Argox AP-9800 Manual de usuario

2D Image Bar Code Scanner

Instruction Manual

v1.4-s

Connection

Connect the scanning gun to the special connector from the cable,

inserted the other end of cable into the corresponding port of the PC.

Please open the bar code configuration switch on the second page

if the bar code configuration switch has been turned off

Interface Mode

This scanning gun supports three kinds of interface modes，RS232 port

and USB keyboard and USB turning to RS232.

Scan the following bar code can be configured as the RS232

scanning mode. (Default mode)

RS232

Scan the following bar code can be configured as the USB keyboard

scanning mode.

USB (default)

Scan the following bar code can be configured as the USB turned to

USB keyboard mode

USB turning to RS232

Enable / Disable configuration code

When the configuration code is open, you can scan all the configuration bar code for

scanning gun configuration. When the configuration code is closed, the other

configuration bar code can not be scanned. Need to re open before scanning the

configuration code to scan the gun configuration

Enable configuration code（Default）

Disable configuration code

Product default configuration

Scan the following bar code can be returned to the factory default configuration.

returned to the factory default configuration

Product user configuration

Scan the following bar code to save the current parameters of the product to the user

configuration.

Save user configuration

Scan the following bar code to recovery the user configuration.

Recovery user configuration

The RS232 baud rate configuration

Baud rate 4800

Baud rate 9600（Default）

Baud rate 19200

Baud rate 38400

Baud rate 57600

Baud rate 115200

Auto-sensing Scan Mode

This product has auto-sensing scan mode. Scan the following bar code to configure

the switch

Disable Automatic Recognition Mode

When theself sensing mode is configured to be closed, Decoded by the trigger of the

scanning gun.Default configuration.

Disable auto-sensing scan Mode (Default)

EnableAutomatic Recognition Mode

When the self sensing mode is configured to be open,The scanning gun

can decode automatically by scanning lens before the bar code

Enable auto-sensing scan Mode

Screen Reading Mode

When you turn on this mode, Scanners can be decoding the codes on

phone or computer. However, Turn on this code will be cause lower speed when

scanning printing codes. The default is turn off.

Disable screen reading mode（Default）

Enable screen reading mode

Focus Mode

When focus mode is turn on, The scanner only identified the focus

codes scanners lens covering, The default is turn off.

Disable Focus Mode（Default）

Enable focus mode

Suffix Setting

Cancel / enter Tab

Add Enter

Add Tab

Add Enter+Tab（Default）

BUZZER volume

Volume-low

Volume-high(default)

Scanner launch prompt tone

Enable

Disable ( default mode)

Successful decoding prompt tone ON-OFF

Off

On (default)

Successful decoding prompt tone GHZ(volume)

Volume-low

Volume-middle(default)

Volume-high

Successful decoding prompt tone time

LONG(default)

Short

Error Warming

Volume-low(default)

Volume-middle
