Anton Paar SmartRef Instrucciones originales

SmartRef

Instruction Manual and

Safety Information

(Original)

This document may contain errors and omissions. If you discover

any such errors, or if you would like to see more information in this

document, please contact us at our address below. Anton Paar

assumes no liability for any errors or omissions in this document.

Changes, copyright, trademarks, etc.

This document and its contents may be changed or amended by

Anton Paar at any time without prior notice.

of it, may not be reproduced, changed, copied, or distributed by

means of electronic systems in any form (print, photocopy, microlm,

or any other process) without prior written permission by Anton Paar.

Trademarks, registered trademarks, trade names, etc. may be

used in this document without being marked as such. They are the

property of their respective owner.

Further information

Published and printed by Anton Paar ConsumerTec GmbH, Austria

Address of the instrument producer:

Anton Paar ConsumerTec GmbH, Kärntner Straße 418

A-8054 Graz / Austria – Europe

Tel: +43 (0) 316 257-0

Fax: +43 (0) 316 257-257

E-Mail: support@my-smartref.com

Web: www.my-smartref.com

Date: 06/2022

Document number: I02IB001EN-A

ABOUT THIS MANUAL 4

CONVENTIONS FOR SAFETY MESSAGES 4

SAFETY INSTRUCTIONS 4

PACKAGE CONTENTS 8

SMARTREF OVERVIEW 9

STARTING UP SMARTREF 11

MEASUREMENT 11

CLEANING AND STORING THE DEVICE 12

CHECKS AND ADJUSTMENTS 13

EXCHANGING THE BATTERIES 14

TECHNICAL DATA 16

EU DECLARATION OF CONFORMITY 17

UK DECLARATION OF CONFORMITY 18

WARRANTY AND RETURNS 18

BLUETOOTH REGULATIONS 19

ABOUT THIS MANUAL

This instruction manual informs you about the installation and the safe handling and use of the product. Pay

special attention to the safety instructions and warnings in the manual and on the product.

The instruction manual is a part of the product. Keep this instruction manual for the complete working life

of the product and ensure that it is easily accessible for all people involved with the product. If you receive

any additions to or revisions of this instruction manual from Anton Paar, these must be treated as part of the

instruction manual.

Download the current version of the instruction manual from: www.my-smartref.com

CONVENTIONS FOR SAFETY MESSAGES

The following conventions for safety messages are used throughout this instruction manual:

WARNING!

Warning indicates a hazardous situation which, if not avoided, could result in death or serious injury.

CAUTION!

Caution indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.

NOTICE

Notice indicates a situation which, if not avoided, could result in damage to property.

TIP

Tip gives extra information about the situation at hand

SAFETY INSTRUCTIONS

Read this instruction manual before using the device.

Make this instruction manual easily accessible to all persons working with the device.

Follow all tips and instructions in this instruction manual to ensure the correct use and safe functioning of the

device.

LIABILITY

This instruction manual does not claim to address all safety issues associated with the use of the device and samples. It is

your responsibility to establish health and safety practices and to determine the applicability of regulatory limitations.

Anton Paar warrants the proper functioning of the device only if no modications are made to mechanics, electronics, or

device software.

Use the device only for the purpose described in the instruction manual. Anton Paar is not liable for damages caused by

incorrect use of the device.

The results delivered by the device depend not only on the correct functioning of the device, but also on various other factors.

Do not base any decisions concerning safety or commercial issues on data measured by a SmartRef.

INSTALLATION AND USE

WARNING!

Do not use the device in medical areas.

Use the device as a stand-alone unit (the SmartRef cannot be operated without a smartphone or tablet). Do not combine the

device with other instruments or devices for automation purposes!

Use only accessories and consumables supplied or approved by Anton Paar.

Ensure that all operators are familiar with the safety instructions for the device.

Keep the device away from children.

Ensure that the device is sufciently supervised during operation.

WARNING!

In case of damage or malfunction, do not continue operating the device. Do not operate the device under conditions which

could result in damage to goods or injuries or loss of life.

Do not expose the device to temperatures below 0 °C (32 °F) if the sample well contains water. Freezing water can cause

damage to the sample well.

OPERATION IN AREAS WITH RISK OF EXPLOSION

WARNING!

The device is not explosion-proof and therefore must not be operated in areas with risk of explosion.

PERSONAL SAFETY

WARNING!

Always keep a distance of at least 15 cm (6 in) between the device and an implanted cardiac pacemaker or debrillator.

CAUTION!

During operation of the device, the operator must be equipped with appropriate personal protective equipment (safety

goggles, gloves).

GENERAL PRECAUTIONS

Observe and adhere to your national safety regulations regarding the handling of all substances associated with your

measurements (e.g. use safety goggles, gloves, respiratory protection, etc.).

For the handling of substances, abide by the corresponding material safety data sheets.

WARNING!

Fill only substances which will not pose a risk if they leak from the device in case of damage or malfunction.

WARNING!

Before a measurement, check the wetted parts of the device for chemical resistance to the samples and cleaning agents

used.

Fill only liquids which will not attack the wetted parts of the device.

WARNING!

Take care that the liquids (samples and cleaning agents) that you use are chemically compatible when they come into contact

with each other. They must not react exothermally or produce harmful substances.

Take measures that spilled liquids cannot get into plug connections or venting slots of electrical appliances.

Do not leave the device in a location exposed to direct sunlight or near a heat source for any extended period of time.

Do not change the ambient temperature of the device abruptly.

CAUTION!

Be careful with hot samples. Handling samples with temperatures of more than 50 °C (122 °F) bears the risk of burns.

Observe the maximum sample temperature.

CAUTION!

Do not drop the device and protect it against strong impacts as this may lead to a malfunction.

PRECAUTIONS FOR FLAMMABLE SAMPLES AND CLEANING AGENTS

CAUTION!

Keep potential sources of ignition, like sparks or open ames, at a safe distance from the device.

Store only the minimum required amount of sample, cleaning agents, and other ammable materials near the device.

Do not spill sample/cleaning agents or leave their containers uncovered. Immediately remove spilled sample/cleaning agents.

Ensure that the setup location is sufciently ventilated. The environment of the device must be kept free from ammable gases

and vapors.

Provide re-extinguishing equipment.

BATTERY HANDLING

Make sure you insert the batteries with the correct polarity.

Keep batteries away from children.

Do not leave batteries lying around unattended. They can be dangerous for children or pets if they use them as toys.

If a battery has been swallowed, seek medical advice immediately.

Leaking or damaged batteries can cause burns if they come into contact with skin. Use gloves for their handling.

Never short-circuit or open batteries.

Do not expose batteries to heat or throw them into re.

Do not charge non-rechargeable batteries. There is a risk of explosion.

WARNING!

Do not insert damaged batteries in the battery compartment. They can cause permanent damage to the device and re.

WARNING!

Do not use lithium ion rechargeable batteries or lithium ion batteries with the device.

Use only batteries type AAA LR03 (alkaline) or rechargeable batteries type AAA HR03 (NiMH).

Do not replace the batteries in an environment with high humidity. Vapor could be trapped inside the unit, which could cause

condensation, permanently damaging your device.

WARNING!

In case you are not using the device for a long time, remove the batteries. Batteries could leak or be damaged.

DEVICE RETURNS

For returns, contact the vendor of the device. The device must be cleaned before return.

You must not return devices which are contaminated by radioactive materials, infectious agents, or other harmful substances

that can pose health hazards.

DISPOSAL

Concerning the disposal of the device, observe the legal requirements in your country.

PACKAGE CONTENTS

SmartRef has been tested and packed carefully before shipment. However, damage may occur during transport.

Keep the packaging material for possible returns and for further questions from the transport or insurance company.

To check the delivery for completeness, compare the supplied parts to those listed in the supplied parts list below.

If a part is missing or damaged, contact the vendor of the device.

NOTICE

A device stored at low temperatures can cause condensation of moisture on sensitive parts. To prevent malfunctions, allow

the transport package and its contents to come to thermal equilibrium prior to opening.

SUPPLIED PARTS

SMARTREF OVERVIEW

ABOUT THE DEVICE

The digital refractometer SmartRef measures the refractive index of liquids. In addition, a temperature sensor measures

the sample temperature directly at the sample area. The refractive index of a pure material is a physical property and can

be used to identify and characterize materials. The refractive index of a dissolved substance in a solvent correlates with

its concentration and can therefore, be used for concentration measurements. Many other scales can be derived from the

refractive index.

You operate and control the device via the mobile app running on your smartphone. For the communication between the

device and your smartphone, Bluetooth Low Energy is used. Via the app various measurement units based on the refractive

index can be calculated (e.g. %Brix).

Picture Quantity Description Mat. no.

SmartRef digital refractometer

(incl. 2 AAA batteries) 251846

4Pipette 253411

DEVICE VIEWS

Sample Well

Status LED

Prism

Power Button

Figure 1: Top View

Indication

of sample

lling height

Figure 2: Sample Area

Screws to

open the

Battery

compartment

Type Plate

Figure 3: Bottom View

Figure 4: Disassembled View with batteries oriented in

correct polarity
