APG PG-7 Manual de usuario
Operator’s Manual
AUTOMATION
PRODUCTS
GROUP, INC.
Automation Products Group, Inc.
PG-7
Full Access
DOC. 9003312
Rev A2, 07/16
www. .com information@itm.com1.800.561.8187
PG7 Rev. A2, 07/16
2
Automation Products Group, Inc.
Table of Contents
Warranty ............................................................................................................ 3
Programming the PG7.................................................................................4-23
Full Access Menu............................................................................................ 5
Accessing the Mode Setting........................................................................... 6
ModeDenitions............................................................................................ 6
Accessing/Exiting the Setup Menu................................................................ 7
Maximum/Minimum Reset ........................................................................... 8
Units of Measure............................................................................................ 9
Using Custom Units............................................................................... 10
Peak-Hold Feature ....................................................................................... 11
Advanced Settings...................................................................................12-17
Auto-O .................................................................................................. 12
Decimal Place......................................................................................... 13
Sample Rate ........................................................................................... 14
Bar Graph............................................................................................... 15
Range Adjustment ................................................................................. 16
Quick Calibration................................................................................... 17
Tare Feature ................................................................................................. 18
Default .......................................................................................................... 19
Output......................................................................................................20-24
Setting/Calibrating Analog Signal Span/End-Points ......................20-21
Trip Points ..........................................................................................22-24
Wiring ..........................................................................................................25-26
Specications..............................................................................................27-28
Declaration of Conformity ........................................................................29-30
www. .com information@itm.com1.800.561.8187
PG7 Rev. A2, 07/16
4
Automation Products Group, Inc.
On/Off Button
Primary Function: Press and hold for 1 second to turn on or o the gauge.
Secondary Function: Press once to access the main setup menu.
Zero Button (Z)
Primary Function: Press to “zero” the gauge reading (the reading must be less
than 5% of full-scale in order to zero the gauge).
Secondary Function: Cycles through the options in the setup menus.
Select Button (S)
Primary Function: Cycles between the current, maximum, and minimum
pressure readings.
Secondary Function: Used to accept the displayed option while in the setup
menus.
Secondary Function: Resets the peak-hold reading when the peak-hold
feature is enabled.
Each of the three buttons on the PG7 performs multiple functions. The
primary function applies when in standard operating mode. The secondary
functions are used for programming operations and when special features,
such as Peak-Hold, are enabled.
Programming the PG7
Battery Meter Bar Graph
Zero (Z) Button
Select (S) Button
On/Off Button
www. .com information@itm.com1.800.561.8187
Rev. A2, 07/16 PG7
5
Automation Products Group, Inc.
MAXMIN
UNITS
P HOLD
ADVSET
TARE
DEFAULT
OUTPUT
YES
NO
ON
OFF
ON
OFF
YES
NO
DEC PL
SAMPLE
BAR 0
RANGE
BAR100
AUTO OFF, 2 MIN, 4 MIN, 8 MIN, 16 MIN, 32 MIN
HI RES, MEd Res, LO RES
SLOW, MEDIUM, FAST
SET RANGE (LBS ONLY)
SET BAR GRAPH 0%
SET BAR GRAPH 100%
FULL ACCESS MENU
AL SET
AH SET
SET ANALOG LOW SET PRESSURE
SET ANALOG HIGH SET PRESSURE
AL CAL
AH CAL
SET ANALOG LOW CALIBRATION
SET ANALOG HIGH CALIBRATION
* Menu options only available
for gauges with an analog
output or relays.
T1TYPE
T1PRES
TYPE0, TYPE1, TYPE2, TYPE3, TYPE4, TYPE5
SET TRIP PRESSURE 1 START PRESSURE
T1WIN
T2TYPE
SET TRIP PRESSURE 1 WINDOW SIZE
TYPE0, TYPE1, TYPE2, TYPE3, TYPE4, TYPE5
T2PRES
T2 WIN
SET TRIP PRESSURE 2 START PRESSURE
SET TRIP PRESSURE 2 WINDOW SIZE
EXIT
CALIBR FAST CALIBRATE, ZERO AND SPAN
EXIT
EXIT
PSI
BAR
KPA
CUSTOM
MBAR
INHG
INH20
MMHG
LBF
KN
LBS
KG
NEWTON
<= 120 psi
> 120 psi
CUSTOM ONLY
CUSTOM ONLY
SELECT
MULTIPLIER
PSI
BAR
KPA
CUSTOM
KGCM^2
MPA
FTH20
CMHG
www. .com information@itm.com1.800.561.8187
PG7 Rev. A2, 07/16
6
Automation Products Group, Inc.
Accessing the Mode Setting:
Step 1: Simultaneously press and hold the On/O button and the (S)
button for approximately 3 seconds. This will bring up the 3 digit mode
number.
Step 2: Enter the desired mode number (see mode denitions below) by
using (Z) to change the value of the ashing digit, and (S) to advance to
the next digit.
Mode Denitions:
Mode 000: Full Access
- Provides access to all menu settings. If no buttons are pushed for
1 minute, the gauge will revert back to Mode 003 (factory default).
Mode 002: Limited Access
- Menu is locked
- (Z) button zeros the reading
- (S) cycles between the Max and Min readings
- On/O functions only on battery powered gauges
Mode 003: Factory Default
- Full access except Full Scale Calibration is locked
Mode 005: Locked Access
- All buttons locked except the on/o button on battery powered
gauges.
www. .com information@itm.com1.800.561.8187
Rev. A2, 07/16 PG7
7
Automation Products Group, Inc.
Accessing the Setup Menu:
Step 1: Simultaneously press and hold the On/O button and the (S)
button for approximately 3 seconds. This will bring up the 3 digit mode
number.
Step 2: Using (Z) to change the value of the ashing digit, and (S) to
advance to the next digit, change the mode number to 000.
Step 3: Press On/O to enter the setup menu, and press (Z) to scroll
through menu choices.
Exiting the Setup Menu:
Step 1: While in the main setup menu, press (Z) until EXIT is displayed.
Step 2: Press (S) to access the Exit options.
Step 3: Press (Z) until YES is displayed.
Step 4: Press (S) to Exit the main setup menu and return to the standard
operating mode.
Zero (Z) Button Select (S) Button
On/Off Button
Accessing/Exiting the Setup Menu:
www. .com information@itm.com1.800.561.8187
PG7 Rev. A2, 07/16
8
Automation Products Group, Inc.
Maximum/Minimum Reset (MAXMIN):
Pressing the (S) button while in standard operating mode will cycle between
displaying the current pressure reading, the Maximum pressure reading
and the Minimum pressure reading. The maximum and minimum readings
will be stored until the gauge is powered down or the max/min readings are
reset.
Resetting the Max/Min readings:
Step 1: Press the On/O button once to enter the main setup menu.
Step 2: Press (Z) to cycle through the options until MAXMIN is displayed.
Step 3: Press (S) to access the Max/Min reset options.
Step 4: Press (Z) to toggle between YES and NO until YES is displayed.
Step 5: Press (S) to reset the Max/Min readings and return to the main
setup menu.
www. .com information@itm.com1.800.561.8187
Rev. A2, 07/16 PG7
9
Automation Products Group, Inc.
Units of Measure (UNITS):
Allows the user to select the unit of measure to be displayed as the pressure
reading.
Options:
For gauges over 120 psi:
PSI (pounds per square inch)
bAR (bar)
KPA (kilopascals)
*CUSTOM (see “Using Custom Units” on next page)
KGCM^2 (kilograms per cubic centimeter)
MPA (megapascals)
FTH20 (feet of water @ 60 F)
cmHG (centimeters of mercury)
For gauges less than 120 psi:
PSI (pounds per square inch)
bAR (bar)
KPA (kilopascals)
*CUSTOM (see “Using Custom Units” on next page)
mbAR (millibar)
INHG (inches of mercury)
INH20 (inches of water @ 60 F)
mmHG (millimeters of mercury)
Setting the Unit of Measure:
Step 1: Press the On/O button once to enter the main setup menu.
Step 2: Press (Z) to cycle through the options until UNITS is displayed.
Step 3: Press (S) to access the Units options.
Step 4: Press (Z) to cycle through setting options until the desired unit of
measure is displayed.
Step 5: Press (S) to apply the setting and return to the main setup menu.
www. .com information@itm.com1.800.561.8187
PG7 Rev. A2, 07/16
10
Automation Products Group, Inc.
Using Custom Units (CUSTOM):
The Custom Units setting allows the user to display a volumetric weight by
applying a conversion factor to the pressure reading.
NOTE: The conversion factor must be calculated using Pound per Square
Inch (psi) as the base unit of measure.
Setting the Custom Units feature:
Step 1: Calculate the conversion factor from psi to the desired unit of
measure.
Step 2: Press the On/O button once to enter the main setup menu.
Step 3: Press (Z) to cycle through the options until UNITS is displayed.
Step 4: Press (S) to access the Units setting options.
Step 5: Press (Z) to cycle through the Units options until CUSTOM is
displayed.
Step 6: Press (S) to access the Custom Units setting. A 5-digit conversion
factor will appear with the rst digit ashing.
Step 7: Press (Z) to change the value of the ashing digit (options: 0-9).
Step 8: Press (S) to accept the ashing digit and advance to the next digit.
Repeat steps 7 and 8 as necessary.
Step 9: After the last digit is accepted by pressing (S), use (Z) to scroll
through the custom units of measure: LBF, KN, LBS, KG, NEWTON.
Step 10:Press (S) to accept the custom unit and return to the main setup
menu.
www. .com information@itm.com1.800.561.8187
Rev. A2, 07/16 PG7
11
Automation Products Group, Inc.
Peak-Hold (P HOLd):
When the Peak-Hold is enabled, the gauge will display the “peak” or
maximum pressure reading since the gauge was powered on or the Max/Min
value was reset.
NOTE 1: When the Peak-Hold feature is enabled, a small box containing the
words PEAK HOLD will be displayed in the upper left corner of the display.
Options: O or On
Enabling the Peak-Hold feature:
Step 1: Press the On/O button to enter the main setup menu.
Step 2: Press (Z) to cycle through the options until P HOLd is displayed.
Step 3: Press (S) to access the Peak-Hold setting options.
Step 4: Press (Z) to toggle between OFF and ON.
Step 5: Press (S) to apply the displayed setting and return to main setup
menu.
NOTE 2: The peak value can be reset by pressing (S) with the Peak-Hold
function enabled.
