Asus X00BD Manual de usuario
E11709
User Guide
15060-82600000
E11709_ZB500KG_UM_Booklet_EU.indd 1
2016-09-12 09:58:56
First Edition/ September 2016
Model: ASUS_X00BD (ZB500KG)
Before you start, ensure that you have read all the
safety information and operating instructions in this
User Guide to prevent injury or damage to your
device.
NOTE: For the latest updates and more detailed
information, please visit www.asus.com.
Front features
Sensor
Touch screen
display
Receiver
Touch keys
Front camera
LED Indicator
E11709_ZB500KG_UM_Booklet_EU.indd 2
2016-09-12 09:58:57
Side features
Audio jack
Micro USB port
Power key
Groove
NOTE: Pry open the rear cover from the groove.
E11709_ZB500KG_UM_Booklet_EU.indd 3
2016-09-12 09:58:57
Rear features
NOTES:
• Removetherearcovertodisplaythedual
micro SIM and microSD card slots.
• ThemicroSIMcardslotssupportWCDMA
and GSM/EDGE network bands.
• ThemicroSDcardslotsupportsmicroSDand
microSDHCcardformats.
NOTES:
• Useonlythepoweradapterthatcamewithyour
device. Using a different power adapter may
damage your device.
• UsingthebundledpoweradapterandASUSPhone
signal cable to connect your ASUS Phone to a
power outlet is the best way to charge your ASUS
Phone.
• Theinputvoltagerangebetweenthewalloutletand
thisadapterisAC100V-240V.Theoutputvoltage
ofthemicroUSBcableisDC5.2V,1A.
IMPORTANT!
• YourASUSPhonecomespartiallychargedbutyou
mustchargeitfullybeforeusingitforthersttime.
Readtheimportantnoticesandcautionsbefore
charging your device.
• WhenusingyourASUSPhonewhileitispluggedto
a power outlet, the grounded power outlet must be
near to the unit and easily accessible.
• WhenchargingyourASUSPhonethroughyour
computer, ensure that you plug the micro USB
cable to your computer’s USB 2.0 / USB 3.0 port.
• AvoidchargingyourASUSPhoneinan
environment with ambient temperature of above
35oC(95oF).
Rear camera
Rear cover
Volume key
Speaker
Camera ash
E11709_ZB500KG_UM_Booklet_EU.indd 4
2016-09-12 09:58:57
Rear features
Charging your ASUS Phone
To charge your ASUS Phone:
1. ConnecttheUSBconnectorintothepower
adapter’s USB port.
2. ConnecttheotherendofthemicroUSBcable
to your ASUS Phone.
3. Plug the power adapter into a wall socket.
NOTES:
• Useonlythepoweradapterthatcamewithyour
device. Using a different power adapter may
damage your device.
• UsingthebundledpoweradapterandASUSPhone
signal cable to connect your ASUS Phone to a
power outlet is the best way to charge your ASUS
Phone.
• Theinputvoltagerangebetweenthewalloutletand
thisadapterisAC100V-240V.Theoutputvoltage
ofthemicroUSBcableisDC5.2V,1A.
IMPORTANT!
• YourASUSPhonecomespartiallychargedbutyou
mustchargeitfullybeforeusingitforthersttime.
Readtheimportantnoticesandcautionsbefore
charging your device.
• WhenusingyourASUSPhonewhileitispluggedto
a power outlet, the grounded power outlet must be
near to the unit and easily accessible.
• WhenchargingyourASUSPhonethroughyour
computer, ensure that you plug the micro USB
cable to your computer’s USB 2.0 / USB 3.0 port.
• AvoidchargingyourASUSPhoneinan
environment with ambient temperature of above
35oC(95oF).
3
1
2
E11709_ZB500KG_UM_Booklet_EU.indd 5
2016-09-12 09:58:57
1. Locate the groove on
thebottom-rightcorner
of your ASUS Phone.
Installing a micro SIM card
To install a micro SIM card:
2. Pry the cover loose
and then pull the rear
cover off.
3. Removethebattery.
CAUTION!
• Donotusesharptoolsorsolventonyourdeviceto
avoid scratches on it.
• UseonlyastandardmicroSIMcardonyourASUS
Phone. A nano to micro SIM adapter or a trimmed
SIMcardmaynotproperlytintoandmaynotbe
detected by your ASUS Phone.
• DO NOT install an empty nano to micro SIM
adapter into the micro SIM card slot to avoid
irreversible damage.
NOTES:
• ThemicroSIMcardslot2isatthelowerpartofthe
micro SIM / micro SD combo card slot.
• BothMicroSIMcardslotssupport2G/3GWCDMA
network bands. But only one micro SIM card can
connectto3GWCDMAserviceatatime.
E11709_ZB500KG_UM_Booklet_EU.indd 6
2016-09-12 09:58:58
4. InsertthemicroSIMcardintooneoftheslots.
CAUTION!
• Donotusesharptoolsorsolventonyourdeviceto
avoid scratches on it.
• UseonlyastandardmicroSIMcardonyourASUS
Phone. A nano to micro SIM adapter or a trimmed
SIMcardmaynotproperlytintoandmaynotbe
detected by your ASUS Phone.
• DO NOT install an empty nano to micro SIM
adapter into the micro SIM card slot to avoid
irreversible damage.
NOTES:
• ThemicroSIMcardslot2isatthelowerpartofthe
micro SIM / micro SD combo card slot.
• BothMicroSIMcardslotssupport2G/3GWCDMA
network bands. But only one micro SIM card can
connectto3GWCDMAserviceatatime.
Micro SIM card
2 / microSD card
combo card slot
Micro SIM card 1
E11709_ZB500KG_UM_Booklet_EU.indd 7
2016-09-12 09:58:58
4. InsertthemicroSDcardintothemicroSDcard
slot.
1. Locate the groove on
thebottom-rightcorner
of your ASUS Phone.
2. Pry the cover loose
and then pull the rear
cover off.
Installing a microSD card
To install a microSD card:
3. Removethebattery.
E11709_ZB500KG_UM_Booklet_EU.indd 8
2016-09-12 09:58:59
FCC Regulations:
Thismobilephonecomplieswithpart15oftheFCC
Rules.Operationissubjecttothefollowingtwo
conditions:(1)Thisdevicemaynotcauseharmful
interference, and (2) this device must accept any
interference received, including interference that
may cause undesired operation.
Thismobilephonehasbeentestedandfoundto
complywiththelimitsforaClassBdigitaldevice,
pursuanttoPart15oftheFCCRules.Theselimits
are designed to provide reasonable protection
against harmful interference in a residential
installation.Thisequipmentgenerates,uses
andcanradiatedradiofrequencyenergyand,
if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee
that interference will not occur in a particular
installationIfthisequipmentdoescauseharmful
interference to radio or television reception, which
canbedeterminedbyturningtheequipmentoff
and on, the user is encouraged to try to correct
the interference by one or more of the following
measures:
- Reorientorrelocatethereceivingantenna.
- Increasetheseparationbetweenthe
equipmentandreceiver.
- Connecttheequipmentintoanoutletona
circuit different from that to which the receiver
is connected.
- Consultthedealeroranexperiencedradio/TV
technician for help.
Caution:Changesormodicationsnotexpressly
approved by the party responsible for compliance
could void the user‘s authority to operate the
equipment.
E11709_ZB500KG_UM_Booklet_EU.indd 9
2016-09-12 09:58:59
RF Exposure Information (SAR)
Thisphoneisdesignedandmanufacturednot
toexceedtheemissionlimitsforexposureto
radiofrequency(RF)energysetbytheFederal
CommunicationsCommissionoftheUnitedStates.
DuringSARtesting,thisdevicewassetto
transmitatitshighestcertiedpowerlevelinall
testedfrequencybands,andplacedinpositions
thatsimulateRFexposureinusageagainstthe
head with no separation, and near the body with
theseparationof10mm.AlthoughtheSARis
determinedatthehighestcertiedpowerlevel,the
actualSARlevelofthedevicewhileoperatingcan
bewellbelowthemaximumvalue.Thisisbecause
the phone is designed to operate at multiple power
levelssoastouseonlythepowerrequiredtoreach
the network. In general, the closer you are to a
wireless base station antenna, the lower the power
output.
Theexposurestandardforwirelessdevices
employing a unit of measurement is known as the
SpecicAbsorptionRate,orSAR.
TheSARlimitsetbytheFCCis1.6W/kg.
ThisdeviceiscompliedwithSARforgeneral
population/uncontrolledexposurelimitsin
ANSI/IEEEC95.1-1992andhadbeentestedin
accordance with the measurement methods and
proceduresspeciedinIEEE1528.
TheFCChasgrantedanEquipmentAuthorization
forthismodelphonewithallreportedSARlevels
evaluatedasincompliancewiththeFCCRF
exposureguidelines.SARinformationonthismodel
phoneisonlewiththeFCCandcanbefound
under the Display Grant section of www.fcc.gov/oet/
ea/fccidaftersearchingonFCCID:MSQX00BD.
Forthisdevice,thehighestreportedSARvaluefor
usageagainsttheheadis0.78W/kg,forusagenear
thebodyis1.15W/kg.
E11709_ZB500KG_UM_Booklet_EU.indd 10
2016-09-12 09:58:59
