS OF MERCHANTABILITY OR FITNESS FOR A

PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS DIRECTORS, OFFICERS,

EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL,

OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,

LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS

AND THE LIKE), EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF

SUCH DAMAGES ARISING FROM ANY DEFECT OR ERROR IN THIS MANUAL OR

PRODUCT.

SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE

FURNISHED FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE

AT ANY TIME WITHOUT NOTICE, AND SHOULD NOT BE CONSTRUED AS A

COMMITMENT BY ASUS. ASUS ASSUMES NO RESPONSIBILITY OR LIABILITY

FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS MANUAL,

INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.

Products and corporate names appearing in this manual may or may not be

registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’benet, without intent

to infringe.

E12397

First Edition

February 2017

Table of contents

1 Getting to know your wireless router

1.1 Welcome! ........................................................................................6

1.2 Package contents.........................................................................6

1.3 Your wireless router.....................................................................7

1.4 Positioning your router..............................................................9

1.5 Setup Requirements ................................................................ 10

1.6 Router Setup............................................................................... 11

1.6.1 Wired connection..................................................................11

1.6.2 Wireless connection.............................................................12

2 Getting started

2.1 Logging into the Web GUI ..................................................... 14

2.2 Quick Internet Setup (QIS) with Auto-detection ........... 15

2.3 Connecting to your wireless network................................ 19

3 Conguring the General settings

3.1 Using the Network Map ......................................................... 20

3.1.1 Setting up the wireless security settings......................21

3.1.2 Managing your network clients.......................................22

3.2 Creating a Guest Network...................................................... 23

3.3 Using the Trac Manager ...................................................... 25

3.3.1 Managing QoS (Quality of Service) Bandwidth..........25

3.3.2 Monitoring Trac .................................................................28

3.4 Setting up Parental Control................................................... 29

4 Conguring the Advanced Settings

4.1 Wireless......................................................................................... 31

4.1.1 General......................................................................................31

4.1.2 WPS ............................................................................................34

4.1.3 Wireless MAC Filter...............................................................36

Table of contents

4.1.4 RADIUS Setting ......................................................................37

4.1.5 Professional.............................................................................38

4.2 LAN................................................................................................. 40

4.2.1 LAN IP ........................................................................................40

4.2.2 DHCP Server............................................................................41

4.2.3 Route .........................................................................................43

4.2.4 IPTV ............................................................................................44

4.3 WAN ............................................................................................... 45

4.3.1 Internet Connection.............................................................45

4.3.2 Port Trigger..............................................................................48

4.3.3 Virtual Server/Port Forwarding........................................49

4.3.4 DMZ............................................................................................53

4.3.5 DDNS .........................................................................................54

4.3.6 NAT Passthrough...................................................................55

4.4 IPv6................................................................................................. 56

4.5 Firewall.......................................................................................... 57

4.5.1 General......................................................................................57

4.5.2 URL Filter ..................................................................................57

4.5.3 Keyword lter .........................................................................58

4.5.4 Network Services Filter .......................................................59

4.6 Administration ........................................................................... 61

4.6.1 Operation Mode ....................................................................61

4.6.2 System.......................................................................................62

4.6.3 Firmware Upgrade................................................................63

4.6.4 Restore/Save/Upload Setting ...........................................63

4.7 System Log .................................................................................. 64

Table of contents

5 Utilities

5.1 Device Discovery....................................................................... 65

5.2 Firmware Restoration .............................................................. 66

6 Troubleshooting

6.1 Basic Troubleshooting............................................................. 67

6.2 Frequently Asked Questions (FAQs) .................................. 70

Appendices

Notices ....................................................................................................... 79

ASUS Contact information.................................................................... 93

Networks Global Hotline Information............................................... 94

1 Getting to know your wireless

router

NOTES:

• Ifanyoftheitemsaredamagedormissing,contactASUSfor

technical inquiries and support, Refer to the ASUS Support Hotline

list at the back of this user manual.

• Keeptheoriginalpackagingmaterialincaseyouwouldneedfuture

warranty services such as repair or replacement.

RT-AC750GF Wireless Router Network cable (RJ-45)

Power adapter Quick Start Guide

Warranty card

1.1 Welcome!

Thank you for purchasing an ASUS RT-AC750GF Wireless Router!

The ultra-thin and stylish RT-AC750GF features both 2.4GHz and

5GHz dual bands which delivers super fast gigabit wireless-AC

speeds up to 867 Mbps on the 5 GHz band & 300 Mbps on the 2.5

GHz band concurrently.

1.2 Package contents

1.3 Your wireless router

1LAN 1~2 LEDs

O: No power or no physical connection.

On: Has physical connection to a local area network (LAN).

2WAN (Internet) LED

O: No power or no physical connection.

On: Has physical connection to a wide area network (WAN).

32.4GHz LED

O: No 2.4 GHz signal.

On:Wireless system is ready.

Flashing:Transmitting or receiving data via wireless connection.

45GHz LED

O: No 5 GHz signal.

On:Wireless system is ready.

Flashing:Transmitting or receiving data via wireless connection.

5Power LED

O: No power.

On: Device is ready.

Flashing slow: Rescue mode

Flashing quick:WPS is processing.

6Power (DC-IN) port

Insert the bundled AC adapter into this port and connect your router to a power source.

7Power button

Press this button to power on or off the system.

NOTES:

• Useonlytheadapterthatcamewithyourpackage.Usingother

adapters may damage the device.

• Specications:

DC Power adapter DC Output: +12V with max 2A current;

Operating

Temperature 0~40oCStorage 0~70oC

Operating Humidity 50~90% Storage 20~90%

8WPS button

This button launches the WPS Wizard.

9Reset button

This button resets or restores the system to its factory default settings.

10 WAN (Internet) port

Connect a network cable into this port to establish WAN connection.

11 LAN 1 ~ 2 ports

Connect network cables into these ports to establish LAN connection.

1.4 Positioning your router

For the best wireless signal transmission between the wireless

router and the network devices connected to it, ensure that you:

• Placethewirelessrouterinacentralizedareaforamaximum

wireless coverage for the network devices.

• Keepthedeviceawayfrommetalobstructionsandawayfrom

direct sunlight.

• Keepthedeviceawayfrom802.11b/gor20MHzonlyWi-Fi

devices, 2.4GHz computer peripherals, Bluetooth devices,

cordlessphones,transformers,heavy-dutymotors,fluorescent

lights, microwave ovens, refrigerators, and other industrial

equipment to prevent signal interference or loss.

• Alwaysupdatetothelatestfirmware.VisittheASUSwebsiteat

http://www.asus.com to get the latest firmware updates.

• Toensurethebestwirelesssignal,orientthethreedetachable

antennas as shown in the drawing below.

90°

1.5 Setup Requirements

To set up your wireless network, you need a computer that meets

the following system requirements:

• EthernetRJ-45(LAN)port(10Base-T/100Base-TX/

1000Base-T)

• IEEE802.11a/b/g/n/acwirelesscapability

• AninstalledTCP/IPservice

• WebbrowsersuchasInternetExplorer,Firefox,Safari,or

Google Chrome

NOTES:

• Ifyourcomputerdoesnothavebuilt-inwirelesscapabilities,you

may install an IEEE 802.11a/b/g/n WLAN adapter to your computer

to connect to the network.

• Withitsdualbandtechnology,yourwirelessroutersupports2.4GHz

and 5GHz wireless signals simultaneously. This allows you to do

Internet-related activities such as Internet surng or reading/writing

e-mail messages using the 2.4GHz band while simultaneously

streaming high-denition audio/video les such as movies or music

using the 5GHz band.

• SomeIEEE802.11ndevicesthatyouwanttoconnecttoyournetwork

may or may not support 5GHz band. Refer to the device's manual for

specications.

• TheEthernetRJ-45cablesthatwillbeusedtoconnectthenetwork

devices should not exceed 100 meters.

Tabla de contenidos

Otros manuales de Enrutador de red de Asus

Asus

Asus ROG STRIX GS-AX3000 Manual de usuario

Asus

Asus RT-AX88U Manual de usuario

Asus

Asus DSL-AC3100 Manual de usuario

Asus

Asus RT-AC66U Manual de usuario

Asus

Asus PCI-DA2100 Manual de usuario

Asus

Asus RT-AC55U Manual de usuario

Asus

Asus DSL-AC55U Manual de usuario

Asus

Asus ZenWiFi Pro ET12 Manual de usuario

Asus

Asus GX-D1051 Manual de usuario

Asus

Asus RT-AC52U Manual

Asus

Asus AAM6020VI Manual de usuario

Asus

Asus RT-N16 Manual de usuario

Asus

Asus 90IG04K0-BU9100 Manual de usuario

Asus

Asus RT-AC66U Manual de usuario

Asus

Asus FX-D1161 Manual de usuario

Asus

Asus ZenWiFi Pro ET12 Manual de usuario

Asus

Asus RT-AC66U B1 Manual de usuario

Asus

Asus Internet Security Router Manual de usuario

Asus

Asus RT-AC87U Dual Band Manual de usuario

Asus

Asus 90IG06K0-MU9R10 Manual de usuario

Asus

Asus ROG Strix GS-AX5400 Manual de usuario

Asus

Asus RT-N800HP Manual de instrucciones

Asus

Asus RT-AC2900 Manual de usuario

Asus

Asus RT-ACRH12 Manual de usuario

Manuales populares de Enrutador de red de otras marcas

Allnet

Allnet ALL0333AU Manual de usuario

HomeSeer

HomeSeer HT-SEL Manual de usuario

Sercomm

Sercomm Genesis OC3505D Manual de usuario

Billion

Billion BIPAC 5102 Series Manual de usuario

TP-Link

TP-Link TD-8817 Manual de usuario

Motorola

Motorola MR1900 Manual de usuario

Digi

Digi IX14 Manual de usuario

Cisco

Cisco NCS 540 Manual

XAVi

XAVi X8821e Manual de usuario

BEC

BEC 6200WZL Manual de usuario

MikroTik

MikroTik hAP ac3 Series Manual de usuario

Korenix

Korenix JetNet 5428G Series Manual de usuario

NETGEAR

NETGEAR FS526T - Switch Manual de usuario

Korenix

Korenix JetNet 5710G Series Manual de usuario

Automated Logic

Automated Logic ZN551 Manual del propietario

Cisco

Cisco ASR 1000 Series Manual del operador

EnGenius

EnGenius ESR-9710 Manual de usuario

Cisco

Cisco 805 Series Instrucciones de funcionamiento y seguridad
