Archos GamePad Manual de usuario

ENEN

Table of contents

For more information, please consult the FAQs on www.archos.com. Make sure to read them before

considering any product return. Your deal may be no big deal. As we are often updating and improving

our products, your device’s software may have a slightly different appearance or modified functionality

than presented in this quick start guide.

Package Contents..................................................................................................................................

Getting started.......................................................................................................................................

Description of the device....................................................................................................................

Through the wizard...............................................................................................................................

Connecting to a WiFi network...........................................................................................................

ARCHOS mapping tool........................................................................................................................

AndroidTM interface..............................................................................................................................

Getting familiar with AndroidTM......................................................................................................

Troubleshooting...................................................................................................................................

A70GT_FRONT VIEW_scale: 1/2

Warranty

Package Contents

ARCHOS GamePad

USB cable Charger

QSG booklet

Warranty legal & safety booklet

Getting Started

Charging

Charge your device by plugging your power cable into the micro-USB port.

The GamePad will turn on and start charging.

The charging indicator is red when the battery is charging.

The charging indicator becomes orange when the battery is charged.

You can use your GamePad whilst it charges.

TIPS:

-Let your device charge completely the first time you use it.

-Use only the supplied charger.

-To receive more complete service, please register your product on www.archos.com/register.

A70GT_FRONT VIEW_scale: 1/2

A70GT_TOP VIEW_scale: 1/2

897

3 4 6

A70GT_BACK VIEW_scale: 1/2

Description of the device

112

134

716

918

* With optional Mini-HDMI to HDMI cable.

Volume buttons Directional pad

ON/OFF button A, B, Y, X buttons

Micro-USB port L2 button

Headphone jack R2 button

Microphone Analog sticks

Mini-HDMI video output* SELECT button

L1 button START button

Camera Loudspeakers

R1 button Micro-SD card slot

Through the Wizard

TIP:

We recommend that you set up your GamePad in the WiFi zone of the network that you will regularly

be using.

The rst time you start up your GamePad, the installation wizard will help you set up your

device:

-Touch-screen calibration

-Language

-Date & time

-WiFi connection

-Location service options

-3rd party apps

Connectivity to a WiFi Network

TIPS:

-When entering a WiFi password, we recommend that you select“Show password” so you can see the

characters you are typing.

-To get the correct WiFi password (or settings) for the network, contact the WiFi network provider.

-If your WiFi is on and you are in range of a network that you previously connected to, your GamePad

will automatically attempt to connect to it.

WARNING: Make sure that you are in a WiFi zone.

1. Touch the time in the status bar.

The status dashboard is displayed.

2. Touch the time a second time in the status dashboard.

The quick settings will be displayed.

3. Touch "WiFi" to open the WiFi settings menu.

4. If the WiFi is o, slide the WiFi switch to the "ON" position.

Once the WiFi is on, the GamePad will scan for WiFi networks in range.

5. Touch the name of network you want to connect to.

Private networks are shown with a lock icon and will require you to enter a password.

A70GT_FRONT VIEW_scale: 1/2

ARCHOS mapping tool

Tip2:

Whenever you launch a game whose virtual

controls are mapped, the right mapping profile

will automatically be selected.

Tip1:

Within ARCHOS mapping tool, there are already

mapping profiles for over 100 games. Also, many

games function automatically with physical

buttons.

ARCHOS mapping tool is an application installed in your GamePad. It allows you to link the

virtual controls of games to the physical controls of the GamePad by using mapping controls.

physical

control

mapping

control

virtual

control

A70GT_FRONT VIEW_scale: 1/2

Starting ARCHOS mapping tool

1. Launch a game.

When you reach the starting screen, the virtual controls are displayed.

2. Select the ARCHOS mapping tool icon from the system bar.

The mapping overlay is displayed with the mapping tool interface.

ARCHOS mapping tool interface

ARCHOS mapping tool icon

A70GT_FRONT VIEW_scale: 1/2

Positioning a mapping control

Hold and drag a type of mapping control to the desired virtual button.

Button

It is for the directional pad

, , , , the X, Y, B, A, buttons

and the L1, R1, L2, R2, Start,

Select buttons.

Stick

It is for the analog

directional sticks.

Target

It is for analog stick

targetting. It is placed

normally in the central

area of the screen on

shooting games.

There are three types of mapping control
