1.1 A Thank-you Note Before You Get Start

First of all, we would like to express our gratitude for purchasing AOpen products.

Once again, this motherboard is designed uniquely to meet all your personal

needs with our great industry-designing ability and our everlasting perseverance

to the quality of all our products.

This manual will introduce you how this motherboard is installed. Please keep it

well for your future reference. If you lost your printed manual, you may also go to

our website at http://www.aopen.com to download the updated file.

Now, we would like to invite you to personally experience this user-friendly

manual and all of the powerful functions this AOpen product offers.

The logos of Adobe and Acrobat are the registered trademarks of Adobe Systems

Incorporated.

The logos of AMD, Athlon, and Duron are the registered trademarks of Advanced Micro

Devices, Inc.

The logos of Intel, Intel Celeron, Pentium II, III, Pentium 4 and Pentium Mare the registered

trademarks of Intel Corporation.

The logos of nVidia are the registered trademarks of nVidia Corporation.

The logos of Microsoft, Windows are the registered trademarks of Microsoft Corporation in

America and other countries.

All the titles of the products and the trademarks mentioned in this manual are for the

purpose of illustrative conveniences and are possessed by their respective firms.

We regret not informing about any changes in usage standards and other related

information. AOpen reserves the right of altering or modifying the content of this manual. In

case of any mistakes or incorrect descriptions, which include those on the products, AOpen

makes no guarantee or commitments.

This document is based on the copyright laws in order to protect our company and reserve

all rights.

Under no circumstances are any types of duplicating and loading this brochure in any

databases and media permitted except the permission signed on formal document by

AOpen Company.

1.2 Features of This Manual

To help you grab the useful information of this motherboard and aware of certain

conditions that you might need to know, you will see the icons below frequently:

1.3 Safety Information

This contains knowledge you should know in process

of assembling, or some helpful tips.

This tip tells you some useful information that will

make your installation smoothly.

Please be careful when you see this mark. It

highlights mistakes that occur often during

assembling, or something you need to pay attention

to.

Please wear a wrist strap and attach it to a metal part of the system unit

before handling a component. Alternatively, you can also touch an object

that is of ground connection or with metal surface.

Always unplug the power before you make any jumper setting.

Before you install or remove any components on the motherboard, please

make sure to disconnect the power first in case of damaging motherboard

or other components.

Warning

Tip

Warning

Warning / Caution

Note

Chapter 2 Introduction to This Motherboard

2.1 How does your motherboard look like?

1. COM2 Connector 18. S/PDIF Connector

2. JP28 PS2 KB/Mouse Wakeup Jumper 19. PCI Express x1 Slots X 2

3. 4-pin 12V ATX Power Connector 20. Black Jack Connector

4. ATX Power Connector 21. IRDA Connector

5. SYSFAN1 Connecto

22. 32-bit PCI Expansion Slots X 3

6. PWRFAN Connector 23. Game Connector

7. Power Temperature Connector 24. USB 2.0 Connectors X 2

8. PCI Express x16 Graphics slot 25. IEEE 1394 Connector X 2

9. LGA775 CPU Socket supporting Intel FC-LGA4

9. CPU 26. DieHard BIOS Lite

10. CPUFAN Connector 27. Serial ATA Ports X 4

11. Intel 915G / ICH6 (i915Ga-PLF)

11. Intel 915P / ICH6 (i915Pa-PLF) 28. Case Open Connector

12. STBY LED 29. JP14 CMOS Data Clear Jumper

13. 184-pin DIMMs x 4 30. SYSFAN2 Connector

14. CD_IN Connector 31. FDD Connector

15. Realtek Gigabit LAN Chip 32. Front Panel Connector

16. Realtek AC’97 CODEC 33. ATA100 Connector

17. Front Audio Connector 34. BOOT LED

8 9

4 5

6 7

24 25

26 27

28 29

30 31

32 33

Chapter 2 Introduction to This Motherboard

2.2 Specification

Here is the main function of your motherboard.

Models i915Ga-PLF i915Pa-PLF

CPU Intel FC-LGA4 CPU

Socket T

800MHz

Intel FC-LGA4 CPU

Socket T

800MHz

Chipset Intel 915G/ICH6 Intel 915P/ICH6

Main

Memory

Dual Channel Mode DDR

DDR 333/400

DDR DIMM x 4

DIMM Type : 128/256/512MB & 1GB

Max Memory : 4GB

Dual Channel Mode DDR

DDR 333/400

DDR DIMM x 4

DIMM Type : 128/256/512MB & 1GB

Max Memory : 4GB

Graphics Integrated VGA Engine in chipset

PCI Express x 16 Graphics slot, support

ADD2 card

PCI Express x 16 Graphics slot

IDE

Integrated ATA100 and Serial ATA

Controller

Max Disk: 144,000,000GB [by 48 bits

LBA

Spec.]

Integrated ATA100 and Serial ATA

Controller

Max Disk: 144,000,000GB [by 48 bits

LBA

Spec.]

LAN Realtek Gigabit PCI LAN Chip Realtek Gigabit PCI LAN Chip

Sound AC’97 Codec on-Board

Support 7.1 Channel and above AC’97 Codec on-Board

Support 7.1 Channel and above

USB Integrated in chipset, USB 2.0 x 8 Integrated in chipset, USB 2.0 x 8

IEEE 1394 Agere 1394 Control Chip Agere 1394 Control Chip

Slots PCI Express x 1 slots x 2

PCI Express x 16 graphics slot x 1

PCI slots x 3

PCI Express x 1 slots x 2

PCI Express x 16 graphics slot x 1

PCI slots x 3

Back

Panel I/O

PS/2 Keyboard x 1, PS/2 Mouse x 1

USB Port x 4, LAN Port x 1, VGA Port x 1

COM Port x 1, Printer Port x 1

Speaker_Out x 1, Line_In x 1, MIC_In x 1

Side SUR x 1, Rear SUR x 1

Center/Subwoofer x 1

PS/2 Keyboard x 1, PS/2 Mouse x 1

USB Port x 4, LAN Port x 1

COM Port x 2, Printer Port x 1

Speaker_Out x 1, Line_In x 1, MIC_In x 1

Side SUR x 1, Rear SUR x 1

Center/Subwoofer x 1

On Board

Connector

Floppy Drive Connector x 1

IDE Channel: ATA100 x 1

Serial ATA Channel x 4

Front Panel x 1

Front Audio x 1

CPU FAN x 1,System FAN x 1,

Chassis FAN x 1 Power FAN x 1

Power Temperature Connector x 1

Case Open Connector x 1

CD_IN x 1, IrDA x 1, S/PDIF x 1

COM2 x 1

Game Connector x 1

IEEE 1394 x 2

USB2.0 Connectors x 2

Floppy Drive Connector x 1

IDE Channel: ATA100 x 1

Serial ATA Channel x 4

Front Panel x 1

Front Audio x 1

CPU FAN x 1,System FAN x 1,

Chassis FAN x 1 Power FAN x 1,

Power Temperature Connector x 1

Case Open Connector x 1

CD_IN x 1, IrDA x 1, S/PDIF x 1

Game Connector x 1

IEEE 1394 x 2

USB2.0 connectors x 2

BIOS Award PnP 4Mb Flash ROM BIOS Award PnP 4Mb Flash ROM BIOS

Board Size 305 mm x 210 mm 305 mm x 210 mm

2.3 Block Diagram

PCI Bus

150MB/s

IDE Drives x2

AC’97

CODEC

ATA 33/66/100

Serial ATA Ports

32-bit PCI Slots

500MB/s PCI Express x 1

Slots x2

Intel

915G / 915P

Chipset

LGA775

Socket

Intel

FC-LGA4

533/800 MHz

System Bus

Support ADD2 Card

(for i915Ga-PLF)

PCI Express x16

Graphics slot

VGA Onboard

(

i915Ga-PLF

)

CPU

DIMM Sockets x4 Dual Channel DDR

333/400 SDRAM

Up to 4GB

ICH6

4Mbits Flash

EEPROM

USB 2.0 x8

LAN connect

Com

onent

Realtek

Gigabit

LAN Chip

Agere

IEEE

1394

Controlle

Winbond

Super I/O

Floppy Disk

Drive

Serial Ports x2 IEEE 1394 x2

Parallel Port

Chapter 3 Hardware Installation

3.1 Quick Installation Procedure

1. Installing CPU

2. Installing CPU

Fan & System Fan

3. Installing

Memory Module

4. Installing HD,

CD-ROM and

SATA Disk, etc

6. Connecting ATX

Power Cable

5. Connecting Front

Panel Cable

7. Installing PCI

Express x16 Graphics

cards & PCI Express x 1

cards & PCI Cards

8. Installing Other

Devices (USB, Front

Audio, etc)

9. Connecting

Back Panel Ports

(Keyboard,

Mouse, etc)

10. Loading

Default BIOS,

Setting CPU

Fre

uenc

11. Installing

Operating System

(such as, Windows

XP)

12. Installing Drivers &

Utilities

3.2 Installation You Have to Know

Installing CPU

This socket supports FC-LGA4 CPU, which is the latest CPU package developed by

Intel. Other forms of CPU package are impossible to be fitted in.

1. Pull CPU socket lever and plate up.

2. Remove plastic cap from CPU socket plate.

3. Locate Pin 1 in the socket and look for a golden arrow on the CPU upper

interface. Match Pin 1 and golden arrow. Then insert the CPU into the

socket.

4. Press down the CPU socket plate and lever to finish CPU installation.

Plastic cap

Plas ptic ca

CPU socket plate

Note: It’s strongly recommended by

Intel to use thermal paste properly to avoid

over-heat generated from Prescott CPU.

Golden

arrow

CPU socket

lever

Socket Pin 1

Warning: If you do not match the CPU

socket Pin 1 and CPU golden arrow well,

you may damage the CPU. And please don’t

touch CPU socket pins when installing CPU.

Installing CPU Cooler

1. Gently put down the CPU fan on CPU socket with four sticks aiming correctly

to the four mounting holes.

Mounting

hole

Mounting

hole

2. Press down four fixing sticks into the holes one by one. Make sure the

sticks are firmly fixed into the holes.

Fixing

stick

Note

you purcha: The picture above may look different from the product

sed.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Placa madre de AOpen

AOpen

AOpen AX3SP-U Hoja de datos

AOpen

AOpen MX46-800N Hoja de datos

AOpen

AOpen P5TC Manual de usuario

AOpen

AOpen MX34 Guía de configuración

AOpen

AOpen AX3S Max Hoja de datos

AOpen

AOpen AX4T II Guía de configuración

AOpen

AOpen AX63PRO Manual de usuario

AOpen

AOpen MX 36 LE-U Guía de configuración

AOpen

AOpen AX45-8X Max Guía de configuración

AOpen

AOpen AX45-533 PLUS Guía de configuración

AOpen

AOpen AK75PRO Hoja de datos

AOpen

AOpen AX4G Hoja de datos

AOpen

AOpen DX34R-U Hoja de datos

AOpen

AOpen MK33 Guía de configuración

AOpen

AOpen MX4BR-533 Guía de configuración

AOpen

AOpen vK8T800a-LF Manual de usuario

AOpen

AOpen AK77-400 Guía de configuración

AOpen

AOpen MX4GVR Hoja de datos

AOpen

AOpen MX33 Hoja de datos

AOpen

AOpen AK77 Pro(A)-133 Guía de configuración

AOpen

AOpen MX4SGI-L Hoja de datos

AOpen

AOpen AX45F-8X MAX Guía de configuración

AOpen

AOpen MX36LE-UI Guía de configuración

AOpen

AOpen AP5T Manual de usuario

Manuales populares de Placa madre de otras marcas

DFI

DFI SD170 Manual de usuario

ASROCK

ASROCK ROMED8-2T Manual de usuario

Asus

Asus P2L97A Manual de usuario

Winmate

Winmate IC70 Manual de usuario

Asus

Asus MES-B Manual de usuario

Grantech

Grantech SYS8F377VGGA-3OMN Manual de usuario

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manual de usuario

Gigabyte

Gigabyte GA-9IVDT Manual de usuario

Texas Instruments

Texas Instruments ADS8372EVM Manual de usuario

Commell

Commell MS-C73 Manual de usuario

IBT Technologies

IBT Technologies MB860 Manual de usuario

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manual de usuario

Biostar

Biostar M7VIT Bravo Instrucciones de funcionamiento e instalación

Intel

Intel D33217CK Manual de usuario

Asus

Asus F1A55-M LX PLUS R2.0 Manual de usuario

EPC

EPC EPC9147C Manual de usuario

Asus

Asus EX-B760M-V5 D4 Manual de usuario

EPOX

EPOX MU-8KHA0010 Manual de usuario
