Dear ASKO customer,

Thank you for choosing this quality product from Scandinavia,

which was made in Sweden.

We want you to feel assured that the inside of your new ma-

chine is just as good as the outside and that the ethics and

standards that went into the production of this machine are

just as high as the quality and performance that you will re-

ceive from it. We hope that this product will give you many

years of pleasure.

To ensure that you get the most from your new machine, we

recommend that you read the operating instructions before

using the machine. The operating instructions also contain

information on how to avoid damaging the environment.

Operating Instructions

Tumble dryer

Asko T712C

Before using your machine for

the first time

3Do not tumble-dry

4Safety instructions

4General

4Installation

4Safety

4Interrupting a program

4Transport/Winter storage

4Packing material

5Recycling

6Child safety

7Description of the tumble dryer

8Front panel

8Options button

Advice and tips before you

tumble-dry

9Have the clothes been spun?

9Materials that can be tumble-dried

Materials that must not be

tumble-dried

10Tumble drying

10Sort your fabrics

10Turn on the main power switch.

Open the door, load the items and

then close the door

10Select the program

10Press the Start button

12Drying program finished

12Once drying has finished

13Selecting Options

13Low temperature

13Anti-crease function

13Delayed Start

14Care and cleaning

14Cleaning the lint filter

Emptying the condensed water

container

Cleaning the outside of the

machine

15Cleaning the condenser

16Troubleshooting

16The machine will not start

16Overheating cut-out

16Drying takes too long

The washing does not dry, or is

too dry

16Error messages

17Technical information

17Technical data

17Standard tests

18Service

Before contacting the service

division

19Installation

19Positioning the tumble dryer

20Adjusting the feet

20Condensed water

21Electrical installation

22Door hanging

24Quick guide

24Fabrics

24Turn on the main power switch

24Load the laundry

24Select a program and any options

24Press the button

24Drying program finished

24Once tumble-drying has finished

Contents

Do not tumble-dry

Certain materials are not suitable for tumble-

drying. Always check and follow the instruc-

tions on each item's laundry label. You can

find more information in the chapter "Advice

and tips before you tumble-dry".

Note!

When starting the tumble dryer for the first

time or after a long period without use, you

may notice a slight thumping noise. This noise

is completely normal and will disappear after

a few loads.

See the Quick guide on the last page.

Before using your machine for the first time

General

• Read the operating instructions and keep

them in a safe place!

• Electrical installation, if required, should

be carried out by a qualified electrician.

• The machine should only be used for tum-

ble-drying as described in these instruc-

tions.

• Repairs and maintenance must be carried

out by a qualified professional.

• Damaged mains cables must only be re-

placed by a qualified electrician.

• Sufficient ventilation is required to prevent

smoke from open fires or fumes from

equipment burning other fuels being

sucked into the room.

•Do not dry dirty laundry in the tumble dryer.

• Items that are stained with e.g. cooking oil,

acetone, alcohol, petrol, kerosene, stain

remover, turpentine, wax and wax remover

should be washed in hot water with extra

detergent before they go in the tumbler

dryer.

• Items such as foam rubber (latex foam),

shower caps, waterproof textiles, rubber-

coated items and clothes or latex foam-

filled cushions may not be dried in the

tumbler dryer.

• Fabric softener or similar products should

be used as per the recommendations of

the detergent manufacturer.

•The last phase of the drying cycle is carried

out without any heat (cool down cycle).

Caution!

Never stop a tumble dryer before the program

is completed unless you immediately remove

all the laundry and spread it out so that the

heat can disperse.

Installation

See the “Installation” chapter.

Safety

• The machine must not be used for drying

items that have been dry-cleaned at home

or fabrics that may contain residues of

flammable liquids.

• The tumble dryer is protected by an over-

heating cut-out. This shuts off the machine

if the temperature gets too high.

• The appliance is not intended for use by

young children or infirm persons without

supervision.

• The machine automatically cuts off if the

condenser water tank is full or outlet hose

is blocked.

Caution!

When the tumble dryer is operating, the back

of the tumble dryer will get very hot. Leave

the machine to cool completely before

touching the back.

Interrupting a program

You can stop a drying program by:

• Open the door. The drum will then then

stop automatically.

• Press the main power switch.

• Press the Stopp button for three seconds.

When you want to resume tumble-drying,

simply close the door and press the Start

button.

Transport/Winter storage

If you need to move your machine or store it

over the winter in unheated premises, make

sure that you drain the condensed water

container beforehand.

Packing material

Sort waste materials in accordance with local

guidelines.

Safety instructions

Recycling

This machine is manufactured and labelled

for recycling. to prevent injuries, the machine

must be made unusable before disposing of

it.. Contact your local authority for information

about where and how your machine can be

recycled correctly.

• Items that have been spotted or soaked

with vegetable or cooking oil constitute a

fire hazard and should not be placed in a

tumble dryer. Oil-affected items can ignite

spontaneously, especially when exposed

to heat sources such as in a tumble dryer.

The items become warm, causing an oxi-

dation reaction in the oil. Oxidation creates

heat. If the heat cannot escape, the items

can become hot enough to catch fire. Pil-

ing, stacking or storing oil-affected items

can prevent heat from escaping and so

create a fire hazard. If it is unavoidable that

fabrics that contain vegetable or cooking

oil or have been contaminated by hair care

products be placed in a tumble dryer they

should first be washed in hot water with

extra detergent - this will reduce, but not

eliminate, the hazard. The ’cool down’ cy-

cle of tumble dryers should be used to re-

duce the temperature of the items. They

should not be removed from the tumble

dryer or piled or stacked while hot.

• Items that have been previously cleaned

in, washed in, soaked in or spotted with

petrol/gasoline, dry-cleaning solvents or

other flammable or explosive substances

should not be placed in a tumble dryer.

Highly flammable substances commonly

used in domestic environments include

acetone, denatured alcohol, petrol/gaso-

line, kerosene, spot removers (some

brands), turpentine, waxes and wax re-

movers.

• Items containing foam rubber (also known

as latex foam) or similarly textured rubber-

like materials should not be dried in a

tumble dryer on a heat setting. Foam rub-

ber materials can, when heated, produce

fire by spontaneous combustion.

•Fabric softeners or similar products should

not be used in a tumble dryer to eliminate

the effects of static electricity unless this

practice is specifically recommended by

the manufacturer of the fabric softener or

product.

•Undergarments that contain metal reinforce-

ments should not be placed in a tumbledry-

er. Damage to the tumble dryer can result

if metal reinforcements come loose during

drying. When available a drying rack could

be used for such items.

• Plastic articles such as shower caps or

babies’ waterproof napkin covers should

not be placed in a tumble dryer. Rubber-

backed articles, clothes fitted with foam

rubber pads, pillows, galoshes and rubber-

coated tennis shoes should not be placed

in a tumble dryer.

Vented dryers

• There has to be adequate ventilation to

avoid the back flow of gases into the room

from appliances burning other fuels, includ-

ing open fires, when operating the tumble

dryer

• The exhaust air must not be discharged

into a flue which is used for exhausting

fumes from appliances burning gas or

other fuels

Caution!

Air from the tumble dryer must not be fed

through ducts used for equipment that burns

gas or other fuels.

Safety instructions

Do not allow children to play with the

tumble dryer.

The tumble dryer does not start automatically

when the door closes (e.g. if a child closes

the door from inside).

The tumble dryer has a magnetic catch, that

allows the door to be opened from the inside.

The door has a door switch that automatically

stops the tumble dryer when the door is

opened.

Child safety

Outer door5.Panel1.

Fan (behind hatch)6.Condensed water container2.

Condenser (behind the front plate)7.Serial Number3.

Lint filter8.Lint filter holder4.

Description of the tumble dryer

125 6

Main power switch1.

Options buttons2-4

Program selector5.

Display6.

Start/Stop7.

Options button

Button for selecting Low Temperature2.

Button for selecting Anti crease3.

Button for selecting Delayed Start 1-24h4.

Front panel

Here are some tips that may help you before

you begin tumble-drying.

Have the clothes been spun?

Items to be tumble-dried should be spun at

1000 rpm or faster. Higher spin speeds save

both energy and drying time.

Materials that can be tumble-dried

This symbol means that the material is

suitable for tumble-drying. Fabrics best suited

to tumble-drying are cotton fabrics, terry cloth

and synthetic fibres. Garments will be softer

and lighter when tumbled than when hung out

to dry.

Note!

The tumble dryer does not cause any signifi-

cant wear to fabrics. The lint that is trapped

in the lint filter consists of dust and fibre

residues that form when the items are used.

Materials that must not be

tumble-dried

This symbol means that the material is not

suitable for tumble-drying. Certain materials

may melt or become a fire hazard if exposed

to heat, and others can lose their shape or

shrink.

And do not tumble-dry

• materials labelled "Do not dry near heat".

• garments that have been dry-cleaned at

home.

• plastic foam.

• fibreglass material.

• wool because of the risk of felting.

Note!

If the door is opened during the program, the

program will be interrupted and will return to

the start. The clothes may be too damp or too

dry as a result.

Advice and tips before you tumble-dry

Below are step-by-step instructions to help

you achieve the best possible tumble-drying

results.

1Sort your fabrics

You will achieve the most uniform drying

results if the items are made of the same

type of material. Do up zips and buttons, fas-

ten belts, sort the items and adjust the load

and temperature.

2Turn on the main power switch.

3Open the door, load the items

and then close the door

4Select the program

The choice of program depends on what

you intend to do with the items after

drying them.

Guidelines as to what specific programs

can be used for.

Auto Extra dry

Auto Extra dry Auto Normal dry

Auto Iron dry

Timed dry Revitalise

Auto Extra dry

This program is for items that are particularly

difficult to dry, e.g. jeans with very thick

seams.

Note!

Knitted fabrics in particular are prone to

shrinkage. Use the Auto Extra dry, Auto Nor-

mal dry or Auto Iron dry programs for these

items. Stretch clothes back into shape imme-

diately after drying.

Auto Extra dry and Auto Normal dry

These programs shut off the heat once the

load is dry but before it is "bone-dry". The

Auto Extra dry program shuts off the heat

slightly later than Auto Normal dry. Use trial

and error to find out what works best. Use

these programs when you want items to be

completely dry.

Auto Iron dry

This program shuts off the heat once the load

is just damp enough for ironing or pressing.

Timed dry

The Timed dry program has a fixed drying

time and tumble-dries the load for 60 minutes

5Press the Start button

Remaining drying time

An estimate of the remaining drying time will

be shown on the display within 2 minutes of

the drying program starting. For example,

1:35 means that it will take approximately 1

hour and 35 minutes for the load to dry. If the

Anti-crease option has been selected, the

drum will rotate every minute for 2 hours after

cooling.

Stopping or changing a program

Press and hold the Start/Stop button for three

seconds. The red field next to the button will

go out.

Note!

The program will not be affected if you change

the program selector after the program has

started.

Loading or removing washing

If you want to load or remove washing once

you have started the machine, open the door

and the program will stop. Load more washing

or take out the items you want, close the door

and press the Start/Stop button.

Tumble drying

Otros manuales para T712C

Tabla de contenidos

Otros manuales de Secadora de Asko

Asko

Asko T754C Manual de usuario

Asko

Asko T884XLHPW Manual de usuario

Asko

Asko DC 7171 Manual de usuario

Asko

Asko PROFESSIONAL TDC112HPS Manual de usuario

Asko

Asko TD60.C Manual de usuario

Asko

Asko T744C Instrucciones de montaje

Asko

Asko T794 Instrucciones de montaje

Asko

Asko TD75.13XX Manual de usuario

Asko

Asko TLS752GXXL Manual de instrucciones

Asko

Asko T209H Manual de usuario

Asko

Asko PROFESSIONAL TDC112CG Manual de usuario

Asko

Asko T700 Series Manual de usuario

Asko

Asko T743C Manual de instrucciones

Asko

Asko T721 Manual de usuario

Asko

Asko TL751 XXLW Manual de usuario

Asko

Asko T783 Manual de usuario

Asko

Asko T784C W Manual de usuario

Asko

Asko T743C Instrucciones de montaje

Asko

Asko DC7583 Manual de instrucciones

Asko

Asko TL751 XXL Guía de solución de problemas

Asko

Asko T744 Instrucciones de montaje

Asko

Asko T753 Manual de usuario

Asko

Asko 7003 Instrucciones de funcionamiento

Asko

Asko TDC Instrucciones de montaje

Manuales populares de Secadora de otras marcas

Bosch

Bosch WTA79200GB Manual de usuario

Amana

Amana W10233410A Manual de usuario

Miele

Miele TWH 780 WP Manual de usuario

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Manual de usuario

Bosch

Bosch Logixx 10 WTB76556GB Hoja de especificaciones

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Manual de instrucciones

Electrolux

Electrolux EW2H328R2 Manual de usuario

Beko

Beko DS8433RX1M Manual de usuario

Dawlance

Dawlance Spinner DS 6000 C Manual de usuario

Electrolux

Electrolux TP5080TW Manual de usuario

AEG

AEG TR838P4OB Manual de usuario

Indesit

Indesit IDV 75 Manual de usuario

Infiniton

Infiniton SD-DG85C Manual de usuario

BOMANN

BOMANN WT 5019 Manual de usuario

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Manual de usuario

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Manual de usuario

Frigidaire

Frigidaire CAQE7077KW0 Manual del propietario

Bosch

Bosch WTX8HKM9SN Manual de usuario
