Arbor Technology EmCORE-i2305 Manual de usuario
- 1 -
♦ Technical Support
If you have any technical difculties, please consult the user’s manual rst at:
http://www.arbor-technology.com
Contact our customer service at the following addresses if your problem persists.
E-mail: info@arbor.com.tw
♦ Declaration of Conformity
FCC Class A
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions : (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
EmCORE-i2305
I/O
SATA/ mSATA/ USB/
COM/ DIO/ I2C
Video
Dual Channel 24-bit
LVDS, Analog RGB,
Vertical HDMI
LAN
2 x Realtek®RTL8111
PCIe GbE controllers
Audio
Realtek ALC662 HD Audio
CODEC, MIC-in/ Line-out/
Line-in
Form Factor
3.5"Compact Board
CPU
Intel®Atom™ Processor
E3800 family & Celeron®
Processor N-Series
Quick Installation Guide
Version 1.2
3.5" Compact Board
Copyright® All Rights Reserved. 4041230500120P
- 2 -
Packing List
Before starting with the installation, make sure the following items are shipped:
1 x EmCORE-i2305 3.5" Compact Board with heatsink
1 x Driver CD
1 x Quick Installation Guide
If any of the aforelisted items is damaged or missing, contact your vendor immediately.
Ordering Information
EmCORE-i2305-E3825 Intel® Atom™ Processor E3825 3.5” Compact Board
EmCORE-i2305-WT-E3825 Wide range temperature Intel® Atom™ Processor E3825 3.5”
Compact Board
EmCORE-i2305-E3845 Intel® Atom™ Processor E3845 3.5” Compact Board
EmCORE-i2305-WT-E3845 Wide range temperature Intel® Atom™ Processor E3845 3.5”
Compact Board
EmCORE-i2305-N2807
(BTO) Intel® Celeron® Processor N2807 3.5" Compact Board
EmCORE-i2305-N2930
(BTO) Intel® Celeron® Processor N2930 3.5” Compact Board
CBK-07-2305-00
Cable kit
1 x AUDIO cable
2 x COM port latching cables
1 x Keyboard & mouse latching y-cable
1 x SATA cable
1 x SATA power cable
1 x USB cable
- 3 -
Find Device Drivers on CD
Windows 7
Device Driver Path
Audio \Audio\32bit_Win7_Win8_Win81_R275
\Audio\64bit_Win7_Win8_Win81_R275
Chipset \Chipset\SetupChipset_10.0.13_PC
Ethernet \Ethernet\Realtek\Win7\Install_Win7_7085_05222014
GPIO \GPIO\windows 7 32_64\Intel Atom E3800 Win7 IO Drivers_Gold_v1.0 package 501232_
20140211
Graphic \Graphics\WIN7_32\Intel_EMGD.WIN7_PC_Version_36_15_0_1073
\Graphics\WIN7_64\Intel_EMGD.WIN7_PC_Version_37_15_0_1073
TXE \TXE\Installers (Only for 64-bit)
USB3.0 \USB3.0\Intel(R) USB 3.0 eXtensible Host Controller_Win7_32bit_64bit_R3.0.0.33
Serial IO \Serial IO\Intel Processor IO Drivers_Win7_32bit_64bit_Gold_v2.0
Windows 8.1
Device Driver Path
Audio \Audio\32bit_Win7_Win8_Win81_R275
\Audio\64bit_Win7_Win8_Win81_R275
Chipset \Chipset\SetupChipset_10.0.13_PC
Ethernet \Ethernet\Realtek\Win8_8.1\Install_Win8_8.1_8031_05222014
GPIO \GPIO\Kit 100882 20140211 windows 8.1 64\GPIO(Only for 64-bit)
Graphic \Graphics\WIN8_32\15.33.22.3621
\Graphics\WIN8_64\15.33.22.64.3621
TXE \TXE\Installers
Serial IO \Serial IO\SerialIO_Installer_Win8.1_64bit_WW23
- 4 -
Board Dimensions (SKU-E3825)
8.84
142.77
8.84
142.77
146
Ø3.2X4PCS
3.38
98.58
101.96
3.38 98.58
1.6
(32)
Unit: mm
- 5 -
Board Dimensions (SKU-E3845)
8.84
142.77
8.84
142.77
146
Ø3.2X4PCS
3.38
98.58
101.96
3.38 98.58
1.6
(25.5)
Unit: mm
- 6 -
Specications
Form Factor 3.5" Compact Board
CPU
Soldered onboard Intel® Atom™ Processor E3825 dual-core 1.33GHz,
E3845 quad-core 1.91GHz, Celeron® N2807 dual-core 1.58GHz or
N2930 quad-core 1.83GHz
System Memory 1 x DDR3L SO-DIMM socket, supporting SDRAM up to 8GB
Graphics Chipset Integrated Intel® HD Graphics
Graphics Interface
HDMI Vertical HDMI connector
LCD Dual-channel 24-bit LVDS
Analog RGB that supports resolution up to 2048 x 1536
Ethernet 2 x Realtek® RTL8111 PCIe GbE controllers
BIOS Insyde BIOS
Audio Realtek ALC662 HD Audio CODEC, MIC-in/ Line-out/Line-in
Storage
1 x Serial ATA port with 300MB/s HDD transfer rate
1 x mSATA socket
Soldered onboard 16GB eMMC(optional) (E3800 Family Only)
Serial Port 2 x COM ports (1 x RS-232 port, 1 x RS-232/485 port selectable)
Universal Serial Bus
4 x USB 2.0 ports
1 x USB 3.0 port
Digital I/O 8-bit programmable Digital Input/Ouput
Expansion Bus
1 x Mini-card socket
1 x Micro-SDXC socket (E3800 family only, supports SDXC card
SD 3.0 only)
2 x I2C ports(optional) (E3800 Family Only)
Power Requirement +12V DC
Power Consumption 0.56A@+12V (typical) (E3825)
0.65A@+12V (typical) (E3845)
Operating Temp. -20°C ~ 70°C (-4°F ~ 158°F)
-40°C ~ 85ºC (-40°F ~ 185ºF, WT series)
Operating Humidity 10% ~ 95% @ 70°C (non-condensing)
10% ~ 95% @ 85ºC (non-condensing, WT series)
Watchdog Timer 1~255 levels reset
Dimension (L x W) 146 x 102 mm (5.7” x 4.0”)
- 7 -
Jumpers & Connectors Quick Reference
Jumpers
Jumper Description
JPIC1 Sets the AT/ATX mode
JINV1 Sets the LCD inverter voltage
JVLCD1 Sets the power voltage for LVDS1 LCD.
JBAT1 Clears/keeps CMOS
JRS1 Sets the data transmitting signals for COM2 between RS-232, and RS-485.
Connectors
Connector Description
INV1 LCD inverter connector
LVDS1 LVDS LCD panel connector
KBMS1 Keyboard & Mouse Connector
COM1&2 Serial port Connectors
FAN1 Fan Connector
CN1 RS-485 Connector
DIO1 Digital I/O Connector
I2C1 I2C connector
AUDIO1 Audio connector
SATA1 Serial ATA connector
PWROUT1 SATA power connector
LAN1,2 Gigabit Ethernet Connectors
RES1 Reset Button
HDMI1 HDMI Connector
USB2 USB 3.0 Connector
USB3 Double-stacked USB Connectors
USB1 USB 2.0 Connector
VGA1 Analog RGB Connector
12VIN1 ATX +12V Connectors
JFRT1 Provides connectors to front-panel status LED
SYSLED1 Power ON & HDD LED Indicator
MC1 Mini-card socket (on board bottom)
MSATA1 mSATA socket
SD1 Micro SDXC card socket
- 8 -
Jumper & Connector Locations
2
1
72 74
71 73
204
203
4
1
4
1
1
2
5
6
1
2
3
4
5
6
7
1
1 2
9
10
1
2
9
10
1
2
9
10
1
2
9
10
10
1
2
9
1
2
9
10
34
2
1
1
1
1
230
29 1
1
2
9
10
1
1
1
1
1
4
10
NO COMPONENT
NO COMPONENT
NO COMPONENT
NO COMPONENT
KBMS1
COM1&2
JBAT1
JPIC1
INV1
1
2
3
4
FAN1
5
CN1
I2C1
8
9 AUDIO1
10
SATA1
11
PWROUT1
12
DIO17
JVLCD1
JINV1
LAN1
13
LAN2
14
RES1
15
HDMI1
16
USB2
17
USB3
19
12VIN1
22
JFRT1
VGA1
20
SYSLED1
18
USB1
21
LVDS1
6
❶
❷
❸
❹
JRS1
❺
- 9 -
Board Bottom
1234567 8
1
2
17
15
18
16
51
52
1
2
17
15
18
16
51
52
23
MC1
24
mSATA1
25
SD1
- 10 -
Jumpers
➊ JPIC1: Sets the AT/ATX mode
Jumper type: 2.00mm pitch 2x3-pin header
Pin Description
2-4 AT
6
5
2
1
4-6 ATX (default)
6
5
2
1
➋ JINV1: Sets the LCD inverter voltage
Jumper type: 2.54mm pitch 1x3-pin header
Pin Description
1-2 +12V
23 1
2-3 +5V (default)
23 1
➌ JVLCD1: Sets the power voltage for LVDS1
LCD.
Jumper type: 2.54mm pitch 1x3-pin header
Pin Description
1-2 +5V
23 1
2-3 +3.3V (default)
23 1
❹ JBAT1: Clears/keeps CMOS
Jumper type: 2.00 mm pitch 1x3-pin header
Pin Description
1-2 Keeps CMOS (default)
23 1
2-3 Clears CMOS
23 1
❺JRS1: COM2 RS-232/485 selection
Jumper type: 2.00 mm pitch 1x3-pin header
Pin Description
1-2 RS-232 (default)
23 1
2-3 RS-485
23 1
Note: To enable RS-485 Port (CN1) ,beside
jumper setting, please go to BIOS Setting Menu
to Enable RS-485 mode of COM2. Option is
under Advanced/ SIO FINTEK71869E/ RS-
232/485 Setting/ RS-485. After enabled RS-485
Mode, CN1 will be activated as RS-485 port.
Connectors
➀ INV1: LCD inverter connector
Connector type: 2.00mm pitch 1x5-pin box wafer
connector
Pin Description
1
5
1Vin
2 GND
3 on/off
4Brightness control
5 GND
② LVDS1: LVDS LCD panel connector
Connector type: ACES 1.25mm 87209-3040-06
connector that supports 24-bit dual
channels.
Pin Description Pin Description
1
2930
2
2VDD 1 VDD
4TX2_CLK+ 3 TX1_CLK+
6 TX2_CLK- 5 TX1_CLK-
8 GND 7 GND
10 TX2_D0+ 9 TX1_D0+
12 TX2_D0- 11 TX1_D0-
14 GND 13 GND
16 TX2_D1+ 15 TX1_D1+
18 TX2_D1- 17 TX1_D1-
20 GND 19 GND
22 TX2_D2+ 21 TX1_D2+
24 TX2_D2- 23 TX1_D2-
26 GND 25 GND
28 TX2_D3+ 27 TX1_D3+
30 TX2_D3- 29 TX1_D3-
③ KBMS1: Keyboard & Mouse connector
Connector type: 2.0mm pitch 1x6-pin header
Pin Description
1
6
1KB_DATA
2 GND
3 MS_DATA
4KB_CLK
5 PS2_VCC
6 MS_CLK
