ASROCK FM2A88M+ BTC Manual de usuario

User Manual

FM2A88M+ BTC

Version 1.0

Published April 2014

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for

informational use only and subject to change without notice, and should not be

constructed as a commitment by ASRock. ASRock assumes no responsibility for

any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the documentation or product.

e terms HDMI™ and HDMI High-Denition Multimedia Interface, and the HDMI

logo are trademarks or registered trademarks of HDMI Licensing LLC in the United

States and other countries.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Website: http://www.asrock.com

Contents

1. Introduction 1

1.1 Package Contents 1

1.2 Specications 2

1.3 Unique Features 6

1.4 Motherboard Layout 11

1.5 I/O Panel 13

2. Installation 14

2.1 CPU Installation 15

2.2 Installation of CPU Fan and Heatsink 16

2.3 Installation of Memory Modules (DIMM) 17

2.4 Expansion Slots (PCI and PCI Express Slots) 19

2.5 Jumpers Setup 20

2.6 Onboard Headers and Connectors 21

3. Software and Utilities Operation 26

4. UEFI SETUP UTILITY 34

4.1 Introduction 34

4.1.1 UEFI Menu Bar 34

4.1.2 Navigation Keys 35

4.2 Main Screen 35

4.3 OC Tweaker Screen 36

4.4 Advanced Screen 39

4.4.1 CPU Conguration 40

4.4.2 North Bridge Conguration 41

4.4.3 South Bridge Conguration 42

4.4.4 Storage Conguration 43

4.4.5 Super IO Conguration 44

4.4.6 ACPI Conguration 45

4.4.7 USB Conguration 47

4.5 Tool 49

4.6 Hardware Health Event Monitoring Screen 52

4.7 Boot Screen 53

4.8 Security Screen 55

4.9 Exit Screen 56

English

FM2A88M+ BTC

1. Introduction

Thank you for purchasing ASRock FM2A88M+ BTC motherboard, a reliable moth-

erboard produced under ASRock’s consistently stringent quality control. It delivers

excellent performance with robust design conforming to ASRock’s commitment to

quality and endurance.

In this documentation, Chapter 1 and 2 contains the introduction of the motherboard

and step-by-step installation guides. Chapter 3 contains the operation guide of the

software and utilities. Chapter 4 contains the conguration guide of the BIOS setup.

Because the motherboard specications and the BIOS software might

be updated, the content of this manual will be subject to change without

notice. In case any modications of this manual occur, the updated ver-

sion will be available on ASRock website without further notice. You may

nd the latest VGA cards and CPU support lists on ASRock website as

well. ASRock website http://www.asrock.com

If you require technical support related to this motherboard, please visit

our website for specic information about the model you are using.

www.asrock.com/support/index.asp

1.1 Package Contents

ASRock FM2A88M+ BTC Motherboard (ATX Form Factor)

ASRock FM2A88M+ BTC Quick Installation Guide

ASRock FM2A88M+ BTC Support CD

2 x Serial ATA (SATA) Data Cables (Optional)

1 x I/O Panel Shield

English

FM2A88M+ BTC

1.2 Specications

Platform • Micro ATX Form Factor

• All Solid Capacitor design

• High Density Glass Fabric PCB

CPU • Supports Socket FM2+ 95W / FM2 100W processors

• 4 + 2 Power Phase design

Chipset • AMD A88X (Bolton-D4)

Memory • Dual Channel DDR3 Memory Technology

• 2 x DDR3 DIMM Slots

• Supports DDR3 1866/1600/1333/1066 non-ECC, un-

buffered memory (see CAUTION 1)

• Max. capacity of system memory: 32GB (see CAUTION

• Supports Intel® Extreme Memory Prole (XMP) 1.3 / 1.2

• Supports AMD Memory Prole Technology (AMP)

• 15μ Gold Contact in DIMM Slots

Expan-

sion

Slot

• 1 x PCI Express 3.0 x16 Slot (PCIE1 @ x16 mode)

* PCIE 3.0 is only supported with FM2+ CPU. With FM2

CPU, it only supports PCIE 2.0.

• 3 x PCI Express 2.0 x1 Slots

• 15μ Gold Contact in VGA PCIe Slot (PCIE1)

Graphics • Integrated AMD RadeonTM R7/R5 Series Graphics in

A-series APU

• DirectX 11.1, Pixel Shader 5.0 with FM2+ CPU. DirectX

11, Pixel Shader 5.0 with FM2 CPU.

• Max. shared memory 2GB

• Dual VGA output: support DVI-D and D-Sub by

independent display controllers

• Supports Dual-link DVI-D with max. resolution up to

2560x1600 @ 60Hz

English

FM2A88M+ BTC

• Supports D-Sub with max. resolution up to 1920x1200 @

60Hz

• Supports AMD Steady VideoTM 2.0: New video post

processing capability for automatic jitter reduction on

home/online video

• Supports HDCP with DVI-D Port

• Supports Full HD 1080p Blu-ray (BD) playback with

DVI-D Port

Audio • 5.1 CH HD Audio (Realtek ALC662 Audio Codec)

• Supports Surge Protection (ASRock Full Spike Protec-

tion)

• TI® NE5532 Premium Headset Amplier (Supports up to

600 ohm headsets) (Line-Out on rear I/O only)

LAN • PCIE x1 Gigabit LAN 10/100/1000 Mb/s

• Realtek RTL8111GR

• Supports Wake-On-WAN (see CAUTION 3)

• Supports Wake-On-LAN

• Supports Lightning/ESD Protection (ASRock Full Spike

Protection)

• Supports LAN Cable Detection

• Supports Energy Efcient Ethernet 802.3az

• Supports PXE

Rear

Panel I/O

• 1 x PS/2 Mouse Port

• 1 x PS/2 Keyboard Port

• 1 x D-Sub Port

• 1 x DVI-D Port

• 4 x USB 2.0 Ports (Supports ESD Protection (ASRock

Full Spike Protection))

• 2 x USB 3.0 Ports (AMD A88X (Bolton-D4))

(Supports ESD Protection (ASRock Full Spike

Protection))

• 1 x RJ-45 LAN Port with LED (ACT/LINK LED and

SPEED LED)

• HD Audio Jacks: Line in / Front Speaker / Microphone

English

FM2A88M+ BTC

Storage • 8 x SATA3 6.0 Gb/s Connectors, support RAID (RAID

0, RAID 1, RAID 5 and RAID 10), NCQ, AHCI and Hot

Plug

Connec-

tor

• 1 x Print Port Header

• 1 x TPM Header

• 2 x CPU Fan Connectors (1 x 4-pin, 1 x 3-pin)

• 2 x Chassis Fan Connectors (1 x 4-pin, 1 x 3-pin)

• 1 x Power Fan Connector (3-pin)

• 1 x 24 pin ATX Power Connector

• 1 x 8 pin 12V Power Connector

• 1 x PCIe Power Connector

• 1 x Front Panel Audio Connector

• 1 x USB Power Jumper (Ultra USB Power)

• 2 x USB 2.0 Headers (Support 4 USB 2.0 ports)

(Supports ESD Protection (ASRock Full Spike Protec-

tion))

• 1 x USB 3.0 Header by AMD A88X (Bolton-D4) (Sup-

ports 2 USB 3.0 ports) (Supports ESD Protection (AS-

Rock Full Spike Protection))

BIOS

Feature

• 64Mb AMI UEFI Legal BIOS with GUI support

• Supports “Plug and Play”

• ACPI 1.1 Compliant wake up events

• Supports jumperfree

• SMBIOS 2.3.1 support

• DRAM, CPU, SB Voltage multi-adjustment

Support

• Drivers, Utilities, AntiVirus Software (Trial Version),

Google Chrome Browser and Toolbar, Start8 (30 days

trial)

Hardware

Monitor

• CPU temperature sensing

• Chassis temperature sensing

• CPU Fan Tachometer

• Chassis Fan Tachometer

• CPU/Chassis Quiet Fan

• CPU/Chassis Fan multi-speed control

• Voltage monitoring: +12V, +5V, +3.3V, Vcore

English

FM2A88M+ BTC

OS • Microsoft®Windows®8.1 32-bit / 8.1 64-bit / 8 32-bit / 8

64-bit / 7 32-bit / 7 64-bit / XP 32-bit / XP 64-bit

* USB 3.0 is not supported by Windows®XP

Certica-

tions

• FCC, CE, WHQL

• ErP/EuP ready (ErP/EuP ready power supply is

required)

WARNING

Please realize that there is a certain risk involved with overclocking,

including adjusting the setting in the BIOS, applying Untied Overclocking

Technology, or using third-party overclocking tools. Overclocking may

affect your system’s stability, or even cause damage to the components

and devices of your system. It should be done at your own risk and

expense. We are not responsible for possible damage caused by

overclocking.

* For detailed product information, please visit our website: http://www.asrock.com

CAUTION!

1. Whether 1866/1600MHz memory speed is supported depends

on the CPU you adopt. If you want to adopt DDR3 1866/1600

memory module on this motherboard, please refer to the mem-

ory support list on our website for the compatible memory mod-

ules.

ASRock website http://www.asrock.com

2. Due to the operating system limitation, the actual memory size

may be less than 4GB for the reservation for system usage

under Windows®8.1 / 8 / 7. For Windows®64-bit OS with 64-

bit CPU, there is no such limitation. You can use ASRock XFast

RAM to utilize the memory that Windows®cannot use.

3. Wake-On-WAN allows you to wake up this system from remote

mobile devices, such as smart phones, tables, or other PCs.

It needs third-party softwares and applications to utilize this

feature. Please visit our website for Home Cloud topic.

English

FM2A88M+ BTC

1.3 Unique Features

ASRock A-Tuning

A-Tuning is ASRock’s multi purpose software suite with a new

interface, more new features and improved utilities, including

XFast RAM, Dehumidier, Good Night LED, FAN-Tastic Tun-

ing, OC Tweaker and a whole lot more.

ASRock Instant Boot

ASRock Instant Boot allows you to turn on your PC in just a few

seconds, provides a much more efcient way to save energy,

time, money, and improves system running speed for your sys-

tem. It leverages the S3 and S4 ACPI features which normally

enable the Sleep/Standby and Hibernation modes in Windows®

to shorten boot up time. By calling S3 and S4 at specic timing

during the shutdown and startup process, Instant Boot allows

you to enter your Windows®desktop in a few seconds.

ASRock Instant Flash

ASRock Instant Flash is a BIOS ash utility embedded in Flash

ROM. This convenient BIOS update tool allows you to update

system BIOS without entering operating systems rst like MS-

DOS or Windows®. With this utility, you can press the <F6> key

during the POST or the <F2> key to enter into the BIOS setup

menu to access ASRock Instant Flash. Just launch this tool and

save the new BIOS le to your USB ash drive, oppy disk or

hard drive, then you can update your BIOS only in a few clicks

without preparing an additional oppy diskette or other compli-

cated ash utility. Please be noted that the USB ash drive or

hard drive must use FAT32/16/12 le system.

ASRock APP Charger

If you desire a faster, less restricted way of charging your

Apple devices, such as iPhone/iPad/iPod Touch, ASRock has

prepared a wonderful solution for you - ASRock APP Charger.

Simply install the APP Charger driver, it makes your iPhone

charge much quickly from your computer and up to 40% faster

than before. ASRock APP Charger allows you to quickly charge

many Apple devices simultaneously and even supports continu-

ous charging when your PC enters into Standby mode (S1),

Otros manuales para FM2A88M+ BTC

Tabla de contenidos

Otros manuales de Placa madre de ASROCK

ASROCK

ASROCK N68-GS UCC - Manual de usuario

ASROCK

ASROCK athena A2 Manual de usuario

ASROCK

ASROCK IMB-186V Manual de usuario

ASROCK

ASROCK A88M-G/3.1 Manual de usuario

ASROCK

ASROCK P4S55FX2 Manual de usuario

ASROCK

ASROCK SP55 DELUXE Manual de usuario

ASROCK

ASROCK E3C224-V4L Manual de usuario

ASROCK

ASROCK H61M-GE Manual de usuario

ASROCK

ASROCK Z68M-ITX/HT Manual de usuario

ASROCK

ASROCK IMB-1005 Manual de servicio

ASROCK

ASROCK Z690 Extreme WiFi 6E Manual de usuario

ASROCK

ASROCK 785G Pro Manual de usuario

ASROCK

ASROCK B250M PRO4 Manual de usuario

ASROCK

ASROCK CONROEXFIRE-ESATA2 - INSTALLATION - 03-2007 Manual de usuario

ASROCK

ASROCK IMB-1313 Manual de usuario

ASROCK

ASROCK N73PC-GS - Manual de usuario

ASROCK

ASROCK Z590 Phantom Gaming-ITX/TB4 Manual de usuario

ASROCK

ASROCK IMB-194-D Instrucciones de uso

ASROCK

ASROCK N68-GS UCC - Manual de usuario

ASROCK

ASROCK 775XFIRE-ESATA2 - 02-2006 Manual de usuario

ASROCK

ASROCK FM2A85X Pro Manual de usuario

ASROCK

ASROCK X570S PG Riptide Manual de usuario

ASROCK

ASROCK 775XFIRE-VSTA - V1.2 Manual de usuario

ASROCK

ASROCK G41C-VS Manual de usuario

Manuales populares de Placa madre de otras marcas

DFI

DFI SD170 Manual de usuario

Asus

Asus P2L97A Manual de usuario

Winmate

Winmate IC70 Manual de usuario

Asus

Asus MES-B Manual de usuario

Grantech

Grantech SYS8F377VGGA-3OMN Manual de usuario

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manual de usuario

Gigabyte

Gigabyte GA-9IVDT Manual de usuario

Texas Instruments

Texas Instruments ADS8372EVM Manual de usuario

Commell

Commell MS-C73 Manual de usuario

IBT Technologies

IBT Technologies MB860 Manual de usuario

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manual de usuario

Biostar

Biostar M7VIT Bravo Instrucciones de funcionamiento e instalación

Intel

Intel D33217CK Manual de usuario

Asus

Asus F1A55-M LX PLUS R2.0 Manual de usuario

EPC

EPC EPC9147C Manual de usuario

Asus

Asus EX-B760M-V5 D4 Manual de usuario

EPOX

EPOX MU-8KHA0010 Manual de usuario

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manual de usuario
