Aquilar Aquitron AT-MGS-408 Instrucciones de instalación

INSTALLATION

& OPERATION

INSTRUCTIONS

AquiTron

AT-MGS-408

Gas Detection Controller

AT-MGS-408 User Manual

Table of Contents

Introduction .................................................. 1

1.1. About this Manual ..................................................................................................... 1

1.2. Conventions................................................................................................................ 1

1.2.1 Short Form Instructions...................................................................................................................... 1

1.2.2 Iconography......................................................................................................................................... 2

1.3. General Safety Statements....................................................................................... 2

Product Description...................................... 4

2.1. Product Overview ...................................................................................................... 4

2.2. Intended Use .............................................................................................................. 5

2.3. Design Features ......................................................................................................... 6

2.4. Components ............................................................................................................... 7

2.5. Communication Features ......................................................................................... 8

Installation .................................................... 9

3.1. Warnings & Cautions ................................................................................................. 9

3.2. Preliminary Inspection.............................................................................................. 9

3.3. Suitable / Appropriate Locations ............................................................................. 10

3.4. Mounting the Gas Detection Controller.................................................................. 10

3.5. Electrical Wiring ......................................................................................................... 11

3.6. Communications Connections ................................................................................. 12

3.6.1 AT-MGS-408 Gas Detection Controller Network .............................................................................. 12

3.6.2 Integration with Building Management System .............................................................................. 13

3.7. Connecting External Alarms ..................................................................................... 14

3.7.1 Overview............................................................................................................................................... 14

3.7.2 Connection Procedure........................................................................................................................ 14

Operation...................................................... 15

4.1. Overview ..................................................................................................................... 15

4.1.1 Main Function...................................................................................................................................... 15

4.1.2 Power Up.............................................................................................................................................. 15

4.1.3 Channel Number Keys ........................................................................................................................ 15

4.1.4 Menu Access and Navigation............................................................................................................. 15

4.2. Controller Setup......................................................................................................... 16

4.2.1 Setup Parameters ............................................................................................................................... 17

4.2.2 Relay Setup .......................................................................................................................................... 17

4.2.3 Audible/Visual (AV) Alarm Beacon..................................................................................................... 18

4.2.4 Fault Latching...................................................................................................................................... 18

AT-MGS-408 User Manual

4.2.5 LCD Contrast........................................................................................................................................ 19

4.2.6 LED Brightness & Auto-dimming ....................................................................................................... 19

4.2.7 Date/Time............................................................................................................................................. 20

4.2.8 Password Protection........................................................................................................................... 20

4.2.9 Factory Reset........................................................................................................................................ 21

4.2.10 Update Firmware ................................................................................................................................ 21

4.3. Channel Summary and Setup................................................................................... 22

4.3.1 Channel Setup Overview .................................................................................................................... 23

4.3.2 CH(X) MON (Monitor).......................................................................................................................... 23

4.3.3 CH(X) TYP (Instrument Type) .............................................................................................................. 24

4.3.4 CH(X) ADR (Node Address).................................................................................................................. 24

4.3.5 CH(X) LOC (Location)........................................................................................................................... 25

4.4. Data Logging............................................................................................................... 25

4.4.1 Data Logging Overview....................................................................................................................... 25

4.4.2 SD Card Requirements ....................................................................................................................... 25

4.4.3 Data Logging Menu............................................................................................................................. 25

MODBUS........................................................ 27

5.1. MODBUS Overview .................................................................................................... 27

5.1.1 MASTER BAUD RATE ............................................................................................................................ 27

5.1.2 SLAVE NODE ADDRESS ........................................................................................................................ 27

5.1.3 SLAVE BAUD RATE................................................................................................................................ 28

5.1.4 SLAVE PARITY ...................................................................................................................................... 28

5.1.5 SLAVE STOP BIT.................................................................................................................................... 28

5.1.6 SLAVE TERMINATION .......................................................................................................................... 28

5.2. MODBUS Registers..................................................................................................... 29

Diagnostics & Troubleshooting .................. 36

6.1. Diagnostic Menu ........................................................................................................ 36

6.1.1 DISPLAY CURRENT FAULT.................................................................................................................... 36

6.1.2 DISPLAY LAST FAULT............................................................................................................................ 37

6.1.3 CLEAR FAULT ........................................................................................................................................ 37

6.1.4 CLEAR LAST FAULT ............................................................................................................................... 37

6.1.5 CLEAR LAST SD FAULT ......................................................................................................................... 37

6.1.6 POWER.................................................................................................................................................. 37

6.1.7 MODBUS SLAVE ................................................................................................................................... 38

6.1.8 MODBUS MASTER................................................................................................................................ 38

6.2. FAULT CODES.............................................................................................................. 39

6.3. SYSTEM TESTS............................................................................................................. 40

6.3.1 RELAY TEST ........................................................................................................................................... 40

6.3.2 LED TEST............................................................................................................................................... 40

6.3.3 KEYPAD TEST ........................................................................................................................................ 40

6.3.4 STROBE TEST ........................................................................................................................................ 40

6.3.5 FAN TEST............................................................................................................................................... 40

AT-MGS-408 User Manual

Additional Information ............................... 41

7.1. Disposing of Instrument ........................................................................................... 41

7.2. TechnicalSpecications............................................................................................ 41

Parts and Accessories.................................. 42

8.1. Part Numbers............................................................................................................. 42

AT-MGS-408 User Manual

1. Introduction

1.1. About this Manual

Thank you for investing in a Aquitron AT-MGS-408 Gas Detector Controller. To ensure

operator safety and the proper use of the controller, please read the contents of this

manual for important information on the operation and maintenance of the instrument.

IMPORTANT: Before using this product, carefully read and strictly follow the

instructions in the manual. Ensure that all product documentation is retained

and available to anyone operating the instrument.

1.2. Conventions

1.2.1 Short Form Instructions

This document uses a short form for describing steps (e.g. executing a command).

Example:

Clearing the current fault.

Short Form Instructions:

Main Menu Diagnostics Clear Fault press OK to clear the current fault.

Steps Required:

1. Press “OK” to access the Main Menu.

2. Select “Diagnostics.”

3. Select “Clear Fault.”

4. When prompted, press “OK” to clear the current fault.

AT-MGS-408 User Manual

1.2.2 Iconography

Alert Icon Description

DANGER Imminently hazardous situation which, if not avoided, will

result in death or serious injury.

WARNING Potentially hazardous situation which, if not avoided,

could result in death or serious injury.

WARNING Potential electrical shock hazard which, if not avoided,

could result in death or serious injury.

CAUTION

Potentially hazardous situation which, if not avoided,

could result in physical injury or damage to the product

or environment. It may also be used to alert against

unsafe practices.

IMPORTANT Additional information on how to use the product.

1.3. General Safety Statements

IMPORTANT: Before using this product, carefully read and strictly follow the

instructions in the manual. Ensure that all product documentation is retained

and available to anyone operating the instrument.

DANGER: This instrument is neither certied nor approved for operation in

oxygen-enriched atmospheres. Failure to comply may result in personal injury

or death.

WARNING: Under no circumstances should this product be operated without

connection to a protective ground. Failure to comply may result in a potential

shock hazard and is a violation of electrical safety standards applicable to this

category of equipment.

WARNING: Always remove AC power before working inside the AT-MGS-408

enclosure and exercise extreme care when accessing the products interior.

Only qualied electrical maintenance personnel should perform connections

and adjustments.

WARNING: DO NOT use soap and water or other detergents to clean the

outside of this product; use a DRY CLOTH only. Failure to comply may result in

a potential shock hazard.

AT-MGS-408 User Manual

CAUTION: The protection provided by this product may become impaired if

it is used in a manner not specied by the manufacturer. Modications to this

instrument, not expressly approved, will void the warranty.

CAUTION: In case of malfunction, DO NOT continue to use this equipment

if there are any symptoms of malfunction or failure. In the case of such

occurrence, de-energize the power supply and contact Aquilar on 01403

216100.

CAUTION: Use ONLY the provided cable glands for electrical and

communication wiring. Drilling into the box will void the warranty.

AT-MGS-408 User Manual

2. Product Description

2.1. Product Overview

The AT-MGS-408 Gas Detection Controller displays comprehensive and centralized

information about the status of all connected gas detectors. A maximum of eight

AquiTron gas detectors can be connected to the AT-MGS-408 via Modbus RTU.

Compatible gas detectors are:

• AT-MGS-410 • AT-MGS-550

• AT-MGS-450

• AT-MGS-460

The AT-MGS-408 can be used to provide power to each connected, compatible gas

detector, negating the need for separate power supply at the location of the gas

detector.

The AT-MGS-408 displays status via an LCD screen and a bank of LEDs that

represent the channel / sensor connected to it. Each channel / sensor has a row of

dedicated LEDs to indicate the status of the sensor:

• Power • Low alarm

• High alarm • Fault

The LCD screen will display the current gas reading and gas type for the selected

channel, or will indicate fault and/or alarm status. The LCD screen is also used for

conguration of the AT-MGS-408 via the integrated keypad.

In addition to the LED alarm status, the AT-MGS-408 includes an integrated audible

alarm. An optional beacon can be installed, mounted in the top of the enclosure, to

enhance local alarm indication.

The AT-MGS-408 provides relays (indicating any high alarm, low alarm or fault status) and

can act as a Modbus slave device. This allows connection to a third-party device such

as a Building Management System (BMS) or Programmable Logic Controller (PLC).

Data logging is available on the AT-MGS-408 via the integrated SD card, which can

be removed to allow download of the logged data to a computer. The data will

AT-MGS-408 User Manual

include a date stamp of all high and low alarms as well as all faults.

Figure 2-1 - AT-MGS-408 Gas Detection Controller with Optional External Beacon

WARNING: This instrument is neither certied nor approved for operation in

oxygen-enriched atmospheres. Failure to comply may result in EXPLOSION.

WARNING: For your safety, DO NOT use this instrument in locations classied

as hazardous because it has not been designed to be intrinsically safe for use

in such areas.

2.2. Intended Use

The AT-MGS-408 provides audio-visual alerts and information pertaining to the

status of a centralized gas detector network. This information allows concise, at-a-

glance notication of any alarm or fault status regarding a connected gas detector

located outside the monitored space, as required by many regulatory codes and

standards.

AT-MGS-408 User Manual

2.3. Design Features

Power Options 100 - 240 VAC, 50/60 Hz, 80 W (max.)

Provides power for 1 - 8 compatible AquiTron gas detectors

Output/

Communications

RS485 Modbus RTU Master for Gas Detectors

Diagnostic / Status LEDs

yController (power, fault)

yGas Detectors (power, fault, low alarm, high alarm)

Outputs

y3 × Relays (fault, low alarm, high alarm), Fail-safe Option

yRS485 Modbus RTU Slave

Optional

yExternal Beacon (red, blue, green, yellow)

Data Logging Via supplied 32GB SD card; will hold up to 10 years of

logged data.

User Interface LCD Display screen

Integrated keypad

Tabla de contenidos

Manuales populares de Controladores de otras marcas

Digiplex

Digiplex DGP-848 Instrucciones de funcionamiento

YASKAWA

YASKAWA SGM series Manual de usuario

Sinope

Sinope Calypso RM3500ZB Manual de usuario

Isimet

Isimet DLA Series Style 2 Manual de instalación

LSIS

LSIS sv-ip5a Manual de usuario

Rockwell Automation

Rockwell Automation 1769-L31 Manual de usuario

Airflow

Airflow Uno hab Manual de usuario

ABB

ABB ACS580-01 drives Manual de usuario

Panasonic

Panasonic GM1 Series Manual de usuario

Emerson

Emerson SW93 Manual de usuario

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manual de usuario

Panasonic

Panasonic FP? Positioning Unit RTEX Manual de usuario

Samson

Samson Type 5824 Manual de servicio

Alpha IP

Alpha IP MIOB 21001 Manual de usuario

Siemens

Siemens OpenAir GMA 1 Series Manual de usuario

Surecom

Surecom SR-629 Manual de usuario

Fishman

Fishman TriplePlay Manual de usuario

Regulus

Regulus SRS1 T Manual de usuario

aquilar aquitron AT-MGS-408 Instrucciones de instalación

Manuales populares de Controladores de otras marcas
