ASHDOWN TONE POCKET - HEADPHONE PRE AMP USER GUIDE

The Ashdown Tone Pocket in the answer to your practising needs and is the product you never

knew you needed until now. With powerful features including a 3 band EQ, Line Input, Headphone

output on the front.

There is a very well conected rear panel with a USB recording output for use with any DAW, the

tone pocket doubles up as a sound card for your bass recording needs. You never know when you

might want to lay down a new bass line...

The USB socket also doubles as a charger for desktop use.

The Tone Pocket is powered by a rechargeable 9v battery located internally (it can be changed if

required by removing the rear panel). Supplied with the Tone Pocket is a 10v DC power supply

centre pin negative as well as a 12v in car power supply for use with a 12v in car socket.

There is a balanced line output on the rear of the Tone Pocket to connect your Tone Pocket to an



The Tone Pocket is very compact measuring in at H: 26mm W: 108mm D:95mm and weighing only

272grams. Perfect for keeping in your back pocket or sat on your desktop, you will never want to

leave home without it.

The light weight black anodised alloy extrusion ensures durability and sleek looks with the CNC

machined front panel with diamond polished detailing sets the knobs back from the pot to ensure

they don’t get knocked and damaged.

What’s inside the box:

- 1 x Tone Pocket in soft case

- 1 x USB to USB cable

- 1 x Headphone 1/4” adaptor

- 1 x 10v power supply

- 1 x 12v in-car charger

- 1 x Pack of 4 self adhisive rubber feet

USER GUIDE

Front Panel:

ASHDOWN TONE POCKET - HEADPHONE PRE AMP

1. 2. 3. 4. 5.

26mm

6. 7. 8. 9.

Front Panel:

1-

INPUT - Instrument input socket for use with

Jack to Jack

2-

LINE IN - 3.5mm Jack socket for use conecting

a line level audio device such as an MP3

player or alike...

3-

3 BAND EQ - Roatery controls Bass, Mids &

Highs, what more could you need +/- 15dB

on each band.

4-

VOLUME - Roatery control master volume output level

control.

5-

PHONES - 1/4” Headphone output socket for use with

any quality headphones. We reconmend Meters OV-1

available directly via ashdownmusic.com USE:

‘TONEPOCKET18’ at checkout for a 20% discount on

OV-1 headphones.

USER GUIDE

ASHDOWN TONE POCKET - HEADPHONE PRE AMP

Rear Panel:

6-

LINE OUT - Balanced line out

7-

USB - Use the Tone Pocket as a sound

card with its built in USB codec record

and monitor your recordings on the go.

Also keep it charged via USB 5.1v - 2.1

8-

DC 10v - Center pin negative 10v power

supply input for charging.

9-

DC-12v - Center pin positive 12v power

supply input for use with in car charger

or on a bus...

Rear Panel:

1. 2. 3. 4. 5.

26mm

6. 7. 8. 9.

USER GUIDE

ASHDOWN TONE POCKET - HEADPHONE PRE AMP

Top View:

108mm

95mm
