Argos Java 156/5465 Manual de usuario

Issue1-30/06/12IW-17-3235-575/576/595/596-0

Java -Double/ King Bed Frame

AssemblyInstructions -Please keepforfuturereference

Dimensions

Width-146.6/160.1cm

Depth-200.4/209.4cm

Height-35cm

Important -Pleaseread theseinstructionsfullybeforestarting assembly.

Ifyouneedhelporhavedamagedormissingparts,call the CustomerHelpline:08456400800

156/5465

149/2057

156/6763

156/6770

•Checkyouhaveallthe

componentsandtoolslisted

onpages2and3.

•Remove all fittingsfromthe

plasticbagsandseparate

themintotheirgroups.

•Keepchildrenandanimals

away fromtheworkarea,

small partscouldchoke if

swallowed.

•Makesureyouhaveenough

spacetolayouttheparts

beforestarting.

•Donotstandorputweight

ontheproduct,thiscould

causedamage.

•Assembletheitemas close

toitsfinalposition(inthe

sameroom)aspossible.

•Assembleonasoftflat/

firm surfacetoavoid

damagingtheunitoryour

floor.

•Partsoftheassemblywill

beeasierwith2people.

•Wedonot

recommendthe

useofpower

drill/ drivers for

inserting screws,

asthiscoulddamagetheunit.

Onlyuse hand screwdrivers.

•Disposeofallpackaging

carefullyand responsibly.

Safetyand CareAdvice

Important -Pleasereadtheseinstructionsfullybeforestartingassembly.

Careand maintenance

•Onlycleanusingadamp

clothandmilddetergent, do

no use bleachorabrasive

cleaners.

•Fromtimetotimecheck that

thereareno loose screwson

thisunit.

•Thisproductshouldnotbe

discardedwithhousehold

waste. Take toyourlocal

authoritywastedisposal

centre.

ifrequiredthenext

pagecanbecutoutand used

asreferencethroughoutthe

assembly. Keepthispagewith

theseinstructionsforfuture

reference.

Components -Panels Ifyou have damagedormissing

components,calltheCustomerHelpline:

08456 400800

Pleasecheckyouhaveallthepanelslistedbelow

Headpostx2

(4.3x35cm)

Headend

(138.6/152.1x12cm)

Footend

(138.6/152.1x12cm)

Siderailx2

(191.8/200.8x12cm)

Footpostx2

(4.3x35cm)

Sprungslatsx28

(68.7/75.5x7cm)

Metalcenterrail

(192.5/201.5x2.6cm)

Adjustablecenterleg

(29 x7.5cm)

Note: Thequantities below arethecorrectamounttocompletetheassembly. Insomecases

morefittingsmay besuppliedthanarerequired.

Bracket x2 17mm Flat headscrewx8 Steeldowelx14

Allenkeyx1 Centerplasticsleevex14

End plasticsleevex28 Wooden dowelx4

Grub screwx14

ABC

D E F

G H

Phillipsscrewdriver

(medium&large)

Tool required

0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 110115120125130135140145150105 155160165170

Ruler-Usethisrulertohelpcorrectlyidentifythescrews

Components -Fittings

Please check you have all thefittingslistedbelow

Step1

Fittingdowels

a: Screw14steel

dowelsintohead

postsand foot posts

Note: Insertsteel

dowelsasfarasshown.

Ensurethe direction of

the holeson fittingsare

facingcorrectlyasper

diagram.

Useascrewdrivertoturn

fittingclockwisetofix.

b: Insert 4wooden

dowelsintopre-drilled

holeson bothendsof

footend asshown.

Note: Insertwooden

dowelsasfarasshown.

Step2

Attachingbrackets.

Attach2bracketsonto

thepre-drilledholeson

headend andfootend

using 8flat head

screwsasshown.

Usescrewdrivertoturn

flatheadscrews

clockwisetofix.

AssemblyInstructions

CHC C

C C

Inset fitting

AssemblyInstructions

Step3

Attachingheadend,

footendandlegs.

a: Position left &right

head postsonto

headend .

Note: Ensuresteel

dowelsarealigned

correctlywithmating

holestoavoiddamage.

Fixheadend and

head postsusing 4

grubscrewsasshown.

Usescrewdrivertoturn

fittingclockwisetofix.

b: Position left &right

foot postsonto

footend .

Note: Ensuresteel

dowelsandwooden

dowelsarealigned

correctlywithmating

holestoavoiddamage.

Fixfootend and foot

postsusing 2grub

screwsasshown.

Usescrewdrivertoturn

fittingclockwisetofix.

AssemblyInstructions

Step4

Attaching siderails.

Twopeopleareneeded

here.

Positionbothsiderails

ontoheadend and

footend .

Note: Ensuresteel

dowelsarealigned

correctlywithmating

holestoavoiddamage

and the label"THISSIDE

UP"isfacingupwardson

bothsiderails.

Fixbothside railsto

headend andfootend

using8grubscrews

Useascrewdrivertoturn

fitting clockwisetofix.

Step5

Attachingcenterlegto

centerrail.

a: Removetopbracket

fromadjustablecenter

leg using allen key.

Turnbolts

counter-clockwiseto

undo.

b: Positionadjustable

centerleg half way

along centerrail, and

fixinplaceby

re-attaching top bracket.

Useallen keytoturn

boltsclockwisetofix.

AssemblyInstructions

Step6

Attaching centerrail.

a: Placecenterrail

intobracketson

headend andfootend

asshown.

b: Turnbaseof

adjustablecenterleg

toadjust the height of

centerrail until the

centerrailrestsfirmlyin

thebrackets.

Step7

Assemblesprung slats.

a: Fix28endplastic

sleevestoone end of

28 sprung slatsas

shown.

b: Fix14centerplastic

sleevestoeverypair

of sprung slatsas

shown.

Step8

Attachingsprungslats.

Snapplasticdowelson

endplasticsleeves

andcenterplastic

sleevesintoplacein

pre-drilledholeson

centerandsiderailsof

bedasshown.

Assemblyiscomplete.

AssemblyInstructions

Ifyouneedhelporhavedamagedormissingparts,call the CustomerHelpline:08456400800
