Aqara Motion Sensor Manual de usuario
Motion Sensor
English
Motion Sensor Quick Start Guide
Aqara Motion Sensor detects human movement with
passive infrared. It works with other smart accessories
to set various scenes, such as, turning on or off lights
automatically when it detects activity or inactivity. It
consumes low energy. No tools are required to install it,
and you can simply place or stick it almost anywhere.
Product Introduction
Indicator Light/
Fresnel Lens
Stand
Reset Button
Long Press for 3s: Reset
Single Press: Effective
Range Test
A hub is required.*
This product is for indoor use only.*
Aqara Hub is required to enable Aqara Motion Sensor to work with
HomeKit technology. See www.aqara.com for more details.
*
English
Quick Setup
Effective Range Test: Single press the reset button on
the accessory at your desired position. If the Hub makes
voice prompts, it indicates that the accessory can
communicate effectively with the Hub.
* Avoid metal surface to maximize signal strength.
Installation
Option 1: Place the Motion Sensor where you need it.
If the connection fails, please move the accessory closer to the
Hub and try again.
*
Please add the Hub to the app according to the Hub
Quick Start Guide.
1.
Please open the app, tap “Home” and then tap “+” in
the top right corner to enter “Add Device(Accessory)”
page. Select “Motion Sensor” , and add it according
to instructions.
2.
English
Stick it to the desired positionRemove the protective film
2
Keep the surface clean and dry.*
Remove the protective film (the round sticker is
in the box), and stick it to the desired position.
Option 2:
Stick the Motion Sensor to the stand, and stick
the stand to where you need it.
Option 3:
1
English
The recommended installation height is 1.2 m to 2.1 m. If the
installation height is below 1.2 m, the detection area will decrease; if
above 2.1 m, the detection area might have blind spots.
*
7m4.5m
2.1m
2m
Effective Detection Area — Side View
Effective Detection Area — Top View
170°
Note that the lens should be aligned with the detection area when
installing, and placed or pasted as close as possible to the edge of a
table or cabinet.
*
Online Customer Service: www.aqara.com/support
Email: [email protected]
Manufacturer: Lumi United Technology Co., Ltd.
Address: 8th Floor, JinQi Wisdom Valley, No.1 Tangling
Road, Liuxian Ave, Taoyuan Residential District, Nanshan
District, Shenzhen, China.
Model: RTCGQ11LM
Dimensions: 30 ×30 ×33 mm (1.18 ×1.18 ×1.30 in.)
Wireless Protocol: Zigbee
Battery: CR2450
Maximum Detection Distance: 7 m
Maximum Detection Angle: 170°
Operating Temperature: -10° – +45° C
Operating Humidity: 0 – 95% RH, no condensation
Specifications
English
