A R R I S

Xfinity TG1682

Telephony Gateway

User's Guide

Get ready to experience the Internet's express lane! Whether you're checking out

streaming media, downloading new software, checking your email, or talking with

friends on the phone, the Xfinity TG1682 Telephony Gateway brings it all to you

faster and more reliably. All while providing toll quality Voice over IP telephone ser-

vice and both wired and wireless connectivity. It also supports a Lithium-Ion bat-

tery backup to provide continued telephone service during power outages.

The Xfinity Telephony Gateway provides four Ethernet connections for use as the

hub of your home/office Local Area Network (LAN). The Xfinity Telephony Gateway

also provides 802.11a/b/g/n wireless connectivity for enhanced mobility and ver-

satility. In addition, the Xfinity Telephony Gateway provides for up to two separate

lines of telephone service and Digital Enhanced Cordless Telecommunications

(DECT) funtionality to allow using cordless telphones within the home. The Tele-

phony Gateway also offers integrated MoCA 2.0 home networking providing Inter-

net access and transfer of multimedia content between devices over coaxial cable

in the home.

Installation is simple and your cable company will provide assistance to you for

any special requirements. The links below provide more detailed instructions.

Safety Requirements

Getting Started

Battery Installation and Removal

Installing and Connecting Your Telephony Gateway

Configuring Your Ethernet Connection

Using the Telephony Gateway

Troubleshooting

Glossary

Export Regulations

This product may not be exported outside the U.S. and Canada without U.S. Department of Commerce, Bureau of Export Administra tion au-

thorization. Any export or re-export by the purchaser, directly or indirectly, in contravention of U.S. Export Administration Regulation is prohib-

ited.

derivative work (such as translation, transformation, or adaptation) without written permission from ARRIS Enterprises, Inc. ("ARRIS"). ARRIS

reserves the right to revise this publication and to make changes in content from time to time without obligation on the part of ARRIS to provide

notification of such revision or change.

ARRIS provides this guide without warranty of any kind, implied or expressed, including, but not limited to, the implied warranties of mer -

chantability and fitness for a particular purpose. ARRIS may make improvements or changes in the product(s) described in this manual at any

time. The capabilities, system requirements and/or compatibility with third-party products described herein are subject to change without no-

tice.

ARRIS and the ARRIS logo are all trademarks of ARRIS Enterprises, Inc. Other trademarks and trade names may be used in this document to

refer to either the entities claiming the marks and the names of their products. ARRIS disclaims proprietary interest in the marks and names of

others.

Protected under one or more of the following U.S. patents: 7,031,435. Other patents pending.

Release 16 Draft 1.0 February 2014

Xfinity TG1682 Telephony Gateway User's Guide 3

A R R I S

Getting Battery Ethernet

Safety Started Installation Installation Configuration Usage Troubleshooting Glossary

Safety Requirements

These Telephony Gateways comply with the applicable requirements for perform-

ance, construction, labeling, and information when used as outlined below:

CAUTION

Risk of shock

Mains voltages inside this unit. No user serviceable parts inside. Refer

service to qualified personnel only!

CAUTION

Potential equipment damage

Potential loss of service

Connecting the Telephony Gateway to existing telephone wiring should

only be performed by a professional installer. Physical connections to

the previous telephone provider must be removed and the wiring must

be checked; there must not be any voltages. Cancellation of telephone

service is not adequate. Failure to do so may result in loss of service

and/or permanent damage to the Telephony Gateway.

CAUTION

Risk of explosion

Replacing the battery with an incorrect type, heating a battery above

75°C, or incinerating a battery, can cause product failure and a risk of

fire or battery explosion. Do not dispose of in fire. Recycle or dispose

of used batteries responsibly and in accordance with local ordinances.

The Telephony Gateway is designed to be connected directly to a telephone.

Connecting the Telephony Gateway to the home's existing telephone

wiring should only be performed by a professional installer.

Do not use product near water (i.e. wet basement, bathtub, sink or near a

swimming pool, etc.), to avoid risk of electrocution.

Xfinity TG1682 Telephony Gateway User's Guide 4

A R R I S

Getting Battery Ethernet

Safety Started Installation Installation Configuration Usage Troubleshooting Glossary

Do not use spray cleaners or aerosols on the Telephony Gateway.

The product shall be cleaned using only a damp, lint-free, cloth. No solvents or

cleaning agents shall be used.

Avoid using and/or connecting the equipment during an electrical storm, to

avoid risk of electrocution.

Do not use the telephone to report a gas leak in the vicinity of the leak.

Do not locate the equipment within 6 feet (1.9 m) of a flame or ignition source

(i.e. heat registers, space heaters, fireplaces, etc.).

Use only power supply and power cord included with the equipment.

Equipment should be installed near the power outlet and should be easily

accessible.

The shield of the coaxial cable must be connected to earth (grounded) at the

entrance to the building in accordance with applicable national electrical in-

stallation codes. In the U.S., this is required by NFPA 70 (National Electrical

Code) Article 820. In the European Union and in certain other countries, CATV

installation equipotential bonding requirements are specified in IEC 60728-11,

Cable networks for television signals, sound signals and interactive

services, Part 11: Safety. This equipment is intended to be installed in

accordance with the requirements of IEC 60728-11 for safe operation.

If the equipment is to be installed in an area serviced by an IT power line

network, as is found in many areas of Norway, special attention should be

given that the installation is in accordance with IEC 60728-11, in particular

Annex B and Figure B.4.

In areas of high surge events or poor grounding situations and areas prone

to lightning strikes, additional surge protection may be required (i.e.

PF11VNT3 from American Power Conversion) on the AC, RF, Ethernet and

Phone lines.

When the Telephony Gateway is connected to a local computer through Eth-

ernet cables, the computer must be properly grounded to the building/res-

idence AC ground network. All plug-in cards within the computer must be

properly installed and grounded to the computer frame per the manufacturer's

specifications.

Xfinity TG1682 Telephony Gateway User's Guide 5

A R R I S

Getting Battery Ethernet

Safety Started Installation Installation Configuration Usage Troubleshooting Glossary

Ensure proper ventillation. Position the Telephony Gateway so that air flows

freely around it and the ventillation holes on the unit are not blocked.

Do not mount the Telephony Gateway on surfaces that are sensitive to heat

and/or which may be damaged by the heat generated by the modem, its power

supply, or other accessories.

FCC Part 15

This equipment has been tested and found to comply with the requirements for a

Class B digital device under Part 15 of the Federal Communications Commission

(FCC) rules. These requirements are intended to provide reasonable protection

against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in ac-

cordance with the instructions, may cause harmful interference to radio communi-

cations. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on,

the user is encouraged to try to correct the interference by one or more of the fol-

lowing measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

Warning: Changes or modifications to this equipment not expressly approved by the

party responsible for compliance could void the user's authority to operate the

equipment.

RF Exposure

This equipment complies with FCC radiation exposure limits set forth for an uncon-

trolled environment. This equipment should be installed and operated with minimum

distance of 7.9 inches (20cm) between the radiator and your body. This transmitter

must not be co-located or operating in conjunction with any other antenna or

transmitter.

Xfinity TG1682 Telephony Gateway User's Guide 6

A R R I S

Getting Battery Ethernet

Safety Started Installation Installation Configuration Usage Troubleshooting Glossary

Getting Started

About Your New Telephony Gateway

The Xfinity TG1682 Telephony Gateway is DOCSIS compliant with the following fea-

tures:

Speed: much faster than dialup or ISDN service; up to eight times faster than

DOCSIS 2.0 cable modems.

Convenience: supports Ethernet and 802.11a/b/g/n wireless connections;

both can be used simultaneously

Flexibility: provides two independent lines of telephone service as well as high

speed data

Compatibility:

Data services: DOCSIS 3.0 compliant and backward-compatible with

DOCSIS 2.0 or 1.1; supports tiered data services (if offered by your cable

company)

Telephony services: PacketCableTM 1.5 or 1.0 compliant

DECT support for CAT-iq 2.0 compliant DECT 6.0 hardware with multi line

calling capabilities

The TG1682 provides:

Wireless 802.11a/b/g/n connectivity

Four Ethernet ports for connections to non-wireless devices

Up to two lines of telephone service with Digital Enhanced Cordless Telecom-

munications (DECT) funtionality

Integrated MoCA 2.0 home networking

DOCSIS 3.0 compliant with Li-Ion backup battery

Two USB host ports (future support for external USB devices)

Xfinity TG1682 Telephony Gateway User's Guide 7

Coax Cable

Phone Cable

A R R I S

Getting Battery Ethernet

Safety Started Installation Installation Configuration Usage Troubleshooting Glossary

What's in the Box?

Make sure you have the following items before proceeding. Call your cable

company for assistance if anything is missing.

Telephony Gateway

Power Cord

Quick Installation Guide

End User License Agreement

Items You Need

If you are installing the Telephony Gateway yourself, make sure you have the fol-

lowing items on hand before continuing:

Telephony Gateway package: see What's in the Box? for a list of items

in the package.

Coaxial cable (coax): as shown in the image to the left, this is a round

cable with a connector on each end. It is the same kind of wire used to

connect to your television for cable TV. You can buy coax from any

electronics retailer and many discount stores; make sure it has connectors

on both ends. There are two types of connectors, slip-on and screw-on;

the screw-on connectors are best for use with your Telephony Gateway.

The coax should be long enough to reach from your Telephony Gateway to

the nearest cable outlet.

Note: For best performance, use high-quality RG-6 type coax cable and mini-

mize or eliminate splitters between the cable jack and the Telephony Gateway.

Phone Cable: as shown in the image to the left, this is a standard phone

cable with standard phone connectors (RJ11 type) on both ends. You can

buy phone cables from any electronics retailer and many discount stores.

Splitter (optional): provides an extra cable connection by splitting a single

outlet into two. You may need a splitter if you have a TV already connected

to the cable outlet that you want to use. You can buy a splitter from any

electronics retailer and most discount stores; you may also need a short

piece of coax cable (with connectors); use it to connect the splitter to the

cable outlet and then connect the Telephony Gateway and TV to the splitter.

Ethernet Cable

Xfinity TG1682 Telephony Gateway User's Guide 8

A R R I S

Getting Battery Ethernet

Safety Started Installation Installation Configuration Usage Troubleshooting Glossary

Note: A splitter effectively cuts the signal in half and sends each half to its

two outputs. Using several splitters in a line may deteriorate the quality of

your television, telephone, and/or internet connection.

Ethernet Cable(s): as shown in the image to the left, this is a Category 5e

(CAT5e) straight-through cable for connecting computers to the Gateway.

Wall-mount hardware (optional): if you want to wall-mount your Tele-

phony Gateway, you need to obtain two drywall anchors or wood screws.

See the Wall-Mount Template and Instructions for more details.

Information packet: your cable company should furnish you with a packet

containing information about your service and how to set it up. Read this in-

formation carefully. Contact your cable company if you have any questions.

Getting Service

Before trying to use your new Telephony Gateway, contact your local cable

company to establish an Internet account and telephone service. When you call,

have the following information ready:

the Telephony Gateway serial number and cable MAC addresses of the

unit (printed on a sticker on the bottom of the Telephony Gateway)

the model number of the Telephony Gateway

If the Telephony Gateway was provided by your cable company, they already

have the required information.

In addition, you should ask your cable company the following questions:

Do you have any special system requirements or files that I need to down-

load after I am connected?

When can I start using my Telephony Gateway?

Do I need a user ID or password to access the Internet or my e-mail?

Will my phone number(s) change?

What new calling features will I have and how do I use them?

Xfinity TG1682 Telephony Gateway User's Guide 9

A R R I S

Getting Battery Ethernet

Safety Started Installation Installation Configuration Usage Troubleshooting Glossary

System Requirements

The Telephony Gateway operates with most computers. The following describes

requirements for each operating system; see the documentation for your system

for details on enabling and configuring networking.

To use the Telephony Gateway, you need DOCSIS high-speed Internet service

from your cable company. Telephone service requires that the cable company has

Pack-etCable support.

Recommended Hardware

The following hardware configuration is recommended. Computers not meeting

this configuration can still work with the TG1682, but may not be able to make

maximum use of TG1682 throughput.

CPU: P4, 3GHz or faster

RAM: 1GB or greater

Hard drive: 7200 RPM or faster

Ethernet: Gig-E (1000BaseT)

Windows

Windows XP, Windows Vista, Windows 7, or Windows 8. A supported Ethernet or

wireless LAN connection must be available.

MacOS

System 7.5 to MacOS 9.2 (Open Transport recommended) or MacOS X. A

supported Ethernet or wireless LAN connection must be available.

Linux/other Unix

Hardware drivers, TCP/IP, and DHCP must be enabled in the kernel. A supported

Ethernet or wireless LAN connection must be available.

Xfinity TG1682 Telephony Gateway User's Guide 10

Model

Number

1.1.04.18dM

IMMIZEIHMEI

013014=1.4.1.1...11

133.1)11.0.10.. 4.4

01.M101.401Pia.....1

A R R I S

Getting Battery Ethernet

Safety Started Installation Installation Configuration Usage Troubleshooting Glossary

About this Manual

This manual covers the Xfinity TG1682 Telephony Gateway. The model number is

on the label affixed to the bottom of the Telephony Gateway. See the image at the

left.

What About Security?

Having a high-speed, always-on connection to the Internet requires a certain amount

of responsibility to other Internet users—including the need to maintain a reasonably

secure system. While no system is 100% secure, you can use the following tips to

enhance your system's security:

Keep your operating system updated with the latest security patches. Run the

system update utility at least weekly.

Keep your email program updated with the latest security patches. In addition,

avoid opening email containing attachments, or opening files sent through

chat rooms, whenever possible.

Install a virus checker and keep it updated.

Avoid providing web or file-sharing services over your Telephony Gateway.

Besides certain vulnerability problems, most cable companies prohibit running

servers on consumer-level accounts and may suspend your account for

violating your terms of service.

Use the cable company's mail servers for sending email.

Avoid using proxy software unless you are certain that it is not open for

abuse by other Internet users (some are shipped open by default). Crimi-

nals can take advantage of open proxies to hide their identity when break-

ing into other computers or sending spam. If you have an open proxy, your

cable company may suspend your account to protect the rest of the net-

work.

If you use the wireless LAN, make sure you enable wireless security on the

Telephony Gateway (for the same reasons that you should run only secured

proxies). See Configuring Your Wireless Connection.

Otros manuales para Xfinity TG1682

Tabla de contenidos

Otros manuales de Puerta de Arris

Arris

Arris NVG5X8 Manual de usuario

Arris

Arris Touchstone TG1652 Manual de usuario

Arris

Arris Touchstone DG1680 Manual de usuario

Arris

Arris BGW210-700 Manual de usuario

Arris

Arris Touchstone TG3452 Manual

Arris

Arris TG 3442 Manual de usuario

Arris

Arris Touchstone DG3450 Manual de usuario

Arris

Arris Touchstone TG9452 Manual de usuario

Arris

Arris Touchstone TG862G/NA Manual de usuario

Arris

Arris Touchstone OG1600 Manual de usuario

Arris

Arris SURFboard SBG6580 Manual de usuario

Arris

Arris Touchstone TG2472 Manual de usuario

Arris

Arris Touchstone DG1670 Manual de usuario

Arris

Arris SURFboard SBG6580 Manual de usuario

Arris

Arris Touchstone TG852 Manual de usuario

Arris

Arris Touchstone TG4482 Manual de usuario

Arris

Arris SURFboard SBG7400AC2 Manual de usuario

Arris

Arris NVG599 Manual de usuario

Arris

Arris Touchstone TG952 Manual de usuario

Arris

Arris Touchstone DG950 Manual de usuario

Arris

Arris SurfBoard SVG2482AC Manual de usuario

Arris

Arris SURFboard SBG7580-AC QSG Manual de usuario

Arris

Arris SURFboard SBG7580-AC QSG Manual de usuario

Arris

Arris SURFboard SBG7580-AC QSG Manual de usuario

Manuales populares de Puerta de otras marcas

LST

LST M500RFE-AS Manual de usuario

Kinnex

Kinnex Media Gateway Manual de usuario

2N Telekomunikace

2N Telekomunikace 2N StarGate Manual de usuario

Mitsubishi Heavy Industries

Mitsubishi Heavy Industries Superlink SC-WBGW256 Manual de usuario

ZyXEL Communications

ZyXEL Communications ZYWALL2 ET 2WE Manual de usuario

Telsey

Telsey CPVA 500 - SIP Manual de usuario

RTA

RTA 460A-NNA4 Hoja de especificaciones

Shaw

Shaw Gateway HDPVR Manual de usuario

ABB

ABB VSN900 Guía de inicio rápido

Commander

Commander Pulse Manual de usuario

2N Telekomunikace

2N Telekomunikace ATEUS EasyGate 501309E Manual de usuario

NETGEAR

NETGEAR C6300BD Manual de usuario

Amit

Amit CDW531AM Manual de usuario

HMS

HMS Netbiter EasyConnect EC150 Manual de usuario

Huawei

Huawei EchoLife HG620 Manual de usuario

AT&T

AT&T U-verse 3801 Manual de uso y cuidado

Logic IO

Logic IO RTCU MX2 turbo Manual de usuario

Suttle

Suttle MediaMAX MXM-521 Manual de usuario
