Arjo Miranti Manual de usuario
Hand control Control panel Raise the stretcher.
Lower the stretcher.
Raise the backrest.
Lower the backrest.
Apply the central brake.
Flashing light = brakes activated
Release the central brake.
Emergency high/lowEmergency stop
Insert thin, blunt object into the hole
and press to raise or lower the lift bath
trolley.
Do not use sharp object.
Push button and pull out
battery. Unplug the hand control.
Backrest and hook rope
Turn hook upwards.
Use buttons to raise
or lower the backrest
Attach hook rope to the button
head on the side of the stretcher.
!3
!2
!1
!1!2
08.CE.05EN_1 • 06/2020 • Page 1/2
QUICK REFERENCE GUIDE - FUNCTIONS
Miranti
Side guard and patient security grip
Lift handle upwards. Lower handle away from
patient’s head.
Position the side guard.
Power drive
3UHVVDQGKROGEXWWRQWRORZHU¿IWKZKHHODQGVWDUWHOHFWULFGULYH
motor.
Thigh support cushion
To attach To remove
!1!2!3
ArjoHuntleigh AB
Hans Michelsensgatan 10
211 20 Malmö, Sweden
www.arjo.com 08.CE.05EN_1 • 06/2020 • Page 2/2
