Welcome to Video Surveillance Done Right™. Archersh is the only smart, wireless

security camera and recorder that can understand what it sees and send video alerts

when important things happen. While the Geng Started with Archersh Solo insert

provides an overview, this guide takes you step-by-step to set up and personalize your

Archersh system.

For addional help or troubleshoong, contact Archersh Customer Support at

support@myarchersh.com or 877.3.THEFISH (877.384.3347) 8:00 am to 9:00 pm Eastern

Time (Monday through Saturday). Online Help is available anyme at www.myarchersh.

com/solosetup.

Note: The order of steps outlined in this document may dier from the order presented

in the Geng Started with Archersh Solo insert. While either order will work, we

recommend you follow the process outlined in this document.

Welcome

page 01Archersh Solo Installaon Guide

Page

Your Archersh Solo comes with the items pictured in Figure 1.

Other things you’ll need to set up are:

- PC (Microso® Windows® XP, Vista, or 7)

or Apple® Mac® (OS X v10.6 or higher)

- One of the following browsers:

Microso®Internet Explorer® (version 7 or higher)

Mozilla®Firefox® (version 3.5 or higher)

Apple®Safari® (version 5 or higher)

- Acve broadband Internet connecon with an upload speed of at least

512 kbps

- Wireless router (with available port for inial setup) connected to the

Internet

- Phillips and sloed (“athead”) screwdrivers

Before You Start Make Sure You Have What You Need

page 02Archersh Solo Installaon Guide

Figure 1 Archersh Solo items

Archersh Solo Device

MicroSD Card

Archersh Solo Mount Base

Archersh Solo Mount with Rotang Joint

Archersh Solo Power Supply

Three Screws

Ethernet Adaptor (usually not needed)

Before you register your Solo device, connect the Ethernet connector to your

wireless router and then connect the power connector to the power supply

(Figure 2).

Next, plug in the power supply.

Wait for the small LED light on the boom of Solo to turn green before

proceeding to the next page. It may take several minutes for the light to turn

green.

Note: The LED light on the Solo device uses dierent color and blink

paerns to tell you what it’s doing. For a summary of all the dierent LED

states, see Appendix A on page 22.

Step 1 Connect Solo to Your Router

page 03Archersh Solo Installaon Guide

Figure 2 Solo device’s power and Ethernet connectors

Ethernet connector

power connector

LED

You’ll need to acvate your Solo by registering it. To do so, open an Internet browser

and go to portal.myarchersh.com.

Click Start here (Figure 3).

Note: If you already have an Archersh account and need to register

addional Archersh devices, do not go through the Inial Registraon

process. Instead, go to portal.myarchersh.com, log in to the SmartPortal,

and then click on Devices > Add a Device.

On the Inial Logon and Registraon Wizard page, you’ll need to enter the serial

number of your Solo (Figure 4). The serial number can be found in your Geng Started

with Archersh Solo insert. You may want to save this insert so you can have the serial

number for your records. If you no longer have the insert, the Serial number can also be

found on the tag aached to the Solo device’s power cable.

Step 2 Register Solo

page 04Archersh Solo Installaon Guide

Figure 3 Begin your registraon at portal.myarchersh.com

Figure 4 Archersh device serial number in Device Serial Number eld

On the Inial Logon and Registraon Wizard page, Register Device secon,

enter a name for your device (Figure 5). The name of the physical locaon for

an Archersh device is recommended (e.g. “Front Door”). Because Archersh is

exible and easy to use, you can change the name at any me.

Click the Test Device buon.

• If the test is successful, you will receive a Congratulaons message (Figure

6). This means that your Archersh Solo has been successfully connected

to the Archersh SmartPortal.

• If the test fails, you’ll be walked through a series of quesons to

troubleshoot the problem. If you need addional help, contact

support@myarchersh.com or call 877.384.3347 (877.3.THEFISH).

Once you have completed a successful Archersh device test, connue with

the Inial Logon and Registraon Wizard page by clicking the Set up User

Informaon buon (Figure 7).

You will be prompted to accept the terms of service. You must agree to the

terms to connue with the installaon.

Step 2 Register Solo (continued)

page 05Archersh Solo Installaon Guide

Figure 5 Customizaon of Device Name

Figure 7 Installaon Wizard buon that will direct you to the next step in the inial

Archersh device registraon process

Figure 6 Congratulaons message, displayed upon successful Archersh device test

The second part of registraon is to register the primary user. The primary

user is usually the owner and main contact of this account, and will dene

system preferences such as adding users to the Archersh system.

On the Inial Logon and Registraon Wizard page, User Informaon

secon, enter the requested informaon in each eld (Figure 8).

Some elds to pay parcular aenon to include:

• Email Address: Enter a valid email address as the primary email

address that you want associated with your Archersh account. You

will use this same email address to log into your account from

portal.myarchersh.com. Note that this does not necessarily have

to be the email address you use to receive event nocaons.

• Password: Enter an alphanumeric password between 6 and

12 characters long. Aer inial registraon, you can update your

password at any me via your User Prole page.

• Time Zone: Select the me zone you prefer as the default me zone

for all Archersh devices registered to this account. All event congu-

raon opons and event nocaons will be displayed according to

the me zone you select.

Aer you have completed the required informaon elds, click the Dene

Nocaon Methods buon (Figure 9) to proceed to the next step in the

registraon process.

Step 2-1 Register Primary User

page 06Archersh Solo Installaon Guide

Figure 9 Installaon Wizard buon that will direct you to the next step

Figure 8 Inial Logon and Registraon Wizard page, User Informaon secon

On the Inial Logon and Registraon Wizard page, Dene Nocaon Methods

secon (Figure 10), you can tell Archersh how to send video nocaons and

other messages to you and people that you designate.

• Email 1 and Email 2: The email addresses entered in the last step will

automacally show up in the Email 1 eld. If you also want nocaons sent

to your mobile phone, enter in your phone’s email address in the Email 2 eld

(e.g., a Verizon email address might be 7035551212@vtext.com). Be sure to

use the correct email address for the type of message you want to receive,

SMS for text-only messages and MMS for messages with an aached video or

image, since they may dier. Figure 11 shows SMS and MMS email addresses

for major U.S. wireless providers. Please refer to your provider’s support

documentaon or web site for more informaon.

• Select one of the following Nocaon Formats:

- “Text” means you‘ll receive an all-text nocaon.

- “Text with hyperlink to video” means you’ll receive a nocaon with a link to

the Archersh SmartPortal to view a 10 second clip of the event. This opon

is only for email and not valid for mobile phones.

- “Text with aached sll image” means you’ll receive a nocaon that

includes an aached snapshot of the event.

- “Text with aached video clip” means you’ll receive a nocaon with a video

clip of the event. Choose the le format appropriate for your mobile phone:

MPEG-4 (standard), WMV (Windows phones), 3GPP (other phones), or MPEG-

4 for 3GS (iPhone). If you’re unsure of your format, try each one starng with

MPEG-4 (standard).

Once you have dened an email address and associated it with a Nocaon

Format, click the Test buon to conrm you can receive alerts as expected. If the

test fails, try another Nocaon Format.

Click the Set up Billing buon to proceed to the next step in the registraon

process.

Step 2-2 Deﬁne Notiﬁcation Method for Primary User

Figure 10 Inial Logon and Registraon Wizard page, Dene Nocaons secon

page 07Archersh Solo Installaon Guide

Figure 11 E-mail address format for major U.S. wireless providers

Provider SMS MMS

AT&T mobile number@txt.a.net mobile number@mms.a.net

Sprint mobile number@messaging.sprintpcs.com mobile number@pm.sprint.com

T-Mobile mobile number@tmomail.net mobile number@tmomail.net

Verizon mobile number@vtext.com mobile number@vzwpix.com

Virgin Mobile mobile number@vmobl.com mobile number@vmobl.com

On the Inial Logon and Registraon Wizard page, Billing secon (Figure 12), you can

choose your Archersh SmartPortal Service Level and method of payment.

Two service levels are available:

• Premium service level provides full Archersh SmartPortal funconality,

including intelligent video ltering and mobile nocaons.

• Basic service level provides remote system operaon and is best for those who

only want to view live and DVR video. The Basic service level is available free of

charge.

Upon the registraon of your rst Archersh device, you will receive an

automac free Premium service level upgrade for three months. Aer the trial

period, you may choose to connue with either service level opon. You are

charged monthly, so you can always update your service level. More informaon

is available at www.myarchersh.com/subscripon.

During inial registraon you are required to enter a valid credit card, even if

you plan to switch to the free Basic Subscripon at the end of the Premium

Subscripon trial.

Fill in your billing informaon and click the Authorize Subscripon buon (Figure

13). You’ll see a screen that summarizes your monthly charges. Click Conrm

Billing.

Click the Complete Registraon buon (Figure 14).

Archersh will check to see if there are any updates for your Solo device. If

updates are available, click the Update buon.

Once the device is updated, you’ll see a conrmaon message.

Note: The device update may take several minutes to complete, but should

take no longer than ten minutes. If you have waited for 15 minutes or longer

and the device update has sll not completed, make a note of what the light on

the boom of Solo is doing (see page 22) and contact Customer Support.

Step 2-3 Set Billing Preferences

page 08Archersh Solo Installaon Guide

Figure 12 Inial Logon and Registraon Wizard page, Billing Preferences secon

Figure 14 Authorize Subscripon secon

Figure 13 Installaon Wizard buon that will direct you to the next step

Step 3 Add Solo to Your Wireless Router

page 09Archersh Solo Installaon Guide

Figure 15 Archersh Devices detected by the Wi-Fi Setup Tool

Figure 16 Creang a password for your Solo

On a PC, go to www.myarchersh.com/solosetup to download the Archersh

Wi-Fi Setup Tool. Make sure you’re saving the le in the same local network you

plan to install Solo on. Double click the le to run it.

Note: If your Windows rewall or other security applicaon asks if you want

to run “SoloCongWizard” you’ll need to agree.

Once the tool has launched, click the Start buon.

The tool takes a few moments to detect all Solo devices that are connected to

your router.

Select the Solo device you wish to congure for Wi-Fi (Figure 15). If you have

mulple Solo devices, you can see which device is which by matching the four

digits displayed at the end of the Solo device name with the last four digits in the

device serial number (included in the Geng Started insert).

Note: The list of devices will include all Solo and Quaro devices currently

connected to your network via a physical, Ethernet connecon. It will not

include any Solo devices connected to your network via a Wi-Fi connecon.

Click the Connue buon.

Now you’ll need to provide and conrm a password for the Solo device (Figure

16). You’ll need this password if you ever need to go back and edit the device’s

Wi-Fi conguraon at a later me.

Click OK.

Tabla de contenidos

Manuales populares de Cámara de seguridad de otras marcas

Okina USA

Okina USA SIR36-870VF650LP Manual de usuario

Divio

Divio NDR155PA Manual de usuario

Canon

Canon VB-C500D Manual de usuario

Easy Access

Easy Access EasyGuard Manual de usuario

Vivotek

Vivotek FD9389-EHV-v2 Manual de usuario

TUYA

TUYA COSMO W2 Manual de usuario

Eusso

Eusso UNC7500-IR Guía de configuración

urmet domus

urmet domus 1096/204 Manual de usuario

VC VC20 series Manual de usuario

Axis

Axis Q1614 Manual de usuario

ieGeek

ieGeek DD201 Manual de usuario

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manual de usuario

Vicon

Vicon V662-D-1 Instrucciones de funcionamiento

Grundig

Grundig GCH-K0274P Manual de usuario

Lorex

Lorex VANTAGE LBC7032 Manual de usuario

4xem

4xem WPT Manual de usuario

Samsung

Samsung SCV-3082 Manual de usuario

Vitek

Vitek VTC-C544 Manual de usuario
