Anzzi LLANO Series Manual de usuario

Model#

SP-AZ047

SP-AZ8095

LLANO & Colossal Series

INSTALL GUIDE

PERFECTION IS OUR TRADITION™

v2.0516

Parts List Pg. 1

Before You Start Pg. 2

Spec Drawing Pg. 3

Installation Pg. 4

Care & Maintenance Pg. 11

Warranty Pg. 12

Registration Final Page

TABLE OF CONTENTS

YOUR REVIEWS MATTER!

For more information please call 1-844-44-ANZZI

or email us at [email protected]

The ANZZI™ Family thanks you for your purchase and hopes you enjoy your very own ANZZI

product for years to come! In the meantime let us know about your experience? We would love

to hear your thoughts from the packaging to the quality and function of the product.

Leave a review on www.ANZZI.com/reviews and let everyone know how satisfied you are with

ANZZI!

Also, we humbly request submitting as many pictures as possible along with your review.

Millions of shoppers will want to know about your experience with our products. Don’t just tell

but show, too!

PARTS LIST

PERFECTION IS OUR TRADITION™

pg. 1

1. Shower Head

2. Diverter

3. Body Jets

4. Mixer

5. Hand Shower

Component no.

Component

Material

clip

s/s

connector

brass

body

tempered glass

washer

silicon

head shower

ABS

glass clamp

brass

Shelf

glass

body jets

ABS

knob

zinc

knob plate

brass

function cartridge

ABS

handle

zinc

handle plate cover

brass

ABS

faucet body 1

brass

backside body

pvc

braided hose

s/s

flexible hose

s/s

hand shower hlolder

ABS

one way joint

ABS

faucet body 2

brass

hand shower

ABS

fixing

flow restricter

bar

S/S

PVC hose

PVC

thermostatic cartidge

PERFECTION IS OUR TRADITION™

pg. 2

For any questions or concerns contact

our dedicated technical support team

at 1-844-44-ANZZI.

BEFORE YOU START

Screwdriver Channel Locks

Adjustable Wrench Allen key

Goggles

Teflon tape

Recommended Items

ATTENTION: Please read all instructions thoroughly

including all warnings, attentions and notes before

beginning installation.

LLANO Series

PERFECTION IS OUR TRADITION™

pg. 3

SPEC

DRAWING

SP-AZ047

Perfection is our Tradition™

Material: Tempered Glass

Finish: Black Tempered Glass

Handles: 2

Jets: 4

Shower: Ø7.677”

Sprayer: 60” reach

Weight: 28.38 lbs

Height: 55.12”

Supply: 1/2” connections

Flow: 2.5 gpm *when reducer is removed

Features

Heavy Rain™ Showerhead

Acu-Stream™ high pressure body jets

Euro-Grip™ hand held sprayer

Rhino Alloy™ certified materials

13.98

9.84

55.12

Figure A

INSTALLATION (SETUP)

PERFECTION IS OUR TRADITION™

pg. 4

Before drilling any holes for the shower panel brackets, ensure there are no hidden cables or

pipelines aligned with the desired drilling position.

Drill the two holes for the top bracket 1” apart at the desired height.

Drill the two holes for the bottom bracket 1” apart below the top bracket.

IMPORTANT

Step A

Step A.2

Ø 6mm Drill

1 INCH

Figure B

INSTALLATION (SETUP)

PERFECTION IS OUR TRADITION™

pg. 5

Insert the wall anchors into the pre-drilled holes as shown in Figure B.

Place the shower panel brackets aligned with the drilled holes and using a Philips screw-

driver tighten the screws to secure the brackets.

Step B

Step C

Figure C

Figure 1

Figure 2

INSTALLATION (HANDSHOWER & SHELF)

PERFECTION IS OUR TRADITION™

pg. 6

Insert the hand shower holder through the pre-drilled hole on the shower panel.

Install the water supply hose for the hand shower onto the holder, as shown.

Make sure all O-rings are inserted to prevent leakage.

Once the shower panel is fully installed and hung on the bracket, you can install the hand

shower hose to the holder connection.

Step 2A

Attach the shelf to the glass clamp, using the screw to fix it.Step 1

Step 2B

Step 2C

Step 2D

Figure 2

INSTALLATION (HANDSHOWER)

PERFECTION IS OUR TRADITION™

pg. 7

Finally, install the hand shower to the hose, as shown.Step 2A

1 Setting

Hand

Shower

3 Setting

Hand

Shower

Figure 3

INSTALLATION (SHOWER HEAD)

PERFECTION IS OUR TRADITION™

pg. 8

Install the shower head to the upper threader connectin on the shower panel as shown.Step 3A
